Owner’s Manual / 使 用手冊 Operating and Servicing Instructions / 操作及維修手冊 Model No. 型號 hoover.com.hk HC-AM-HKA HC-AM-HKB IMPORTANT: READ CAREFULLY BEFORE ASSEMBLY AND USE. 重要提示:在裝配及使用前請仔細閱讀本手冊。 THIS PRODUCT IS INTENDED FOR HOUSEHOLD USE ONLY. IF USED COMMERCIALLY WARRANTY IS VOID. 本產品只適用於家庭使用。如果用於商業用途保用無效。...
Thank you for choosing a HOOVER product. ® Please enter the complete model and Manufacturing Code in the spaces provided. Model V13408001xxyy00001 HU-AS-H KA MFG. Code Hint: Attach your sales receipt to this owner’s manual. Verification of date of purchase may be required for...
IMPORTANT SAFETY INSTRUCTIONS SAVE THESE INSTRUCTIONS When using an electrical appliance, basic precautions should always be followed, including the following: READ ALL INSTRUCTIONS BEFORE USING THIS APPLIANCE. WARNING: TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK OR INJURY: • Fully assemble before operating. •...
Page 4
CAUTION: TO REDUCE THE RISK OF DAMAGE: • Avoid picking up hard, sharp objects with this product, as they may cause damage. • Store appropriately indoors in a dry place. Do not expose machine to freezing temperatures. • Do not use sharp objects to clean out hose as they can cause damage. •...
1. Cleaner asseMBlY CartOn COntents A. Canister B. Dirt Cup (Packaged Attached To Canister) C. Hose Assembly D. Telescoping Extension Wand E. Combination Floorhead F. Upholstery tool (available on selected models) G. Low profile floorhead (available on selected models) H. Dusting brush I.
2. getting started PLEASE READ SAFETY INFORMATION BEFORE USE: Before plugging the cord into the electrical outlet, make sure the switch is in the ‘off’ position. Hold the vacuum cleaner firmly when starting and in use. Assembling your canister Plug in and switch the Insert the end of the Slot the metal telescopic Fully unwind the power...
3. hOw tO use Operation Carpets Hard Floors To vary the suction power For use on carpets click open/close the sliders on rocker switch forward. For the hose handle. use on hard floors click rocker switch back. Use low profile floorhead or upholstery tool to get around under and around furniture.
Familiarize yourself with these home maintenance tasks as proper use and care of your cleaner will ensure continued cleaning effectiveness. Any other servicing should be done by a Hoover authorized distributor/service center. If appliance is not working as it should, has been dropped, damaged, left outdoors, or dropped into water, take it to a service center prior to continuing use.
CYClOne separatOr WARNING To reduce the risk of personal injury - Unplug vacuum before cleaning or servicing. Do not use vacuum without dirt cup or filters in place. how to Clean Remove dirt cup as described in Fig. 3.1. 3.3 To remove inner shroud, hold the dirt cup and rotate the shroud clockwise. 3.4 Hold the dirt cup and turn the separator counter-clockwise.
filter Made with hepa Media 3.10 3.11 WARNING To reduce the risk of personal injury - Unplug vacuum before cleaning or servicing. Do not use vacuum without dirt cup or filters in place. when to Clean It is recommended that the Filter Made With HEPA 3.12 3.13 Media be checked and cleaned at least every 2...
5. trOuBleshOOting If a minor problem occurs, it usually can be solved quite easily when the cause is found by using the checklist below. Any other servicing should be done by an authorized service representative. If appliance is not working as it should, has been dropped, damaged, left outdoors, or dropped into water, take it to a service center prior to continuing use.
7. Other infOrMatiOn Contact and Service Please refer to the last page for the contact of our distributor. Consumables To purchase spares and accessories, please visit www.hoover.com.hk or contact our authorized distributor. Contact information on the last page. Technical Specification Voltage:...
1. 組裝吸塵器 包裝盒內容 A. 吸塵器 B. 集塵桶 (裝在吸塵器中) C. 軟管 D. 伸縮管 E. 地板吸頭 F. 傢俱吸頭 (適用於特定型號) G. 地板專用吸頭 (適用於特定型號) H. 除塵刷 I. 縫隙吸頭 J. 寵物工具 (適用於特定型號) K. 工具收納夾 將所有組件從包裝盒中取出,識別每一個出現 的項目。 確定已取出所有組件再棄置包裝。 吸塵器描述 1. 可洗式濾網蓋 2. 上限線 3. 集塵桶 4. 旋風式分離器 (位於集塵桶內部) 5.
