Meter Description

1. LCD Display
2. HOLD/
3. MODE/
4. SET Button
5. AC adaptor jack
6. Tripod mount (detachable probe also has a
Tripod mount)
7. Probe connection
8. (Power) Button
9. MAX-MIN/
10. UNIT Button
11. Down Arrow /
12. Inlet/Outlet ports for tubing
13. Detachable Probe
14. Probe LED indicators
Note
: Battery compartment located on back of the meter. A tripod mounting port is available on
the back of the external probe.
800.561.8187
Up Arrow Button
Left Arrow Button
Right arrow
Backlight Button
