  • Page 1 confidea System Description...
  • Page 2 Attention: This manual for Wireless Confidea System 3.0 is valid only for all WCAP+ firmware version ≥ 1.06 WCAP fpga version ≥ 1.06 WDU+ firmware version ≥ 1.06 WCAP+ 71.98.0033 Cocon ≥ 3.02...

  • Page 3: Table Of Contents

    Conformity and Certification info for Japan Important safety instructions General conformity info Power Connections Confidea wireless system information General system architecture 4.1.1 Components 4.1.2 Standalone system Wireless network and frequency bands Wireless LAN Televic Confidea wireless system. 5.2.1 Frequency bands...

  • Page 4: Copyright Statement

    However, the information in this manual is supplied without warranty, either express or implied. Neither the authors, Televic Conference NV, nor its dealers or distributors will be held liable for any damages caused or alleged to be caused either directly or indirectly by this book.

  • Page 5: Safety Instructions And Conformity Info

    3 Safety Instructions and conformity info The Confidea Wireless Conference system is state of the art and has been designed to meet quality. Nevertheless, the individual components of the conference system can cause danger for persons and material assets if The conference system is not used as intended, The conference system is set up by personnel not familiar with the safety regulations, The conference system is converted or altered incorrectly,...

  • Page 6: Conformity And Certification Info For Japan

    Wireless Access Point equipment not expressly approved by should be installed and operated with Televic NV may void the FCC minimum distance of 20 cm between the authorization to operate this equipment. radiator and your body.
  • Page 7 The safety and operating instructions should be retained for future reference. Heed Warnings All warnings on the product and the operating instructions should be adhered to. Follow Instructions All instructions for installation or operating / use should be followed. Cleaning Unplug this product from the wall outlet before cleaning.
  • Page 8 Grounding or Polarization Do not defeat the safety purpose of the polarized or ground-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong. The wider blade or the third prong are provided for your safety.
  • Page 9 When the product exhibits a distinct change in performance-this indicates a need for service. Replacement Parts When replacement parts are required, be sure the service technician has used replacement parts specified by the manufacturer or have the same characteristics as the original part. Unauthorized substitutions may result in fire, electric shock, or other hazards.

  • Page 10: General Conformity Info

    General conformity info The Confidea Wireless Conference system is compliant with following standards:  EN60065  EN55103-1/-2  IEC60914 Power Connections For permanently connected equipment, a readily accessible disconnect device shall be incorporated in the fixed wiring; for pluggable equipment, the socket-outlet shall be installed near the equipment and shall be easily accessible.

  • Page 11: General System Architecture

    4.1 General system architecture 4.1.1 Components Confidea G3 is a wireless conference system offering conferencing capabilities over a robust wireless link. Depending on the model, these facilities include discussion, voting and/or language distribution. The units (delegates/chairman) are table top units that make a wireless link to a Wireless Conference Access Point called WCAP G3.

  • Page 12: Wireless Network And Frequency Bands

    5 Wireless network and frequency bands 5.1 Wireless LAN Most of the wireless local area computer networks today are based on the IEEE 802.11 a/b/g standards. These standards were developed by the IEEE (Institute of Electrical and Electronics Engineers) in order to insure inter-operability between different WLAN vendors. 802.11 Release Frequency...

  • Page 13: Televic Confidea Wireless System

    5.2 Televic Confidea wireless system. The wireless network of the Televic Confidea wireless system is based on the 802.11 a/g standards. Additional protocols have been added on top of the 802.11 a/g standards to provide high robustness against interference from other wireless devices. These additional protocols also ensure a guaranteed quality of service for the audio streams on the wireless network.
  • Page 14 In the 2.4 GHz ISM (Industrial Scientific Medical) band, there are 13 overlapping high- frequency carriers available. Only 3 non-overlapping carriers are available. Europe Japan Korea ISM 2.4 GHz Canada 2412 MHz 2417 MHz 2422 MHz 2427 MHz 2432 MHz 2437 MHz 2442 MHz 2447 MHz...
  • Page 15 In the “RLAN high” frequency band, there are 10 non-overlapping carriers. Europe Japan Korea RLAN HIGH Canada 5500 MHz 5520 MHz 5540 MHz 5560 MHz 5580 MHz 5600 MHz 5620 MHz 5640 MHz 5660 MHz 5680 MHz 5700 MHz In the “5 GHz ISM” frequency band, there are 5 non-overlapping carriers. All of these carriers can be used.

