  • Page 3 PS Gate is a Wi-Fi programmable џ additional settings. thermostat controller. The device is an Internet connected relayed PS Gate is a complex system with џ module, that includes a weekly which you not only open and close schedule. The latter could be...
  • Page 4 Complete integrated control system џ Easy to use and user friendly software interface џ Mobile application running on all mobile OS џ PS Gate could be used for Control of garage doors џ Control of entrance doors џ Control of barriers џ...

  • Page 5: Technical Specifications

    Technical specifications 61.6mm 45.1mm 42.20mm Схема 1...
  • Page 6 Switching socket 3А Air humidity during transportation from 5% till 90% without condense Charging block 8-36V AC/DC Working frequency Wi-Fi (b/g/n) 2,4GHz Size 90,2 x 53,3 x 56,5 mm (LxWxH) Working temperature 0°— + 45°C -20°— + 60°C Storage temperature Working humidity 90% without condense —...

  • Page 7: Safety Instructions

    Safety instructions Please, read before using the device for the first time The outlined safety procedures below are to be followed while using the current product. Please, do follow all warnings in the device’s user manual. General safety instructions You are the only one responsible for the device’s usage, as well as for any caused damages in consequence of that.
  • Page 8 national and regional legislations are followed. The device is to be installed in electric switchboards or in the device/s it will manage and is created to control household devices and equipment. Any unauthorized reconstruction and/or product modification is strictly forbidden following the European safety and approval directives (CE). Services, settings and repairs could be accomplished only by an authorised service provider.
  • Page 9 Attention! Damaged power supply cables are a life treat as could lead to an electric shock. Do not use the device if there is a damaged cable, power supply cord or network plug. In the case of power supply cable’s damage, please leave its repair to a qualified professional! Do not leave children with the device without supervision! Do not let children play with the device.
  • Page 10 Electric safety This device could be used only when powered by the specific supply unit. Every other way could be dangerous and terminates the validity of any issued device’s certificate. Use the correct external power supply. The device should be powered only by the specific power supply as indicated on the nominal electric power supply’s nameplate.
  • Page 11 In case you are in a flammable materials’ environment, the device must be turned off and the user is to follow all instructions and warning labels. The sparks in such places could cause fires or explosions, leading to injuries and even death. We highly recommend to not use the device in fueling areas, workshops or gas stations.
  • Page 12 with high air humidity. If the device ever gets wet, do not attempt to dry it off in a furnace or a dryer for the risk of damage is high! Do not use the device after a sudden temperature change. If you are transferring the device between environments with big temperature and humidity level differences, it is possible for the steam to condense on the surface and inside of the device.
  • Page 13 the use of certain hazardous substances in electrical and electronic equipment (RoHS) and its recasts. Burns and fire prevention Do not use the device if the premises’ temperature goes above 40°C. Keep the highly flammable materials away from the device. Make sure free air access around the device is available.
  • Page 14 PS Gate is a Wi-Fi programmable thermostat, suitable for domestic and industrial buildings without the need of additional wiring. With PS Gate you can easily control the movements of garage and portal doors, external doors, interior and exterior roller shutters, as well as other electric devices such as electric light bulbs, irrigation systems and more, all through your smartphone, smartwatch or tablet.
  • Page 15 PS Gate is created to work on the following environmental conditions: - For premises’ work; - For altitude up to 2000m; - For ambient temperature from 0°С till +45°С; - For average maximum air humidity for temperature of up to 31°С - 80%, linear decreasing to 30% average humidity for 45°С...
  • Page 16 Unpack the device and take the two main elements out of the box (Scheme 1). Scheme 1 Connect PS Gate to a chosen electric device or appliance. Attention! Switch off the power supply before installing PS Gate We highly recommend the installation to be performed by a qualified technician.
  • Page 17 Connect the two connection points of the device you wish to control to the outputs NO and COM, that is to the relays’ normally open outputs. The device’s installation is outlined in Scheme 2. The device must be installed and connected by a qualified professional.
  • Page 18 1.2 Central control block’s installation Connect the power supply cable to the Scheme 3 PS Gate’s main control block. After that, connect it to the power supply (Scheme 3). 1.3 Installation possibilities PS Gate is a product, constructed for installation in limited access zones and must...
  • Page 19 the power supply (the controller itself, as well as the chain it controls through the relayed exit). - The device is to be installed only in places with limited access with the assistance of an instrument or key and are accessible only to the service personnel or a user who has passed the initial training.
