Instruction Manual rel. 1.1

Advertisement

loading
Need help?

Need help?

Do you have a question about the LAB-TE02 and is the answer not in the manual?

Questions and answers

Related Manuals for Capricorn LAB-TE02

Summary of Contents for Capricorn LAB-TE02

  • Page 1 Instruction Manual rel. 1.1...
  • Page 2 Capricorn RC Step 1.0 - Front Transmission - Step 1 Step 2 Step 2 Step 1 Parts List Parts List Cap17030 3x6 round head screw Cap17015 2x9.8mm Pin (2pcs) Cap23001 Spool Outdrive(2pcs) Front Spool Pulley Cap2102A 38T kevlar 10x15x4mm Cap18018...
  • Page 3 Capricorn RC Step 2.0 - Rear Transmission - Step 1 Step 2 Parts List Parts List Eccentric Hub ergal Cap2102E Rear Diff Case kevlar Cap20011 (2pcs) Cap23025 Gear Diff Shims Set Cap21110 Diff Gears (with Axle) Gear Diff Outdrive Alu...
  • Page 4 Capricorn RC Step 3.0 - Rear Transmission - Step 1 Step 2 Parts List Cap21110 Diff Gears (with Axle) Parts List Cap23024 Gear Diff Shim Set Cap170520 O'ring 5x2 soft (1pcs) Cap17015 2x9.8mm Pin (1pcs) Cap2102E Rear Diff Case kevlar...
  • Page 5 Capricorn RC Step 4.0 - Rear Transmission - Fill differential up to the top of the pins with silicon oil. Initial Setting 1.000 with stock motor 1.500 with modified motor Diff case direction needs to match as below. Made in Italy...
  • Page 6 Capricorn RC Step 5.0 - Rear Transmission - Parts List Cap18018 10X15mm Ball Bearing (2pcs) Cap17022 2.5x8 flat head screw Cap20011 Eccentric Hub ergal (2pcs) Made in Italy...
  • Page 7 Capricorn RC Step 6.0 - Shock Damper - Apply Oil before assembly Apply Oil before assembly Parts List Cap30100 Shock Low Cap Cap30101 Cap Shim Cap30109 Quad-ring Cap29162 Shock ADJ Nut Alu Cap30102 Shock Body Cap30103 Shock Shaft Tin Cap30110 Shock Piston Big Bore 3 Hole 1.1...
  • Page 8 Capricorn RC Step 7.0 - Shock Damper - Silicon Oil #500 12.5mm Fill the oil to shock body till full Made in Italy...
  • Page 9 Capricorn RC Step 8.0 - Shock Spring - Parts List Shock uniball mount Cap14036 + spring retainer Parts List Cap29172 Front Shock Spring 0.30 Yellow Shock absorber Cap29173 Rear Shock Spring 0.28 Green Cap29148-6 members 5.8mm Ball End ergal hard...
  • Page 10 Capricorn RC Step 9.0 - Main Transmission- Step 3 Step 1 Step 2 Step 3 Parts List Parts List Cap22004 Spur Axle Alu Cap29112 Spur gear 112T Cap2102C 19T Belt Pulley kevlar Cap18021 3x4 round head screw Cap25502 C-Clip (2pcs)
  • Page 11 Capricorn RC Step 10.0 - Main Chassis - Notice: Use CA Glue to seal the chassis edge Parts List Cap20009B Bulkhead Alu FL/RR Cap20010B Bulkhead Alu FR/RL Cap30104 Chassis 2.25mm Cap17031 3x8 Flat Head Screw Made in Italy...
  • Page 12 Capricorn RC Step 11.0 - Rear Bulkhead - Parts List Parts List Cap29012 Rear Separate Bracket Cap20010B Bulkhead Alu FR/RL Cap22021 Shims 1mm Cap20009B Bulkhead Alu FL/RR Cap17031 Cap17029 Screw 3x6 Flat Head Screw 3x8 Flat Head Made in Italy...
  • Page 13 Capricorn RC Step 12.0 - Transmission - Parts List Parts List Cap24050RB Front Belt 510-3mm Cap22506K Motor Mount Cap24051RB Rear Belt 3mm Cap22506K Motor Mount Cap17023 Cap17029 Screw 3x6 Flat Head Screw 3x10 Bottom Head Cap22506C Motor Mount column 8 Cap17021...
  • Page 14 Capricorn RC Step 13.0 - Front Bulkhead - Parts List Parts List Cap22503 Bulkhead Upper Alu FL/RR Low Profile Front Shock Cap29145 Tower Cap22504 Bulkhead Upper Alu FR/RL Cap17032 Cap17031 3x8 flat head screw 3x8 round head screw Made in Italy...
  • Page 15 Capricorn RC Step 14.0 - Rear Shock Tower - Parts List Parts List Cap22503 Bulkhead Upper Alu FL/RR Low Profile Rear Shock Cap29146 Tower Cap22504 Bulkhead Upper Alu FR/RL Cap17032 Cap17031 3x8 flat head screw 3x8 round head screw Made in Italy...
  • Page 16 Capricorn RC Step 15.0 - Front Suspension Bracket - Parts List Front split Cap29011 suspension bracket Cap22021 Shims 1mm Steering Shaft Cap23006 (2pcs) 3x6 flat head Cap17029 screw(6pcs) Separate suspension bracket Front Cut point Inside=#1 Suspension Bracket (Defalut Setup) Cut point Outside=#2 Suspension Bracket...
