Foreword
Dear Customer,
Congratulations on becoming the proud owner of a "CT 100", one of the most value for money
motorcycles in the country.
Your safety and the safety of others is extremely important. Hence, before you ride the bike,
please read this Owner's Manual carefully and familiarize yourself with the operating mechanism,
controls and maintenance requirements. This will ensure you a long and trouble free ownership
experience.
To keep your bike in perfect running condition and deliver consistent performance, we have
specially programmed the periodic maintenance services which includes 3 Free and subsequent
Paid services. We earnestly advise you to avail all these services at any of our Vehicle Dealers or
Authorised Service Centers as per the schedule contained in this booklet
Your "CT 100" comes with a warranty of 2 Years or 30,000 Kms. whichever occurs earlier from
the date of sale. For details please refer to "Warranty: Scope & Limits" given in this manual.
We urge you to entrust all your service needs to a Bajaj Dealer or Authorised Service Centers
only. They are well equipped with all necessary facilities / genuine parts / oil and trained
manpower will ensure the best care for your bike.
Should you require any additional information or wish to convey any grievance you may contact
us on our toll free no. / e-mail mentioned on front cover inner page of this manual.
Thank you for choosing a Bajaj "CT 100" & wish you unlimited miles of happy riding!!
SERVICE DEPARTMENT
BAJAJ AUTO LIMITED
Advertisement
Table of Contents
Related Manuals for Bajaj Auto CT 100
Summary of Contents for Bajaj Auto CT 100
- Page 1 Foreword Dear Customer, Congratulations on becoming the proud owner of a “CT 100”, one of the most value for money motorcycles in the country. Your safety and the safety of others is extremely important. Hence, before you ride the bike, please read this Owner's Manual carefully and familiarize yourself with the operating mechanism, controls and maintenance requirements.
-
Page 2: Table Of Contents
15. Periodic Maintenance Information..... 20 type described and illustrated herein remaining 16. Free Service Guidelines........23 unaltered. Bajaj Auto Limited reserves the 17. Periodic Maintenance & Lubrication Chart..24 right to carry out at any moment without 18. Non Use Maintenance........29 being obliged to bring this booklet upto-date 19. -
Page 3: Technical Specifications
Technical Specifications Engine : 4 stroke, Natural air Front Brake : Drum Brake cooled. Rear Brake : Drum Brake Bore x Stroke : 53 mm x 45 mm Fuel Tank Capacity : CT100 CT100B Eng. Displacement : 99.27 cc Full : 10.5 liters 10 liters Compression Ration : 9.5 +/- 0.5 :1... - Page 4 Technical Specifications Tyre Size (Front) : 2.75 X 17”, 41 P Neutral Indicator Lamp : 3W Turn Signal Indicator : 3W (Rear) : 3.00 X 17”, 50 P Hi-Beam Indicator Lamp : 3W Tyre Pressure : 3W x 2 nos. Speedometer Lamp : 1.75 kg/cm (25 PSI) Front...
-
Page 5: Identification Data
Identification Data- (Frame Number & Engine Number) The Frame and Engine serial numbers are used to register the motorcycle. They are the unique alpha-numeric codes to identify your particular vehicle from others of the same model and type. Frame Number Location On LH Side of Steering Tube (Alpha-Numeric - 17 Digits) Engine Number Location... -
Page 6: Location Of Parts
Location of Parts EVAP compatible Fuel Tank Grab Handle Rear Shock Speedometer absorber Brake Lever Kick Lever Tail Lamp Silencer Engine Oil Level Window Brake Pedal... -
Page 7: Steering Cum Ignition Lock
Steering cum Ignition Lock Steering cum Ignition Lock : To Lock the Steering : To lock the steering, turn the handle bar to the left or right. Push It has three positions. the key inside & turn toward ‘LOCK’ position. Match the lock position &... -
Page 8: Fuel Tank Cap / Fuel Tap
Fuel Tank Cap & Fuel Tap Fuel Tap Fuel Tank Fuel Tank Cap Fuel Tap • To open the fuel tank cap, insert the key Fuel tap lever has following positions. in the lock and turn it clockwise and lift : When fuel level is above Reserve fuel tank cap. -
Page 9: Speedometer Details
Speedometer Details indicator will glow. 5. Turn Signal Indicator (LH & RH) : When Turn signal switch is turned to Left or Right, Turn pilot indicator will flash. AHO Feature AHO (Automatic Headlight ON) feature is provided. There is no ‘Light switch’ on RH control switch. -
Page 10: Control Switches
Control Switch LH Control Switch LH C. Turn Signal Switch : When the turn signal switch is turned to Left ( ) or Right ( ), the corresponding turn signals A. Hi/Low beam switch flash on and off. To stop flashing, turn the knob to center position. -
Page 11: Removal & Fitment Of Side Cover
Removal of Side Covers Side Side Cover Cover Removal of Side Cover LH & RH • Similarly ‘Side cover’ RH can be removed after removing screw (D). • Insert the key into the cover lock (C) and turn the key clockwise & pull the ‘Side cover’... - Page 12 Fitment of Side Covers Side Side Cover Cover Fitment of Side Cover LH & RH • For ‘Side cover’ RH fitment, adopt the same procedure and fit the screw (D) • Match slot (B) provided on rear side of properly. ‘Side Cover’...
