AVE Time-Date-Character-Title TDCT-Pro Operation Manual

Time-date-character-title
Hide thumbs
Table of Contents

Advertisement

Quick Links

TDCT-Pro
Time-Date-Character-Title
Operation Manual
March 2007
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Time-Date-Character-Title TDCT-Pro and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for AVE Time-Date-Character-Title TDCT-Pro

Summary of Contents for AVE Time-Date-Character-Title TDCT-Pro

  • Page 1 TDCT-Pro Time-Date-Character-Title Operation Manual March 2007...

  • Page 2: Table Of Contents

    HER OWN EXPENSE WILL BE REQUIRED TO TAKE WHATEVER MEASURES MAY BE REQUIRED TO CORRECT THE INTERFERENCE. Copyright C ... 6 ... 7 ... 8 ... 8 ... 9 ... 9 CAUTION! RISK OF ELECTRICAL SHOCK! DO NOT OPEN! WARNING! AVE Thailand Co., Ltd. 2000-2006...

  • Page 3: Introduction

    TDCT and a communi- cation device (e.g Personal computer). • Synchronizing the time and date between master and slave. • Compatible with the AVE RS-232 to RS-485 Adapter for dis- tances of up to 3000’ for master slave connections.

  • Page 4: Programming

    3. PROGRAMMING TDCT-Pro has an easy programmable option that can be ac- cessed by pressing “UP”, “DOWN”, “SET”, button andby press- ing and releasing the “RESET” button. Figure 2: Four Front Pannel Push Buttons of TDCT-Pro 3.1 FRONT CONTORL PANEL The front panel controls are provided to allow simple chang- ing of the display’s vertical and horizontal position and the gray scale or border.
  • Page 5 PROGRAMMING CONT. Changing the Gray scale Down 1) Press and hold the “Down” button 2) Press and release the “Reset” button 3) Release the “Down” button 4) Press “Down” or “Up” to select the Gray scale 5) When choice is made, press and release the “Reset” button Changing the Horizontal Position Down 1) Press and hold the “Up”...

  • Page 6: Main Programming Menu

    PROGRAMMING CONT. Main Programming Menu Following is a detailed description of the Menu selections and the programming capabilities of the TDCT-Pro. Figure 3: TDCT-Pro main menu Note: If a sub menu has an "EXIT" selection, always go there and press "SET". Pressing "RESET" at the main menu exits you from the program Set Master / Slave This programming feature can be used to select the TDCT-Pro as a...

  • Page 7: Time And Date

    PROGRAMMING CONT. By selecting the Set Address between 0 to 254 make TDCT-Pro to act as a slave and that make TDCT-Pro ready to receive command from the master. Selecting “ANY” will make TDCT-Pro as a stand-alone unit. Selecting “MSTR” make the TDCT-Pro to act as a master.

  • Page 8: Set Time And Date

    PROGRAMMING CONT. Time Display can be programmed on or off by selecting ON or off. Date can be displayed in 1 line or, 2 lines or can be pro- grammed off by selecting Date display feature. If the counter is turned on then the date is automatically displayed in the 2nd line.

  • Page 9: Screen Setup

    PROGRAMMING CONT. The title can be programmed either ON or OFF by selecting ON or OFF from the tiler menu. A 20 characters title can be entered by selecting the title from the programming menu. 3.8 Screen Setup Character size, position, and gray scale is programmed from this menu.

  • Page 10: Cables

    4. Cables 4.1 Cable User are able to program TDCT-Pro via RS232C by TDCT- Pro software for Windows. The cable is optional for this product. COM1 or COM2 (Newer computer required COM1 cable) cable are needed if RS-232 device is used to set the time and date and title of the TDCT-Pro See Appexdix for TDCT-Pro software and command set.

  • Page 11: Appendix

    RS-485 Network For extended distance use the AVE RS-232 to RS-485 converter and get extend up to 3000’ between the Master and Slave units. RS-232 to RS-485 Converter APPENDIX TDCT-Pro Software To send the title to the TDCT-Pro first enters the address of the TDCT- Pro in the address window.
  • Page 12 TDCT-Pro Windows Software RS232 Command Protocol 1. Update Titler(Master) Command /TT(Address)<Title><CR> Description This command is only support Master mode Address (1 byte) Title (1-20 bytes) <CR> (1 byte) Main Menu 0 - 255 text strings Carriage return...
  • Page 13 Ex Update titler at address 65 with Camera 65 /TTACamera 65<CR> 0x2F 0x54 0x54 0x41 Address 65 0x43 0x61 0x6D 0x65 0x72 0x61 space 0x20 0x36 0x35 <CR> 0x0D Carriage return 2. Update Hour Command /Hxx Description H (1 byte) xx(2 bytes) ;00=12AM,01=1AM,..,12=12PM,13=1PM,..,23=11PM Ex Update hour = 1AM(12 hour) or 13:00(24 hour)
  • Page 14 M(1 byte) xx (2 bytes) 00-59 Ex Update minute = 3 /M03 0x2F 0x4D 0x30 0x33 4.UpdateYear Command /Yxx Description Y(1 byte) xx(2 bytes) 00=2000,01=2001,..,10=2010,..,99=2099 Ex Update Year = 2007 /Y07 0x2F 0x59 0x30 0x37 5.Update Month Command /mxx Description m(1 byte) xx(2 bytes) ;01=JAN,02=FEB,..,10=OCT,..,12=DEC...
  • Page 15 6.Update Date Command /Dxx Description D(1 byte) Date xx(2 bytes) 01-31 Update Date = 5 /D05 0x2F 0x44 0x30 0x35 7.Update Titler(Slave) Command /T(Address)<Title><CR> Description This command is only support Slave mode Address (1 byte) Title (1-20 bytes) <CR> (1 byte) Ex Update titler at address 65 = Camera 65 /TACamera 65<CR>...
  • Page 16 ASIA AVE (Thailand) Co., Ltd. 217/4 Crystal Garden Soi 4 (Nanatai), Sukhumvit Rd. Klongtoey, Klongtoey Bangkok, 10110 Thailand Tel: 662-656-8231 Fax: 662-656-9554 Email: ave@avethailand.com www.avethailand.com NORTH AMERICA AVE USA 2000 West Governors Circle, Suite E Houston, Texas 77092 Tel: 281-443-2300 Fax: 281- 443-8915 Email: aveus@ave-us.com...
