1 Configuration

1.5.7 PORT

Allows you to activate the forced power mode functionality on each port. This way, and unless a short circuit is detec-
ted, ports always receive power supply.
You should also configure the maximum power allocated to the connected device.
This command also allows you to permanently power off a port.
The port is configured in normal power mode by default.
Syntax:
ethernet0/0 PSE config>port <port number> <mode> <power assigned>
<port number>
<1..16>
all
<mode>
disable
force-power
<power assigned>
<4500..15400>
To configure port 3 in forced power mode and assign it 7600mw.
Example 1:
ethernet0/0 PSE config>port 3 force-power 7600
To configure all ports in forced power mode and assign 7600mw to each port.
Example 2:
ethernet0/0 PSE config>port all force-power 7000
To disable the forced power configuration on port 3.
Example 3:
ethernet0/0 PSE config>no port 3 force-power
To disable the forced power configuration on all ports.
Example 4:
ethernet0/0 PSE config>no port all force-power
History:
Release
11.00.06
11.01.01

1.5.8 TRACE

Use this command to selectively enable debugging traces. Traces are generated as ETH.055 events.
Syntax:
ethernet0/0 PSE config>trace {all | <subsystem>}
Example:
ethernet0/0 PSE config>trace all
History:
Release
11.00.04
11.01.00
6
Port number
All ports
Power off
Force power
milliWatts
Modification
The disable option was introduced.
Modification
This command was introduced.
Teldat SA
PoE Power over Ethernet