-
Page 13: Location Of Battery / Tool Kit / First Aid Kit
Location of Battery / Tool Kit / First Aid Kit Battery Tool Kit First Aid Battery Tool Kit Location • It is located inside ‘Side Cover’ LH near • It is located inside the ‘Side Cover’ LH. battery. • Always maintain electrolyte level in each •... -
Page 14: Daily Safety Checks
Daily Safety Checks Before riding motorcycle be sure to check • Rear brake pedal free play- 20 to 30 mm. following items. Please give proper importance • Wear lining Indicator within usable range. to these checks and perform all of them No brake dragging, applicable to drum before riding motorcycle. -
Page 15: How To Ride Your Bike
How to Ride Your Bike Starting The Engine : Note : Before starting the engine, in ignition key off condition, press the clutch lever & • Turn the fuel tap knob to ‘ ’ or ‘ ’ position. operate kick lever all the way down for 5-6 •... - Page 16 How to Ride Your Bike Shifting Gears : • Close throttle & depress the clutch. • Shift into next higher or lower gear. • Open the throttle and release the clutch lever slowly and simultaneously. Gear Shifting Pattern Gear Shifting Lever Braking : •...
- Page 17 How to Ride Your Bike Stopping the Vehicle : Running IN • Close the throttle completely. Proper running-in is important for the better life & trouble free performance of the vehicle. • Shift the transmission into neutral. • During first 2000 kms running-in period do •...
- Page 18 How to Ride Your Bike Optimum shifting speeds for best mileage Fuel Saving Tips : 1st gear : 0 Km/hr A well maintained vehicle and good driving 2nd gear : 14 ~ 17 Km/hr can contribute a lot to the saving of petrol. 3rd gear : 22 ~ 25 Km/hr Following are a few simple fuel saving tips.
-
Page 19: Safe Riding Tips
Safe Riding Tips Safe Riding Tips • Drive cautiously. Start early & reach your destination safely. • Always wear Helmet while driving or riding. Your helmet should conform to appropriate Indian • Always carry vehicle registration & insurance papers, standards. and a valid driving licence with you. -
Page 20: Engine Oil
Engine Oil A : Oil Filler Cap Recommended Engine Oil: B : Oil Level Gauge Always insist on Bajaj Genuine Engine Oil C : Upper Level for optimum engine performance and to D : Lower Level avail warranty benefits. It is a specially formulated oil for Bajaj motorcycles. -
Page 21: Wheels - Tyre
& for better fuel consumption. Front 25 PSI Rear (Solo) 28 PSI CT 100 Alloy Wheel Spoke Wheel Rear (with Pillion) 32 PSI Ensure no damage to wheel rim while Note : Incase the motorcycle is fitted with removing tyre for puncture &... -
Page 22: Periodic Maintenance Information
Periodic Maintenance Information-Battery CAUTION : Tap water is not a substitute for distilled water and will shorten the life of the battery. • When battery is found discharged, it is advised to get it charged immediately. • Environment care must be taken to dispose off used battery. - Page 23 Periodic Maintenance Information- Spark Plug, Drive Chain Top edge 0.7 to 0.8 mm Std. Chain slackness : 20~30 mm Spark Plug Drive Chain Slackness • Remove spark plug by using plug spanner. • Chain top edge to be kept between the •...
- Page 24 Periodic Maintenance Information- Drive Chain Lubrication Drive Chain Cleaning Drive Chain Lubrication Drive chain must be cleaned & lubricated as per periodic maintenance schedule. Drive Chain (Non sealed type ) • Non sealed type chain should be removed & cleaned by Nylon brush & Kerosene / diesel in chain cleaning stand.
