WARNING:
THIS GENERATOR IS DESIGNED TO GIVE SAFE AND DEPENDABLE SERVICE WHEN
OPERATED ACCORDING TO THE INSTRUCTIONS IN THE TECHNICAL MANUALS PROVIDED
WITH THE GENERATOR.
WARNING:
DO NOT OPERATE THE GENERATOR BEFORE YOU HAVE READ AND UNDERSTAND THE
INSTRUCTIONS AND THE ENGINE MANUFACTURER'S MANUAL. FAILURE TO DO SO
COULD RESULT IN PERSONAL INJURY OR EQUIPMENT DAMAGE.
1-3 Placards
Placards, shown in Figure 1-1 through Figure 1-8 are attached to the portable generator to warn
operating and maintenance personnel of potential hazards, to provide maintenance information,
and to provide generator ratings and capabilities. The large label below is located on the front
panel of the portable generator. The label presents operational Warnings and Cautions for
generator users.

1-4 SAFETY PRECAUTIONS

WARNING: IN ORDER TO ASSURE SAFE AND EFFICIENT OPERATION OF THE GENERATOR,
OPERATOR'S SHOULD READ AND COMPLY WITH THE FOLLOWING SAFETY PRECAUTIONS.
• Do not operate the generator near gasoline or gaseous fuels because of the potential danger from
explosion or fire. Do not fill the fuel tank with fuel while the engine is running. Do not smoke or use open flame
near the fuel tank. Be careful not to spill fuel during refueling. If fuel is spilled, wipe it off and let it dry before
starting the engine.
• Do not place flammable materials near the generator. Be careful not to place fuel, matches, gunpowder, oily
cloths, straw, trash, or any other combustibles near the generator.
• Do not operate the generator inside a room, cave, tunnel, or other insufficiently ventilated area. Always
operate the generator in a well-ventilated area. The engine may become overheated, and the poisonous carbon
monoxide gas contained in the exhaust gases will endanger human lives.
• Keep the generator at least 1 meter (3 feet) away from any structure or building during use. When a
generator is located close to a building or nearby equipment, heat and exhaust from the engine will cause the
surrounding temperature to rise. This will degrade the engines cooling efficiency, causing overheating.
• Do not enclose the generator nor cover it with a box. The generator has a built-in, forced-air cooling system,
and may become overheated if it is enclosed.
• Operate the generator on a level surface. It is not necessary to prepare a special foundation for the generator.
However, the generator will vibrate on an irregular surface. Therefore, choose a level place without surface
irregularities.
• Shutoff the generator when moving the generator to another work site. It the generator is tilted or moved
during operation, fuel may spill and/or the generator may tip over, causing a hazardous situation. Proper
lubrication cannot be expected if the generator is operated on a steep incline or slope. In such a case, the piston
may seize; it may seize even if the oil is above the upper level.
• Do not operate in rain or with wet hands. The operator may suffer severe electric shock, if the generator is wet
due to rain or snow. If wet, dry before starting. Do not pour water directly over the generator, nor wash it with water.
• Do not connect the generator to a commercial power line. Connection to a commercial power line may result
in short circuit and damage the generator. When connecting to domestic circuits, install only approved transfer
switches and make sure power and control circuitry meet local electrical code requirements.
• Do not smoke or use other smoking materials (pipes, cigars, etc.) while handling the battery. The battery
emits flammable hydrogen gas, which can explode if exposed to electrical arcing or open flame. Keep the work
area well ventilated and keep the battery away from open flames/sparks.
Introduction
Tsurumi's Operation, Service, and Repair Manual
3

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TPG4-3000HDX and is the answer not in the manual?

Questions and answers

Related Manuals for Tsurumi Pump TPG4-3000HDX

Summary of Contents for Tsurumi Pump TPG4-3000HDX

  • Page 1: Safety Precautions

    Tsurumi’s Operation, Service, and Repair Manual WARNING: THIS GENERATOR IS DESIGNED TO GIVE SAFE AND DEPENDABLE SERVICE WHEN OPERATED ACCORDING TO THE INSTRUCTIONS IN THE TECHNICAL MANUALS PROVIDED WITH THE GENERATOR. WARNING: DO NOT OPERATE THE GENERATOR BEFORE YOU HAVE READ AND UNDERSTAND THE INSTRUCTIONS AND THE ENGINE MANUFACTURER’S MANUAL.

  • Page 2: Air Cleaner Maintenance

    Tsurumi’s Operation, Service, and Repair Manual Figure 1-2: Electrical Warning TSURUMI PORTABLE GENERATOR Figure 1-4: Fuel Handling Warning MODEL TPG4-3000HDX MAX. OUTPUT 2.6kVA RATED OUTPUT 2.2kVA VOLTAGE 120V TPG4 Fig. 1-2 FREQUENCY 60Hz ＊＊＊＊＊＊ SERIAL NO. MADE IN JAPAN TPG4 Fig. 1-1 ■CHECK FOR SPILLED FUEL OR FUEL LEAKS.

