Using Navios Software
Analysis Menu

Rectangular Region Properties

Region Name
Prime
Automatic Region Name Positioning
Region statistics exported for QC
QC Product
X and Y Coordinate
Minimum Count
Linked Region
NOTE
You cannot make any changes on this screen when
running a
product or choosing to export QC statistics.
X and Y Coordinate
Set the region to defined position by entering X and lower Y coordinates for the region.

Interactive Rectangular Region Editing

When a Region's position is changed, any Gates and statistics that use the Region are automatically
updated and each plot is redrawn to reflect the changes in the Gate. When the Region is deleted, any
Gate or statistics that used the Region are also automatically deleted. When a Gate has been deleted,
any plot, which used the deleted Gate, is reset to Ungated. Navios software allows resizing of
previously created Regions.

Quadrant Region

Insert a Quadrant Region into a dual parameter plot. All quadrants comprise four sets of Rectangular
shaped polygonal Regions on a dual parameter plot. The Quadrants are automatically assigned an
alphabetical region name and a number for each quadrant. Quadrant regions have flexquad
capabilities allowing adjustment of the dividers between FlexQuad quadrants 1 and 2 and between
quadrants 2 and 4. See also:
10-128
locked protocol other than selecting a
Quadrant Region
QC
and Repositioning a Quadrant Region.
773232AH
