  • Page 1 Universal Battery Charger II Instructions for Use...

  • Page 3: Table Of Contents

    • Battery Power Line and Colibri/SBD batteries • Battery Power Line II and Colibri II / SBD II batteries 13 • Trauma Recon System power module Storing Batteries Slot Covers Set Universal Battery Charger II Instructions for Use DePuy Synthes...
  • Page 4 • Power module for Trauma Recon System • Batteries for Colibri/Small Battery Drive • Battery for Colibri II/Small Battery Drive II Explanation of Symbols Used Symbols for Operating the Charger Symbols on the Charger Ordering Information DePuy Synthes Universal Battery Charger II Instructions for Use...

  • Page 5: General Information

    Battery Power Line handpieces (530.605, 530.610, 530.615). Precaution: The battery for the Power Drive (530.200) cannot be charged with the UBC II. Please use the UBC item number 530.600 or 530.601. Universal Battery Charger II Instructions for Use DePuy Synthes...

  • Page 6: Safety Precautions

    Before operating the device, visually inspect the device for damage and wear. If it is not in perfect working order, contact the Synthes representative. Do not use a damaged or faulty device. DePuy Synthes Universal Battery Charger II Instructions for Use...

  • Page 7: Scope Of Delivery

    Precautions: Storage and transport • Only use the Synthes Universal Battery Charger II All batteries / power modules should be removed for (05.001.204) to charge the batteries. Using a char- transporting the charger. ger that does not originate from Synthes can dam- age the battery.

  • Page 8: Front View

    3 ON/OFF blue LED 4 Control symbols for each charging bay 5 Ventilation holes Rear view 6 Ventilation holes 7 Power switch 8 Fuses: 225 AT/250 V 9 Power cord connection DePuy Synthes Universal Battery Charger II Instructions for Use...

  • Page 9: Starting The System

    Fig. 2 • Only connect to a power supply with grounding, a rated voltage between 100 V and 240 V and a network frequency range of 50 or 60 Hz. Fig. 3 Universal Battery Charger II Instructions for Use DePuy Synthes...

  • Page 10: Charging The Battery

    1 Battery Power Line and Battery Power Line II batteries (530.620, 530.630) 2 Trauma Recon System Power Module (05.001.202) 3 Colibri / SBD and Colibri II / SBD II batteries (532.003, 532.033, 532.103) Fig. 1 DePuy Synthes Universal Battery Charger II Instructions for Use...

  • Page 11: Charging The Battery

    • Do not insert any objects other than batteries into the charger, as the contacts may otherwise be damaged. Universal Battery Charger II Instructions for Use DePuy Synthes...

  • Page 12: Temperature Monitoring

    • Do not charge mechanically damaged batteries in the charger. • Only charge batteries authorized for the device (see page 32). • Only use fully charged batteries to avoid delays during surgery. DePuy Synthes Universal Battery Charger II Instructions for Use...

  • Page 13: Checking And Refreshing Batteries

    To refresh and check the battery, press the but- ton with the exclamation mark for at least 2 seconds (fig. 1) until the symbol lights up yellow (fig. 2). The device then carries out the process. The symbol yellow throughout this time. Universal Battery Charger II Instructions for Use DePuy Synthes...
  • Page 14 • The process is interrupted if there is a power cut Fig. 4 or a switch to the emergency power supply and will then have to be restarted. DePuy Synthes Universal Battery Charger II Instructions for Use...

  • Page 15: Battery Power Line Ii And Colibri Ii / Sbd Ii Batteries

    Fig. 5 yellow. To check the battery, press the button with the exclamation mark for at least 2 seconds (fig. 5) until the symbol lights up yellow (fig. 6). The device then carries out the process. The symbol is yellow through- out this time. Fig. 6 Universal Battery Charger II Instructions for Use DePuy Synthes...
  • Page 16 • The process is interrupted if there is a power cut or a switch to the emergency power supply and Fig. 8 will then have to be restarted. DePuy Synthes Universal Battery Charger II Instructions for Use...

  • Page 17: Trauma Recon System Power Module

    • If the check is not carried out within the next 3 charging cycles, the charger starts this process automatically. The symbol is yellow (fig. 11). • It takes around 4 hours to check the power module. Fig. 11 Universal Battery Charger II Instructions for Use DePuy Synthes...

  • Page 18: Storing Batteries

    A partial charge may not be suffi- cient for the intended use. • Unusable or faulty batteries/power modules should not be used. They should be disposed of (see sec- tion “Disposal” on page 20). DePuy Synthes Universal Battery Charger II Instructions for Use...

  • Page 19: Slot Covers Set

    Universal Battery Charger II because it covers the unused slots of the charger (fi g. 2). Therefore, it prevents to insert the appropriate battery or power module into the wrong slot. Fig. 1 Fig. 2 Universal Battery Charger II Instructions for Use DePuy Synthes...

  • Page 20: Cleaning

    • Device must not be sterilized. • Make sure that no solution enters the device. • If necessary, clean the contacts in the charger bays using utmost care. DePuy Synthes Universal Battery Charger II Instructions for Use...

  • Page 21: Repair And Technical Service

    The same applies if the ON/OFF blue LED does not light up or flashes when the device is switched on. To prevent damage during shipping use the original packaging to return devices back to Synthes. If this is not possible, please contact the Synthes representative. Users or third parties should not carry out repairs them- selves.

