Capricorn LAB-TE02 Instruction Manual page 27

Step 26.0
- Rear Suspension -
7
1 Cap2107A
2 Cap23031
3 Cap2107B
4 Cap22102
Made in Italy
26
5
6
10
Parts List
Ball Joint 4.9mm Open
Turnbuckle 3x25mm
Ball Joint 4.9mm Closed
4.9mm Ball End Long Alu
Capricorn RC
1
8
9
5 Cap18024
6 Cap23010
7 Cap22018
8 Cap22017
9 Cap17006
10 Cap23016
2 3
4
Length 13.9mm
Parts List
3x14 round head screw
4.9mm Ball End Open
3x6x4mm Alu Shims
3x6x3mm Alu Shims
3x3 screw set
Pivot Pin Rear-Out