-
Page 25: Free Service Guidelines
Free Service Guidelines Customer ID : Instruction to avail Free Service through Periodic Service Criteria Digitized Free Service Coupon Please follow following procedure : - Service Days • Please provide your mobile number to Dealer 1st Free at the time of buying of new Bajaj Vehicle. 30~45 500~750 Service... -
Page 26: Periodic Maintenance & Lubrication Chart
Periodic Maintenance & Lubrication Chart RECOMMENDED FREQUENCY Servicing 1 Free 2 Free 3 Free Operation Subsequent Every 4500 9500 5000 Km after Previous Service 5000 10000 Water wash & dry the vehicle Ensure to prevent water ... - Page 27 Periodic Maintenance & Lubrication Chart RECOMMENDED FREQUENCY Servicing 1 Free 2 Free 3 Free Operation Subsequent Every 4500 9500 5000 Km after Previous Service 5000 10000 Air filter cover ‘O’ ring CL,R 10. In line paper filter 11. Fuel cock paper filter. 12.
- Page 28 Periodic Maintenance & Lubrication Chart RECOMMENDED FREQUENCY Servicing 1 Free 2 Free 3 Free Operation Subsequent Every 4500 9500 5000 Km after Previous Service 5000 10000 20. Silencer tail pipe cleaning** 21. Brake cam & brake pedal pivot pin C,L,R C,L,R C,L,R C,L,R C,L,R C,L,R C,L,R Use AP grease.
- Page 29 Periodic Maintenance & Lubrication Chart RECOMMENDED FREQUENCY Servicing 1 Free 2 Free 3 Free Operation Subsequent Every 4500 9500 5000 Km after Previous Service 5000 10000 29. Handle bar control switches C,CL C,CL C,CL C,CL C,CL C,CL C,CL C,CL Use WD40 spray contacts cleaning 30.
- Page 30 Periodic Maintenance & Lubrication Chart RECOMMENDED FREQUENCY Servicing 1 Free 2 Free 3 Free Operation Subsequent Every 4500 9500 5000 Km after Previous Service 5000 10000 38. Coolant level in expansion tank** Use recommended 'Ready to use coolant'. 39. Coolant hose damage/clamps/leakage** 40.
-
Page 31: Non Use Maintenance
Non-Use Maintenance Non-use maintenance is necessary if a vehicle wheels. remains off road for a longer duration (more • Do not apply oil on front brake disc, to than 15 days**). The correct and careful non- prevent rusting. If the front brake disc rusts use maintenance carried out before storing during storage, do not attempt to clean it the vehicle will prevent the vehicle from... -
Page 33: Delivery Certificate
Delivery Certificate Customer's Signature (To be filled in by the dealer) Imp - "Do not detach this page from Owner's Manual"... -
Page 34: Warranty Scope & Limit
“CT 100” motorcycle manufactured by them. such claims. Bajaj Auto Limited undertake no liability in the matter of Every possible care and precaution has been taken to consequential loss or damage caused due to the failure of ensure quality in respect of the material &... - Page 35 Warranty : Scope & Limit to remove and despatch the part / parts attributing to Part C : the manufacturing defect to the Company. Further this warranty is NOT applicable to : b. Produces the Owner's Manual, in original, to enable 1.
- Page 36 Bajaj changes in design or to add any improvements on the Auto Limited, if in the sole judgement of Bajaj Auto vehicle at any time without incurring any obligation to Limited, such use prematurely affects the install the same on a vehicle previously supplied and performance and reliability of the vehicle.
-
Page 37: Battery Warranty Card
BATTERY WARRANTY CARD MAKE OF BATTERY : ......MFG. CODE OF BATTERY : BATTERY SR. NO.: BATTERY CHARGING DATE : TYPE OF BATTERY : VEHICLE SALE DATE : NAME OF OWNER AND ADDRESS : TYPE OF VEHICLE : REG. NO.: FRAME NO.: ENGINE NO.: SERVICE RECORD... - Page 38 TO BE FILLED IN BY BATTERY DEALERS / DISTRIBUTORS IN CASE OF CLAIM Name of Dealer & Code :____________________________________________________________________ ____________________________________________________________________________________________ Date of claim :________________________________________________Battery Type :_________________ Serial No. :__________________________________________________Date of Fitment :________________ Failure Mode (Please tick as applicable) • Loose connection •...