  • Page 16: System Components

    System Components Wireless contribution units Introduction Controls and indicators Installation Startup and shutdown of delegate unit Microphone Introduction Electrical and acoustic properties Microphone connector Operation Battery pack Introduction Controls and indicators Installation Wireless Conference Access Point (WCAP) Introduction Installation 9.2.1 Wall Mounting 9.2.2 Tripod Mounting...

  • Page 17: Introduction

    6.1 Introduction The wireless contribution units, called Confidea WDU, consist of Delegate and Chairman Units. Both are used for speech reinforcement in a conference room. The chairman units are used to guide and control an ongoing discussion. 6.2 Controls and indicators The Confidea WDU has the following features: 1.
  • Page 18 15. Battery status LEDs Red LED blinking the remaining operation time 1 Hz 4h remaining 2h remaining 1h remaining Note: Units with the out of range LED on will be switched off after 2 minutes.
  • Page 19 Confidea DD G3 Confidea CD G3...
  • Page 20 Confidea DV Confidea CV...
  • Page 21 Confidea Back...

  • Page 22: Installation

    6.3 Installation In order to use the Confidea WDU, the battery and microphone need to be installed. For instructions, see the microphone and battery installation and handling. Disconnect the battery to avoid unwanted operation of the unit. Keep the devices in a clean and dry area.

  • Page 23: Microphone

    7 Microphone 7.1 Introduction The Confidea-D MIC30SL (30 cm) - D MIC40SL (40 cm) - D MIC50SL (50 cm) pluggable microphone is used with the different delegate- and chairman units. This microphone ha a uni- directional response for optimum performance even in noisy conditions, and has a very low susceptibility to RF-interference from mobile phones.
  • Page 24 Indicator ring: shows the status of the microphone Union nut: attaches the pluggable microphone to the unit Microphone plug: connects the microphone to the unit The colour of the microphone indicator ring shows the status of the microphone. Color Condition Red (on) Microphone active Red (flash)

  • Page 25: Battery Pack

    8 Battery pack 8.1 Introduction The Confidea wireless battery pack is used with the wireless conference units. Output voltage: 7.2V Capacity: 6600 mAh Charge time: 4 Hours Max charge voltage: Charge current: Autonomy: + 28 Hours (Typical) 8.2 Safety...

  • Page 26: Controls And Indicators

    Warning: Danger of explosion if the battery pack is incorrectly replaced Replace with the same or equivalent type Do not use or leave the battery pack at very high temperature conditions (e.g. strong direct sunlight or a vehicle in extremely hot conditions) Do not throw the battery pack into fire 8.2.1 Power supply 15V / 2A...

  • Page 27: Installation

    8.4 Installation Install a charged battery pack in a compatible device. To check the condition of the battery pack, push the test button 1. The indicator is a five segment LED. The first LED (LED1 closest to the test button) is red and indicates a low capacity battery.

  • Page 28: Wireless Conference Access Point (Wcap)

    9 Wireless Conference Access Point (WCAP) 9.1 Introduction All communication to and from the wireless units is controlled by the WCAP. 9.2 Installation 9.2.1 Wall Mounting The WCAP can be mounted on the wall by means of the 2 fixing holes at the bottom side of the device To prevent accident, this device must be securely attached to the wall in accordance with the installation instructions.

  • Page 29: Connections And Controls

    9.3 Connections and Controls 1. Power Switch The WCAP can be switched on/off with the power switch at the back of the WCAP. 2. Power Supply The power supply of the WCAP is provided by a 110 - 230VAC/24VDC adaptor 3.
  • Page 30 Specifications of th ACDC adapter: 24V / 0.625A DC power plug: outer diameter: 5.5mm Inner diameter: 2.1mm Polarity: LED1 LED3 Meaning LED2 White Boot sequence started Blinking red Unitialized golden mode Fixed red Initialized golden Blinking green Unitialized application Fixed Green Initialized application Fixed green Connected with uniCOS...