  • Page 22: Disposal

    Only return Trauma Recon System power module (05.001.202) to the Synthes representative, observing the applicable instructions for use. DePuy Synthes Universal Battery Charger II Instructions for Use...
  • Page 23 Check firmware version on the sticker, which is visible on the under- side of the charger and compare with the minimum required firmware listed on page 25. Send the charger to Synthes re presentative for a soft- ware update. Universal Battery Charger II Instructions for Use DePuy Synthes...
  • Page 24 Auto- heat source. matic cooling is on full power. DePuy Synthes Universal Battery Charger II Instructions for Use...
  • Page 25 Battery/power module fell on the floor. Replace battery/power module. Please also observe the instructions for use of the corresponding Power Tools. If the recommended solutions do not work, please contact your Synthes representative. Universal Battery Charger II Instructions for Use DePuy Synthes...

  • Page 26: Device Specifications

    Mains rated input 250 W Protection class I, EN/IEC 60601-1 Protection type by casing IPX0, EN/IEC 60601-1 Fuses 225 AT/250 V Operating mode Continuous operating mode Sterilization Device must not be sterilized Subject to technical modifications DePuy Synthes Universal Battery Charger II Instructions for Use...

  • Page 27: Minimum Required Firmware Version Of Ubc Ii

    Battery Power Line II 530.630 (14.8 V, Li-Ion) 14.0 (sticker visible on the underside of the charger*) *Sticker as shown on the underside of the charger with SW-Rev.14.0 Firmware version 14.0 2012/12/10 Universal Battery Charger II Instructions for Use DePuy Synthes...

  • Page 28: Environmental Conditions

    *Products have been tested according to ISTA 2A Precaution: The device is not suitable for use in the presence of a flammable anesthetics mixture with air or oxygen or with nitrous oxide. DePuy Synthes Universal Battery Charger II Instructions for Use...

  • Page 29: Applicable Standards

    Collateral Standard: Electromagnetic disturbances – Requirements and tests: IEC 60601-1-2 (2014) (Ed 4.0), EN 60601-1-2 (2015) Medical electrical equipment – Part 1–6: Collateral Standard: Usability: IEC 60601-1-6 (2010) (Ed. 3.0) + A1 (2010) Universal Battery Charger II Instructions for Use DePuy Synthes...

  • Page 30: Electromagnetic Compatibility

    Electromagnetic Compatibility Table 1: Emissions Guidelines and manufacturer’s declaration – electromagnetic emissions The Synthes Universal Battery Charger II is intended for use in the electromagnetic environment specified below. The customer or the user of the Synthes Universal Battery Charger II should assure that it is used in such an environment. Emission tests Compliance Electromagnetic environment – guidance...
  • Page 31 Table 2: Immunity (all devices) Guidelines and manufacturer’s declaration – electromagnetic immunity The Synthes Universal Battery Charger II is intended for use in the electromagnetic environment specified below. The customer or the user of the Synthes Universal Battery Charger II should assure that it is used in such an envi- ronment. IEC 60601 Compliance Electromagnetic environment – guidance...
  • Page 32 RF compliance level above, the Synthes Universal Battery Charger II should be observed to verify normal operation. If abnormal performance is observed, additional measures may be necessary, such as re-orienting or relocating the Synthes Universal Battery Charger II.
  • Page 33 Synthes Universal Battery Charger II The Synthes Universal Battery Charger II is intended for use in the electromagnetic environment in which radiated RF disturbances are controlled. The customer or the user of the Synthes Universal Battery Charger II can help prevent...

  • Page 34: Permissible Battery Types

    Typical charging time <60 min Power module for Trauma Recon System Art. no. 05.001.202 Operating voltage (rated) 25.2 V Battery capacity 1.2 Ah/30.24 Wh Battery Li-Ion Typical charging time <60 min Subject to technical modifications DePuy Synthes Universal Battery Charger II Instructions for Use...

  • Page 35: Batteries For Colibri/Small Battery Drive

    Li-Ion Typical charging time <60 min Precaution: The battery for the Power Drive (530.200) cannot be charged with the UBC II. Please use the UBC item number 530.600 or 530.601. Subject to technical modifications Universal Battery Charger II Instructions for Use DePuy Synthes...

  • Page 36: Symbols For Operating The Charger

    Symbol for Battery Power Line and Battery Power Line II batteries (530.620, 530.630) Symbol for Trauma Recon System power module (05.001.202) Symbol for Colibri/SBD and Colibri II/SBD II batteries (532.003, 532.033, 532.103) DePuy Synthes Universal Battery Charger II Instructions for Use...

  • Page 37: Symbols On The Charger

    The device meets the requirements of directive 93/42/EEC for medical devices. It is authorized by an independent named site for which it bears the CE symbol. Environment-friendly use period according to China RoHS. Universal Battery Charger II Instructions for Use DePuy Synthes...
  • Page 38 Power Cord, three-pole (China) 05.001.145 Power Cord, three-pole (Japan) 05.001.146 Power Cord, three-pole (Argentina) 05.001.147 Power Cord, three-pole (Israel) Slot Covers Set 05.001.228 Slot Covers Set, for Universal Battery Charger II DePuy Synthes Universal Battery Charger II Instructions for Use...
  • Page 40 This publication is not intended for distribution in the USA. For full user instructions and precautions please consult the Switzerland Tel: +41 61 965 61 11 product IFU. Please contact your DePuy Synthes sales Fax: +41 61 965 66 00 representative for more information. All surgical techniques 0123 are available as PDF files at www.depuysynthes.com/ifu...
