Docomo SH-01A User Manual page 26

1Earpiece
Listen to the other party's voice.
Listen to Record message/Voice memo.
2Brightness sensor (nP. 107)
The sensor detects the light of the surrounding area and
automatically adjusts the display brightness and turns on/off the
keypad backlight.
Do not cover the sensor area with your hand or a sticker. May
interfere with the sensor.
3Main display (nP. 28)
4Optical TOUCH CRUISER , (;) (nP. 34)
Slide the finger to perform the same operations as those for w
of Multi-guide key.
Use the FOMA terminal as a fingerprint sensor to authenticate
Fingerprint ID (nP. 117).
5i-mode/Operation guidance key i (,)
Press to use i-mode (nP. 168).
Press to execute the functions of the operation guidance (nP. 27).
Press for 1+ seconds to display the i-appli software list screen
(nP. 269).
6Mail/Operation guidance key m
Press to use mail functions (nP. 136).
Press to execute the functions of the operation guidance
(nP. 27).
Press twice to check new messages (nP. 146).
Press for 1+ seconds to display a compose message screen
(nP. 136).
7Start/Hands-free key s
Press to make or receive a voice call.
Press to use Hands-free (nP. 53, P. 77).
8Dial/Text entry keys 1 to 9, 0, *, #
Press to enter a phone number or text.
Press * for 1+ seconds to enable/disable the Public mode
(Drive mode) (nP. 67).
Press # for 1+ seconds to enable/disable the Manner mode
(nP. 101).
Press 1 to 3 for 1+ seconds to use assigned functions
(nP. 390).
Press 5 for 1+ seconds to set font size collectively (nP. 113).
Press 6 for 1+ seconds to turn on/off the Bluetooth power
(nP. 404).
Press 7 for 1+ seconds to record Voice memos or play Voice
memos/Recorded messages (nP. 71, P. 394).
Press 8 for 1+ seconds to start to use 2in1 or switch modes
(nP. 429, P. 430).
Press 9 for 1+ seconds to reset Kisekae Tool settings or Font
style setting (nP. 108, P. 113).
9Multi/GPS/Quick search key $
Press to use Quick search (nP. 391).
Press to use Multi Assistant (nP. 380).
Press for 1+ seconds to check your present location (nP. 308).
aMouthpiece/Microphone
Sends out your own voice.
bSub camera
Use to shoot still pictures of yourself.
Use to send images of yourself during a Videophone call.
cMulti-guide key wt
Move the cursor to select an item and execute or set (nP. 27).
Press to display Menu, Redial list screen, Received calls list
screen, i-Widget screen and Shortcut menu.
Press t for 1+ seconds to use Lock selection (nP. 124).
Press r for 1+ seconds to to show the Sent messages history
(nP. 155).
Press q for 1+ seconds to to show the Received messages
history (nP. 155).
Press u for 1+ seconds to adjust the earpiece volume
(nP. 98).
dCamera/Operation guidance key C
Press to activate the camera (nP. 214).
Press to execute the functions of the operation guidance
(nP. 27).
Press for 1+ seconds to display Data box (nP. 324).
Continued on next page
25