  • Page 3: Operating Controls

    PILOT light, circuit BREAKER(s), a ground (or earth) post, and electrical receptacles. The specific controls used in each model are shown in Figures 3-1 through 3-4. NOTE: The auto throttle feature is not available on Model TPG4-3000HDX, which uses a hand operated throttle lever. The Model TPG4-7000H-DXE generator is equipped with a electric starter motor.
  • Page 4 Tsurumi’s Operation, Service, and Repair Manual Pilot Circuit breaker Receptacle 120/240V lamp GFCI switch Voltage selector Idle control switch Circuit breaker VOLTAGE SELECTOR CIRCUIT BREAKER TEST START PILOT ＯＦＦ ＯＮ ＯＮ GFCI 120V/240V 120V ON LY AT 120/240V CIRCUIT BREAKER IDLE CONTROL S W .

  • Page 5: Grounding Provisions

    Tsurumi’s Operation, Service, and Repair Manual Grounding Provisions WARNING: TO PREVENT ELECTRICAL SHOCK FROM FAULTY APPLIANCES, THE PORTABLE GENERATOR SHOULD BE GROUNDED. CONNECT A LENGTH OF HEAVY WIRE BETWEEN THE GENERATOR’S GROUND TERMINAL AND EXTERNAL GROUND SOURCE. WARNING: CONNECTIONS FOR STANDBY POWER TO A BUILDING’S ELECTRICAL SYSTEM MUST BE MADE BY A QUALIFIED ELECTRICIAN AND MUST COMPLY WITH ALL APPLICABLE LAWS AND ELECTRICAL CODES.

  • Page 6: Check Engine Fuel

    FUEL LEVEL INDICATOR RESPONDS TO FLOAT LEVEL TANK EMPTY TANK FULL (FLOAT LOW) (FLOAT HIGH) TPG4 FIG 3-7 Figure 3-7: Fuel Gauge Indications Fuel tank capacity TPG4-3000HDX (4.2 gal.) TPG4-4500HDX (6.6 gal.) TPG4-6000HDX (6.6 gal.) TPG4-7000HDX (6.6 gal.) TPG4-7000HDXE (6.6 gal.)

  • Page 7: Pre-Start Checks

    Pre-Start Checks WARNING: MAKE SURE YOU REVIEW EACH WARNING IN ORDER TO PREVENT FIRE HAZARD. WARNING: KEEP AREA CLEAR OF FLAMMABLES OR OTHER HAZARDOUS MATERIALS. Check the following items before starting the engine. Fuel leakage from fuel hoses, shutoff valve, auto-throttle unit, engine, and fitttingd Loose bolts and nuts.

  • Page 8: Starting And Stopping The Engine

    Starting & Stopping the Engine MANUAL START: (Models TPG4-3000HDX, TPG4-4500HDX, TPG4-6000HDX, and TPG7-7000HDX. Before starting the engine, set AC circuit breakers to OFF (the generator may be hard to start if a load is connected. Refer to the Honda engine owner’s manual for location of fuel valve. Turn the fuel valve to the ON position.

  • Page 9: Using The Generator

    As the engine warms up, gradually open the choke ring. Set auto throttle switch to ON. The engine idle function is enabled and will remain at idle until a load is sensed and increases speed in response to the load. (ALL MODELS): When starting the engine using recoil starter, proceed as follows:.
  • Page 10 Single Voltage Type Check the pilot lamp for proper voltage. NOTE: The generator is thoroughly tested and adjusted in the factory. If the generator does not produce the specific voltage, consult your nearest Tsurumi Generator dealer Set switches on the electrical appliances to OFF before connecting to the generator. (10) Insert the plug of the electrical appliance into the appropriate receptacle.
  • Page 11 Dual Voltage Type Select the voltage using the FULL POWER switch in accordance with the electrical appliance. Refer to Table 3-2. (12) Operate the generator in the same way as step (1) through step (3) of single voltage type. Table 3-2: Available Receptacles With Full Power Switch On Switch Setting Lower Voltage Receptacle Higher Voltage Receptacle...

  • Page 12: Stopping The Generator

    3-12 Stopping the Generator Set the ENGINE SWITCH to OFF or unplug from the cord receptacle of the generator. Set the engine switch to the OFF position. Turn fuel valve on fuel tank to CLOSE. Figure 3-8: Fuel Valve 3-13 Oil Alert The oil alert detects the fall in oil level in the crankcase and automatically stops the engine when the oil level falls down below the predetermined level.

  • Page 13: Ground Fault Circuit Interrupter (Gfci)

    3-17 Ground Fault Circuit Interrupter (GFCI) WARNING: USING THE GENERATOR IN RAIN, SNOW OR NEAR WATER CAN LEAD TO DEATH FROM ELECTRIC SHOCK. KEEP THE GENERATOR DRY. All receptacles on the generator are protected by a ground fault circuit interrupter (GFCI) for protection against the shock hazard of ground fault current.
  • Page 14 Inspection: (Models TPG4-4500HDX, TPG4-6000HDX, TPG4-7000HDX and TPG4-7000HDXE) NOTE: ALWAYS CHECK GFCI OPERATION BEFORE USING THE GENERATOR. WARNING: YOU RISK ELECTRIC SHOCK IF YOU OPERATE THIS GENERATOR WITH A FAULTY GFCI(GROUND FAULT CIRCUIT INTERRUPTER). TEST GFCI BEFORE USE. If the GFCI FAILS TESTING, DO NOT USE YOUR GENERATOR. CONTACT YOUR TSURUMI DEALER.
