SPECIFICATIONS
SUPPLY VOLTAGE.......................
CONTROL VOLTAGE...................
MOTOR....................................
OPERATOR OUTPUT SPEED.........
WEIGHT (net)..............................
STANDARD WIRING TYPE............... C2 momentary contact to open and stop and constant pressure to close.
4
GENERAL
115, 230 VAC single phase 208, 460, 575 VAC three phase
24VAC class 2 transformer, 2 amp fuse type ACG
Continuous duty 1/2, 3/4, 1 & 1.5 Horsepower
103.5 RPM
126 lbs (approx), 56.8 kg
DIMENSIONS
(MGT)
