4. Quick Start

1. Start the installation with turning off the Manhattan II DAC and disconnecting it from mains.
2. Unscrew the screws securing the top lid of the converter and remove the top lid.
3. Unscrew four M3 screws that were inserted in the brass spacers in the center of the Manhattan
main PCB (If there was no screws please use attached spares in the next steps).
4. Unplug the ANALOG IN2 L and ANALOG IN2 R wires from the header on the mainboard.
5. Connect two attached wires to this header and the other end to the headers on the Phono card
described OUTL, OUTR.
