Service setup 2 (contd.)
contd. from previous page
1
15 MAR 2001 REV C
AUTOMATION
scale factor of rudder angle feedback unit
4
50 mV/° - 300 mV/°
6
function ext. status input
0FF
= input disabled
4
tur
n
= turn 180° port/stbd.
180
°
= turn hdg. display 180°
5tE
P
6
= alter set hdg. port/stbd. (tiller or pushbuttons)
L0Ad = select load state
switchover mode gyro/magnetic
1nt M
4
1nt ALL
Port
6
In service setup: quit service setup immediately and return to normal operational mode
= internal, from control master only
= internal, from all operating units
= external
