NAVIGATION
Service setup 2 (contd.)
contd. from previous page
contd. on next page
15 MAR 2001 REV C
AUTOMATION
NAV interface protocol
0FF
= interface disabled
4
H5C
= NMEA sentence HSC
bod
= NMEA sentence BOD (+ XTE)
APA
6
= NMEA sentence APA
APb
= NMEA sentence APB
Ct5
= NMEA sentence CTS
PCt
= NMEA sentence PCT
bPi
= NMEA sentence BPI (+ XTE)
bur
= NMEA sentence BWR (+ XTE)
buc
= NMEA sentence BWC (+ XTE)
1n5
1
= INS data 1 (general)
1n5
2
= INS data 2 (chart plotter NAVIPLOT)
1n5
3
= INS data 3 (NACOS)
1n5
4
= INS data 4 (VECTOR)
1n5
5
= INS data 5 (DB 2000)
1n5
6
= INS data 6 (INS 970)
1n5
7
= INS data 7 (VMS)
5Er
u
= for service only
gyrocompass interface format
0FF
= interface disabled
4
6
= 6 step/°
12
= 12 step/° / synchro 1:360
P96
6
= Plath-format 9600 baud
L96
= Lehmkuhl 9600 baud
L12
= Lehmkuhl 1200 baud
183
= NMEA 0183
Nt
= compass monitor NAVITWIN
magnetic compass interface format
0FF
= interface disabled
4
5in Co5
= fluxgate sensor, sin/cos type
183
= NMEA 0183
tE5
t
6
= for service only
speed interface format
0FF
= interface disabled
4
200 M
P
= 200 p./nm
183
= NMEA 0183
6
056300 8-151
NAVIPILOT V HSC
Quick Reference Guide
Page 9 of 12
