Wen 61720 User Manual

18-gauge 2-inch brad nailer
Hide thumbs Also See for 61720:

Advertisement

Quick Links

Your new tool has been engineered and manufactured to WEN's highest standards for dependability,
ease of operation, and operator safety. When properly cared for, this product will supply you years
of rugged, trouble-free performance. Pay close attention to the rules for safe operation, warnings,
and cautions. If you use your tool properly and for intended purpose, you will enjoy years of safe,
reliable service.
18-GAUGE 2-INCH
BRAD NAILER
IMPORTANT:
NEED HELP? CONTACT US!
Have product questions? Need technical support?
Please feel free to contact us at:
800-232-1195
techsupport@wenproducts.com
WENPRODUCTS.COM
Model # 61720
bit.ly/wenvideo
(M-F 8AM-5PM CST)

Advertisement

loading
Need help?

Need help?

Do you have a question about the 61720 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Wen 61720

Summary of Contents for Wen 61720

  • Page 1 IMPORTANT: Your new tool has been engineered and manufactured to WEN’s highest standards for dependability, ease of operation, and operator safety. When properly cared for, this product will supply you years of rugged, trouble-free performance. Pay close attention to the rules for safe operation, warnings, and cautions.

  • Page 2: Table Of Contents

    Know Your Nailer Operation Maintenance Troubleshooting Exploded View Parts List Warranty TECHNICAL DATA Model Number: 61720 Operating Pressure Range: 60 psi - 100 psi Air Inlet: 1/4˝ NPT Nail Size Range: 3/4˝ - 2˝ Nail Diameter: 18 Gauge Air Consumption: 1.8 CFM...
  • Page 3 SAFETY INTRODUCTION Hello! Thank you for purchasing the WEN Brad Nailer. Safe operation of this pneumatic tool requires that you read and understand this operator’s manual and all labels affixed to the tool. Safety is a combination of common sense, staying alert, and knowing how your tool works.
  • Page 4 SAFETY RULES Safety is a combination of common sense, staying alert and knowing how your item works. SAVE THESE SAFETY INSTRUCTIONS. WARNING: To avoid mistakes and serious injury, do not use your tool until the following steps have been read and understood 1.
  • Page 5 SAFETY RULES 13. USE ONLY clean dry and regulated air. Condensation from an air compressor can rust and damage the internal workings of the tool. 14. DO NOT USE BOTTLED GASES to power this tool. Bottled compressed gases including but not limited to oxygen, carbon dioxide, nitrogen, hydrogen, propane, acetylene or air are not for use with pneumatic tools.
  • Page 6 SAFETY RULES 28. KEEP FACE AND BODY PARTS away from the back of the tool cap when working in restricted areas. Sudden recoil can result in impact to the body, especially when nailing into hard or dense material. 29. DO NOT DRIVE FASTENERS near the edge of your work material. The workpiece may split, causing the fastener to ricochet, injuring you or a bystander.

  • Page 7: Know Your Nailer

    KNOW YOUR NAILER 1- Jam-Clearing Latch 2- Contact Trip 3- Low Nail Indicator Window 4- Magazine 5- Air Inlet 6- Trigger 7- Exhaust 8- Depth Adjustment Wheel   OPERATION WARNING - if any parts are missing, do not operate this tool until the missing parts are replaced. Failure to do so could result in a possibly serious personal injury.
  • Page 8 OPERATION LOADING THE FASTENERS CAUTION: Always connect the nailer to the air supply before load- ing fasteners. Otherwise a misfire may occur. 1. Depress the lock to release the movable magazine and pull the magazine out fully. 2. Place a full clip of the specified type and size fasteners on the fixed magazine.  ...

  • Page 9: Maintenance

    8. Make sure the trigger and contact trip move freely without sticking or binding. 9. Load the magazine. 10. Reattach nailer to air supply. NOTE: If nails continue to jam in the nosepiece, have your tool serviced by an authorized WEN service center. MAINTENANCE CLEAN AND INSPECT DAILY CAUTION - Disconnect tool from air supply before performing any maintenance.

  • Page 10: Troubleshooting

    TROUBLESHOOTING CAUTION: Stop using the tool immediately if any of the following problems occur or risk serious personal injury. Repairs and replacements should only be performed by authorized personnel at a certified WEN service center. Problem Common Causes Solution Air leaking at Trigger area 1.

  • Page 11: Exploded View

    EXPLODED VIEW  ...

  • Page 12: Parts List

    PARTS LIST Item Stock # Description Item Stock # Description 61720-001 SCREW 61720-037 O-RING 15×1.9 61720-002 BUSHING 61720-038 TRIGGER VALVE GUIDE 61720-003 EXHAUST COVER 61720-039 TRIGGER SPRING 61720-004 SEAL 61720-040 SPRING PIN 61720-005 SCREW 61720-041 RAIL 61720-006 SPRING WASHER 61720-042...

  • Page 13: Warranty

    LIMITED ONE YEAR WARRANTY WEN Products is committed to building tools that are dependable for years. Our warranties are consistent with this commitment and our dedication to quality. LIMITED WARRANTY OF WEN CONSUMER POWER TOOLS PRODUCTS FOR HOME USE GREAT LAKES TECHNOLOGIES, LLC (“Seller”) warrants to the original purchaser only, that all WEN con- sumer power tools will be free from defects in material or workmanship for a period of one (1) year from date of purchase.