  • Page 17 Capricorn RC Step 16.0 - Turnbuckle - Length 24mm Length 8.5mm Parts List Parts List Cap17032 3x8 round head screw(2pcs) Cap22101 4.9mm Ball End Med Alu Cap27501 Adjust Steering Plate Cap22100 4.9mm Ball End Short Alu 5X8X2.5mm Cap16019 Ball Bearing(4pcs)
  • Page 18 Capricorn RC Step 17.0 - Steering Rack - Cap27052-8 8±0,03 Cap27052-8.5 8,5±0,03 Cap27052-9 9±0,03 Cap27052-9.5 9,5±0,03 Cap27052-10 10±0,03 Cap27052-10.5 10,5±0,03 Parts List Plastic Servo Horn Cap21060P Dual Steering Arm 11±0,03 Cap27052-11 Cap27052-8.5 Ackerman Plate8.5 3X6X3mm Cap22017 Alu Shims (2pcs) Made in Italy...
  • Page 19 Capricorn RC Step 18.0 - Steering Rack - Parts List Cap17030 3x6 round head screw Made in Italy...
  • Page 20 Capricorn RC Step 19.0 - Front Arm - Please fix the plastic shim Front lower arms have 4 different shock positions. thickness thinner if suspension Make sure left and right sides are both symmetrical during assembly. arm moving not free.
  • Page 21 Capricorn RC Step 20.0 - Front Arm - Please fix the plastic shim thickness thinner if suspension arm moving not free. Parts List Parts List Cap17008 3x8 screw set Cap18022 3x10 screw set Cap23008 Ball 5mm(2pcs) Cap22514 Suspension Alu Bracket #2...
  • Page 22 Capricorn RC Step 21.0 - Rear Arm - Rear lower arms have 6 different 39.5mm 35.1mm 30.7mm 30.7mm 35.1mm 39.5mm positions for shocks and anti-roll bars. Make sure left and right sides are symmetrical during assembly. 40.5mm 36.1mm 31.7mm 31.7mm 36.1mm...
  • Page 23 Capricorn RC Step 22.0 - Rear Arm - Parts List Parts List Cap17008 3x8 screw set Cap18022 3x10 screw set Cap23008 Ball 5mm(2pcs) Cap22516 Suspension Alu Bracket #3 Cap30107 Low Arm Rear 30% Cap23022 Roll Center Shim 1.0mm Cap23014 Cap17031...
  • Page 24 Capricorn RC Step 23.0 - Rear CVD - Step 3 Step 2 Step 1 Apply slight amount of anti wear grease. Parts List Cap27001 CVD G-Clip Cap23002 Wheel Axle(pcs) Parts List Cap17015 2x9.8mm Pin Cap23005 CVD Insert Cap21030 C cap2 3.5mm...
  • Page 25 Capricorn RC Step 24.0 - D.J CVD - Step 3 Step 2 Step 1 Step 4 Apply slight amount of anti wear grease. Parts List Cap27001 CVD G-Clip Parts List D.J CVD Cap23101 Front Wheel Shaft Cap418 5x10x4mm Ball Bearing (2pcs) Cap26105 1.5x8mm Pin...
  • Page 26 Capricorn RC Step 25.0 - Steering Block - RIGHT SIDE LEFT SIDE Parts List Cap23007 Steering Block Bushing(4pcs) Cap21080 C-Hub 4 Right -Left Cap17032 3x8 round head screw Made in Italy...
  • Page 27 Capricorn RC Step 26.0 - Rear Suspension - Length 13.9mm Parts List Cap18024 3x14 round head screw Parts List Cap23010 4.9mm Ball End Open Cap2107A Ball Joint 4.9mm Open Cap22018 3x6x4mm Alu Shims Cap22017 Cap23031 Turnbuckle 3x25mm 3x6x3mm Alu Shims...
  • Page 28 Capricorn RC Step 27.0 - Steering Block - Parts List Parts List Cap18024 3x14 round head screw Cap23015 Pivot Pin Front-Out Cap22018 3x6x4mm Alu Shims Cap23010 4.9mm Ball End Open Cap17006 3x3 screw set Cap17023 3x10 round head screw Made in Italy...
  • Page 29 Capricorn RC Step 28.0 - Anti Roll Bar - Parts List Cap2013 3x6x2.5 Flanged Cap17006 3x3 screw Cap20006 Anti-Roll Bar Holder Anti-Roll Bar Rear Cap27013 1.2mm (Black) Cap17006 3x3 screw set Made in Italy Initial Setup Initial Setup...
  • Page 30 Capricorn RC Step 29.0 - Anti Roll Bar - Parts List Cap2013 3x6x2.5 Flanged Cap17006 3x3 screw Cap20006 Anti-Roll Bar Holder Anti-Roll Bar Front Cap27012 1.4mm (Black) Cap17006 3x3 screw set Made in Italy Initial Setup Initial Setup...
  • Page 31 Capricorn RC Step 30.0 - Upper Deck - Parts List Cap17030 3x6 round head screw Cap30105 Upper Deck 2mm Cap29006 Belt Tensioner Made in Italy...
  • Page 32 Capricorn RC Step 31.0 - Bumper - Parts List Parts List Cap17040 Nylon Nut M3 Cap17030 3x6 round head screw Cap17027 3x10 flat head screw(5pcs) Cap21049 Carbon Upper Bumper Plate Cap15011B Front Body Column Cap21051 Bumper Column Cap21050 Plastic Bumper Plate...
  • Page 33 Capricorn RC Step 32.0 - Bumper - Parts List Parts List Cap15011B Front Body Column Cap24010 Bumper Foam Cap17016 2x11.8mm Pin Cap17032 3x8 round head screw Cap27002 R-Clip Made in Italy...

