Minimum Count

Check this option and enter a number in the
overrides an existing stop count to ensure a minimum number of events within a particular region
are collected. The actual stop count in this case is approximate (but is always in excess of the
minimum count value). This is limited by the Duration and Total Events.

Linked Region

Select a region to be linked to another region and the region tracks the selected region. A region
may only link to a region of the same type and parameters. For dual parameter regions, the
parameters may be transposed. A polygonal region may link to a quadrant region/FlexQuad region,
but a quadrant region/FlexQuad region may not link to a polygonal region.
When a region is linked to another, changes to either region's coordinates (by dragging the region)
are propagated to both regions. The exception is when the region is an auto analysis region
(positives analysis, Elliptical and Contour AutoGate). Then the regions track the auto analysis region
and the link is unidirectional.
If a region is linked to another, positives analysis and autogating are disabled for that region.

Polygonal Region Format Tab

Specify the
Region boundary.
NOTE
You cannot make any changes on this screen when
running a

Interactive Polygonal Region Editing

When a Region's position is changed, any Gates and statistics that use the Region are automatically
updated and each plot is redrawn to reflect the changes in that Region. When the Region is deleted,
any Gate or statistics that used the Region are also automatically deleted. When a Gate has been
deleted, any plot that used the deleted gate is reset to Ungated. Navios software allows you to resize
an already created Region.

Rectangular Region

This option draws a Rectangular Region on a dual parameter plot. See also:
773232AH
Color Weight
and line for the Polygonal
locked protocol.
Count field to enable the minimum count function. This
Using Navios Software
Analysis Menu
Rectangular Region.