  • Page 20 - The device is installed only in a shell allowing the needed level of protection of the end product. Its installation on accessible surfaces and covers, allowing the easy access without the use of any instrument, is strictly forbidden. - The device’s installation must be accomplished in such a way as to deem it impossible to accidentally activate the reset button.
  • Page 21 Step 2: Example connection scheme of PS Gate to a front door Scheme 5 PS Gate is parallelly connected to the chip reader (Scheme 5). A signal is sent to the central control module’s ‘sig’ entrance through the PS Gate relay’s...
  • Page 22 Scheme 6 PS Gate is parallelly connected to the central control module (Scheme 6) and sends direct charge through the NO contact to the lock + 12V DC. This type of connection is allowed if the electric lock uses a direct current and its supply voltage is the same as the central control module one.
  • Page 23 Scheme 7 PS Gate controls external relay through an NO contact (Scheme 7) which is powered by the central control module’s power supply. With this external relay, the electric lock could be triggered by an external power source and to not influence the work (exits) of the central control...
  • Page 24 In order for the device to work properly, it must be connected to an Internet network. After the installation is finished, provide a supply voltage to the device and PS Gate . Wait 10 seconds, press and hold the button for three seconds and follow the device’s light indication.
  • Page 25 Log in to your profile with your email and password. If this is your first PS Gate device purchased and you have not registered yet, you can do that in COMPUTHERM B Series’s webpage: https://computhermbseries.com/ Press the ‘Add’ button for adding a new device, located in the upper hand side of the screen.
  • Page 26 Take a look at the blue light emitting diode and when its light goes off, and then stays on permanently, PS Gate is all set up for work. Look at the mobile device’s screen. The app is now ready to control PS Gate. If you have used Smart Config mode, please proceed to Step 4.
  • Page 27 3.2.1 Initiate a wireless network search from your smartphone or laptop and connect to the PS Gate’s AP (the wireless network). Every device creates a network with its own name, starting with PSGate_xxx and a combination of letters and numbers. For example PSGate_254 and it does not require a...
  • Page 28 Scheme 3.2.2 After connecting, your browser will automatically open a new page giving you the chance to choose the wireless network, to which you want to connect the device (Scheme 10). If your browser does not open automatically, please open it manually for the automatic opening of the browser is a manual setting and thus it could be turned off.
  • Page 29 3.2.4 Choose the desired Wi-Fi network, type in your password and click on the ‘Connect’ button - Scheme 11 3.2.5. In up to 20 seconds PS Gate will switch to a working mode and the light indicator will be on all the time, blinking shortly per every second.
  • Page 30 The only way to connect with PS Gate is via the user profile, associated with the particular device. If you do not have one, you can load the COMPUTHERM’s page: https://computhermbseries.com/ or download and install the COMPUTHERM B Series app in your smartphone or tablet:...
  • Page 31 4.2 If you choose to use a browser, open https://computhermbseries.com in your PC desktop or mobile device and press the ‘Log in’ button in the upper right corner (Scheme 12). Scheme 4.3 If you access the website or the app for the first time, you need to register or log in with your Facebook or Google + accounts just by clicking the particular button.
  • Page 32 4.4 New user registration. Fill in the registration form’s fields and click the ‘Register ’ button. You are now registered and may enter the app. (Scheme 14). Scheme 14...
  • Page 33 5.1 Home Screen —After the successful login with username and password, you should already be seeing the home screen in your profile and can add the device you have received. Enter the serial number of your PS Gate device that you previously connected to the wireless network (Scheme 15).
  • Page 34 Scheme In order to set a name for your device, as well as a time zone and location, press button in the upper right corner and fill in the fields (Scheme 17). From that window you can also delete the device from your profile via clicking the deletion button in the bottom right corner.
  • Page 35 Scheme 17 5.3 You can now set and control your device. In the upper left corner you can find two buttons: Main screen and Settings (Scheme 18). Main screen Settings Scheme 18...
  • Page 36 Step 6: Main screen 6.1 In the main page you can find a button for opening and closing or turning on and off of the connected system. By pressing the button, an impulse is sent with predefined length (Scheme 16). 6.2 Settings screen Scheme 19...
  • Page 37 Step 7: PS Gate servicing 7.1 PS Gate is cleaned with a dry or slightly dampened with water towel. The use of aggressive or abrasive cleaning liquids is strictly forbidden.

  • Page 38: Warranty

    Warranty The warranty of the device is 24 months from the date of purchase. The serial number of the PS Gate device is unique and you need to present it in the event of a problem during the warranty period.
  • Page 40 Manufacturer: Quantrax Ltd 34 Fülemüle Str. 6726 Szeged, Hungary www.quantrax.hu...
