PROGRAMMING THE VSSI-PRO
DEST ID and SRC ID
Choices: 1 through 32
Press the "Up" or "Down" button to move the cursor to "DEST ID" or "SCR ID" and press "Set". The cursor will start
flashing. Press the "Up" or "Down" button to toggle between values and press "Set" when the desired value is dis-
played.
EXIT
Press the "Up" or "Down" button to move the cursor to "EXIT" and press "Set" to return to the previous menu.
VSSI-Pro
VIDEO IN
CAMERA
DB-9(F)
VIDEO OUT
RG-59U
VIDEO IN
RG-59U
RS-232
ATM
VIDEO OUT
VIDEO IN
RG-59U
MONITOR
Figure 38: VSSI-Pro with DVR Connections
VSSI-Pro VIDEO SERIAL ATM INTERFACE
31
