ID Parameter Name
P2-8 Alarm 3 High Limit
P2-9 Alarm 3 Low Limit
N/A LED Status
N/A Pushbutton Status
P2-10 Lock Mode
N/A Firmware Version
P2-2 Starting Ramp / Soak
Pattern
P3-21 Last Step Number
P3-22 Additional Cycles
P3-23 Next Pattern Number
P3-19 Ramp / Soak SV
P3-20 Ramp / Soak Time
*Note: The Appendix covers the Modbus address map for the Ramp / Soak Control.
1st Ed. Rev C 07/08
Chapter 7: Modbus Communication
Data Registers cont.
Description
Please refer to the contents of
the "Alarm Outputs" for
details.
Please refer to the contents of
the "Alarm Outputs" for
details.
Bit 0 = ALM3
Bit 1 = ALM2
Bit 2 = °F
Bit 3 = °C
Bit 4 = ALM1
Bit 5 = OUT2
Bit 6 = OUT1
Bit 7 = AT
Bit 0 = SET
Bit 1 = Rotate
Bit 2 = Up
Bit 3 = Down
If the button is pressed, the
bit is off.
0 = OFF
1 = Lock Mode 1
11 - Lock Mode 2
V1.00 indicates 0x100
0 - 7
0 - 7 = The last step number
of the pattern
0 - 199
0 - 7 = Next pattern number
8 = There is no next pattern.
-999 - 9999
0 - 1500 (15 hours 0
minutes)
SOLO Temperature Controller User Manual
R/ Hexadecima Modbus
W l Decimal
R/W 1028 44137
R/W 1029 44138
R 102A 44139
R 102B 44140
R/W 102C 44141
R 102F 44144
R/W 1030 44145
R/W 1040~ 44161~
1047* 44168*
R/W 1050~ 44177~
1057* 44184*
R/W 1060~ 44193~
1067* 44200*
R/W 2000~ 48193~
203F* 48256*
R/W 2080~ 48321~
20BF* 48384*
PLC
Address
(Octal)
V10050
V10051
V10052
V10053
V10054
V10057
V10060
V10100~
V10107*
V10120~
V10127*
V10140~
V10147*
V20000~
V20077*
V20200~
V20277*
