1.3 Configuration Commands

This chapter describes the power sourcing equipment (PSE) configuration commands and is divided into the follow-
ing sections:

• Viewing the PSE configuration prompt.

• PSE configuration commands.
1.4 Viewing the PSE configuration prompt
To access the configuration environment, do the following:
(1) At the GESTCON (*) prompt, enter PROCESS 4 (or P 4) or CONFIG.
(2) At the configuration prompt (Config>), enter NETWORK <interface_name> (interface_name is the name of
the Ethernet interface on which the PSE functionality can be used).
(3) To set specific POE parameters, use the available commands from the PSE configuration menu described in
this chapter. To access the menu corresponding to the specific parameters, enter the POWER-
SOURCING-EQUIPMENT command once inside the interface configuration.
*config
Config>net ethernet0/0
-- Ethernet Interface User Configuration –
ethernet0/0 config>?
description
input-buffers
ip
ip-encapsulation
list
llc
mac-address
no
power-sourcing-equipment
repeater
shutdown
update
exit
ethernet0/0 config>power-sourcing-equipment
-- Power Sourcing Equipment configuration --
ethernet0/0 PSE config>
Certain commands are common to all device interfaces. These commands are described in the manual on common
configuration interfaces (Teldat-Dm772-I Common Configuration Interfaces).

1.5 Configuring PSE

This section describes the PSE configuration commands.
Command
? (HELP)
AVAILABLE-POWER
DEFAULT-
PORT-CONSUMPTION
ENABLE
LIST
NO
PORT
TRACE
PoE Power over Ethernet
Detection error (Strength: High or Low).
Enter interface description
Number of rx buffers
Interface Internet Protocol config commands
IP transport mode in the ethernet frame
Displays the current configuration
Displays the LLC configuration prompt
Adopt locally administered addresses
Access to the Power Sourcing Equipment configuration
Access to the repeater configuration
Change state to administratively down
Update a level indicator
Function
Allows you to view the available commands, as well as the available options within
a command.
Configures the available power value.
Configures the default power consumption value for each connected port.
Enables power sourcing equipment.
Lists the interface options configuration.
Sets the default of a particular option.
Configures each port individually.
Enables tracing.