  • Page 34: Cap17030 3X6 Round Head Screw

    Capricorn RC Step 33.0 - Shock & Body Tower - Parts List Cap15012B Rear Body Column Parts List Cap17016 2x11.8mm Pin Cap17030 3x6 round head screw Cap17023 3x10 round head screw Made in Italy...
  • Page 35 Capricorn RC Step 34.0 - Shock & Servo - It is recommended to use servo mount rubber. Not Included Parts List Cap17030 3x6 round head screw Parts List Cap17029 3x6 flat head screw Flex floating servo plate Cap17032 3x8 round head screw...
  • Page 36 Capricorn RC Step 35.0 - Floating Servo Mount - 10° Parts List Cap17029 3x6 flat head screw Cap17030 3x6 round head screw Cap21060P Plastic Servo Horn Dual Steering Arm Made in Italy...
  • Page 37 Capricorn RC Step 36.0 - Motor - Gear mesh should have a minimal amount of play between spur and pinion. A gear mesh that is too tight will put extra strain on the spur gear. Brushless Motor Motor Pinion 64DP...

  • Page 38: Cap17040 Nylon Nut M3

    Capricorn RC Step 37.0 - Botter Holder - Use a small file to shape the battery holder edge. Parts List Parts List Cap2101A Antenna Mount Set Cap17040 Nylon nut M3 Cap17029 3x6 Flat head screw Cap22110F/R Low Arm F/R Set with Shims...
  • Page 39 Capricorn RC Step 38.0 - Electronical Accessory - Fiber Tabe Not Included Use glass fiber tape attached to the battery Parts List mount plate to secure the battery. Cap14001 Antenna (3set) Made in Italy...
  • Page 40 Capricorn RC Step 39.0 - Battery - Battery location can be adjusted by moving the battery holder. It can be used to adjust weight distribution. Battery Not Included Made in Italy...
