Chapter 2: Installation and Wiring
Ambient Conditions
Ambient Temperature Range
Storage Temperature Range
Relative Humidity
Altitude
Pollution Degree
Vibration Resistance
Shock Resistance
IP Rating
Installation Considerations
Improper installation of the controller will greatly reduce its life. Be sure to
observe the following precautions when selecting a mounting location:
Warning: Failure to observe these precautions may damage the controller and void
the warranty!
• Do not mount the controller near heat-radiating elements or in direct
sunlight.
• Do not install the controller in a place subjected to high temperature, high
humidity, excessive vibration, corrosive gases or liquids, or airborne dust or
metallic particles.
• Do not restrict the air flow to the vent opening on the controller housing
•
This controller is an open-type unit and must be placed in an enclosure to ensure
proper operation and maintain the IP65 rating.
2–2
SOLO Temperature Controller User Manual
Ambient Conditions
32°F to 122°F (0°C to 50°C)
-4°F to 149°F (-20°C to 65°C)
35% to 80% (non-condensing)
2000m or lower above sea level,
keep from corrosive gas, liquid and dust
Degree 2 - Normally, only non-conductive pollution occurs.
Temporary conductivity caused by condensation is to be expected
2
10 to 55 Hz, 10 m/s
for 10 min, each in X, Y and Z directions
2
Max. 300 m/s
, 3 times in each 3 axes, 6 directions
IP65: Complete protection against dust and low pressure spraying
water from all directions when mounted in a suitable enclosure.
