PROGRAMMING THE VSSI-PRO
CAPTURE TO MEMORY
Press the "Up" or "Down" button to move the cursor to "CAPTURE TO MEMORY" and press "Set". The following display
will appear (example only):
Press "Set" to return to the previous menu.
DUMP TCP/IP
Press the "Up" or "Down" button to move the cursor to "DUMP TCP/IP" and press "Set". The following sub-menu will
appear:
An asterick shows which of IP Addresses 1-4 is selected. Press the "Up" or "Down" button to move the cursor to the
desired IP Address 1-4 and press "Set". The cursor will start flashing. Press the "Up" or "Down" button to set the value.
The choices are 0 through 255. When the desired value is displayed press "Set". Press the "Up" or "Down" button to
move the cursor to "EXIT" and press "Set". You will be presened with the following display (example only):
Press "Set" to return to the previous menu.

ATM DEMO

This demonstrates the VSSI Pro's use as an Automatic Teller Machine Interface. To access this demonstration, press
the "Up" or "Down" button to move the cursor to "ATM DEMO" and press "Set". The demo will start after a few seconds.
To exit this demo, press "RESET". This will take you out of the programming menu entirely though, and you will have to
re-enter the main-menu to continue programming
VSSI-Pro VIDEO SERIAL ATM INTERFACE
PROTOCOL :
RX BAUDRATE :
TX BAUDRATE :
DATA ENCODE :
CAPTURE DATA TO MEMORY
CHA RX BYTE :
CHB RX BYTE :
Figure 55: CAPTURE TO MEMORY Display
IP ADDRESS 1
IP ADDRESS 2
IP ADDRESS 3
IP ADDRESS 4
EXIT
Figure 56: DUMP TCP/IP Sub-Menu
PROTOCOL :
RX BAUDRATE :
PARITY :
DATA BIT :
BUFFER REMAINING : 03071
RECEIVIED BYPE :
Figure 57: DUMP TCP/IP Display
.
44
ASYNC
19200
19200
NRZ
ASCII
00000
00000
0
0
0
0
ASYNC
19200
NONE
8
0000
