SERVICE
WARNING:
The muffler on this
product contains chemicals known to the
State of California to cause cancer.
We recommend all service and adjustments
not listed in this manual be performed by an
an authorized service dealer.
CARBURETOR ADJUSTMENTS
Your carburetor is equipped with limiter caps.
Adjusting the carburetor is a complicated
task. We recommend that you take your unit
to an an authorized service dealer. Damage
will occur if you turn the needles beyond the
limiter stops.
TROUBLESHOOTING TABLE
WARNING:
Always stop unit and disconnect spark plug before performing any of the
recommended remedies below other than remedies that require operation of the unit.
TROUBLE CAUSE
Engine will not S Engine flooded.
S Fuel tank empty.
start.
S Spark plug not firing.
S Fuel not reaching carburetor.
S Carburetor requires adjustment.
Engine will not S Carburetor requires adjustment.
S Throttle trigger screw too
idle properly.
tight.
Engine will not S Air filter dirty.
S Spark plug fouled.
accelerate,
S Carburetor requires adjustment.
lacks power,
or dies under
a load.
Engine S Fuel mixture incorrect.
smokes
S Air filter dirty.
excessively.
S Carburetor requires adjustment.
Line does not
S Line improperly routed in head.
advance or S Line improperly wound on
spool.
breaks while
S Line size incorrect.
cutting.
Line welds S Line size incorrect.
S Incorrect spool.
onto spool.
S Line is being crowded against
material being cut.
Line pulls S Too little line outside of head.
back into
S Line size incorrect.
head.
IGNITION TIMING
The ignition timing is fixed, non--adjustable.
SPARK PLUG
Replace the spark plug yearly using a
Champion RCJ--7Y plug. Spark plug gap is
0.025".

NEED ASSISTANCE?

Need Assistance?
Call 1--800--554--6723
Need Service Part?
Contact your dealer.
REMEDY
S See "Starting."
S Fill tank with correct fuel mixture.
S Install new spark plug.
S Check for dirty fuel filter; replace.
Check for kinked or split fuel line;
repair or replace.
S See "Carburetor Adjustments."
S See "Carburetor Adjustments."
S Loosen screw.
S Clean or replace air filter.
S Clean or replace spark plug; re-gap.
S See "Carburetor Adjustments."
S Empty fuel tank and refill with
correct fuel mixture.
S Clean or replace air filter.
S See "Carburetor Adjustments."
S Check line routing.
S Rewind line tightly and evenly.
S Use only 0.080" (2 mm) dia. line.
S Use only 0.080" (2 mm) dia. line.
S Replace with correct spool.
S Cut with tip of line fully extended.
S Remove spool and pull 4 inches
(10 cm) of line outside of head.
S Use only 0.080" (2 mm) dia. line.
