Ports Status
Status of each port. The list of available states is as follows:
Port Status
Adm. auto
Adm. disabled
Adm. force <n> mW
Detect Unknown
Detect Short Circuit
Detect Signature Resistance
Low
Detect Signature Resistance
High
Detect Good
Detect Open Circuit
Disabled
Power forced, applied <n> mW
Unavailable
The list of detected classes is as follows:
Class
0
1
2
3
4
5

2.3.5 MODE-PORT

Changes the operating mode of the ports.
Syntax:
ethernet0/0 PSE+mode-port <port number> <mode> <assigned power>
<port number>
<5..8> Value in the specified range
all All ports
<mode>
auto
default
force-power
<power assigned>
<4500..15400>
PoE Power over Ethernet
The port mode has been set as auto with the mode-port auto monitoring com-
mand.
The port has been disabled with the disable-port monitoring command. This com-
mand overrides the current configuration.
The port mode has been forced to deliver the specified power. This has been en-
abled with the mode-port force-power monitoring command.
The port is in auto mode. Detection has not completed.
The port is in auto mode. A short circuit was detected during the detection pro-
cess.
The port is in auto mode. The detection process has revealed that the resistance
presented by the device is below that specified in the IEEE.802.3af norm (below
15K).
The port is in auto mode. The detection process has revealed that the resistance
presented by the device is above that specified in the IEEE.802.3af norm (above
33K).
The port is in auto mode. The device class has been correctly detected as shown.
The port is in auto mode. No device has been detected.
The port is disabled and will not deliver power.
Power is unconditionally applied to the port as shown, except when a short circuit
is detected.
The port cannot be managed because the device is unavailable. This can happen
when there is no power.
Power delivered by default: 15400 mW.
Default class for devices that do not implement detection.
"Low Power PD" devices
Power delivered by default: 4000 mW.
"Medium Power PD" devices
Power delivered by default: 7000 mW.
"High or Full Power PD" devices
Power delivered by default: 15400 mW.
Reserved. Power is delivered as for class 0.
Reserved. Power is delivered as for class 0.
auto mode
set default mode
force power
milliWatts
