Summary of Contents for Suunto ELEMENTUM TERRA

  • Page 1 SUUNTO ELEMENTUM TERRA USER GUIDE...
  • Page 3 CHRONOGRAPH / DATE SETTINGS MEMORY ALTITUDE TIME RECORDING COMPASS CALIBRATION...
  • Page 5 _Cumulative asc./desc. _Log: last 8 asc./desc., max. altitude GETTING STARTED Thank you for choosing Suunto Elementum Terra, a digital sports watch for mountaineering and outdoor activities. To get started: 1. Press any button to activate the watch. 2. Keep [A] pressed to enter .
  • Page 6 SETTINGS 1. In mode, keep [A] pressed to enter/exit time settings 2. Rotate [A] to change the values. 3. Press [A] to accept. 4. Press [B] or [C] or keep [A] pressed to exit. TIME/ALTITUDE RECORDING Press [B] to switch between mode.
  • Page 7 MEMORY 1. In mode, rotate [A] downwards to enter time memory 2. Rotate [A] upwards/downwards to browse the logs. 3. Press [A] to switch between the first and second view of the log. 4. Press [B] or [C] to exit. BACKLIGHT Keep [B] pressed to activate the backlight.
  • Page 8: Table Of Contents

    2 Using Suunto Elementum Terra ........
  • Page 9 Exclusions and Limitations ......... 27 Access to Suunto warranty service ....... . . 28 Other important notices .
  • Page 10: Getting Started

    TIME ALTITUDE RECORDING mode includes altitude measuring and recording functions. view helps you to orient yourself in relation to magnetic North. COMPASS Change the settings of your Suunto Elementum Terra in . View altitude SETTINGS logs in MEMORY 1.1 Changing general settings To change the general settings: 1.
  • Page 11: Using Alarm

    TIP: You can exit at any time by pressing [B] or [C] or keeping [A] SETTINGS pressed. You can change the following general settings on your Suunto Elementum Terra: ● altitude reference value ● alarm: on/off ● alarm time: hours and minutes ●...
  • Page 12: Using Button Lock

    When the alarm goes off, press any button to turn it off. The alarm goes off the same time the following day. 1.3 Using button lock The button lock can be activated in mode. TIME ALTITUDE RECORDING To activate the button lock: 1.
  • Page 13 NOTE: If you want to use the backlight in , activate it before MEMORY SETTINGS entering them. NOTE: Heavy use of the backlight significantly reduces battery life. To save power, the backlight blinks when used in view. COMPASS...
  • Page 14: Using Suunto Elementum Terra

    ● time (second row) ● date (bottom row) ● sea level air pressure (outer rim) 2.1.1 Using stopwatch Suunto Elementum Terra features also a stopwatch. To use the stopwatch: 1. In mode, rotate [A] upwards to enter the stopwatch function. TIME 2.
  • Page 15: Altitude Recording Mode

    2.2 Altitude recording mode mode, you can measure and record your cumulative ALTITUDE RECORDING ascent and descent. Press [B] to switch from mode to TIME ALTITUDE RECORDING mode. Rotate [A] to change between positive (+) and negative (-) cumulative altitude readings.
  • Page 16: Recording Altitude

    2.2.1 Recording altitude When you are in mode or record altitude measurements, ALTITUDE RECORDING the watch measures altitude changes at an interval of 1, 5 or 10 seconds (depending on vertical speed). TIP: Use mode to see immediate altitude changes. ALTITUDE RECORDING 2.2.2 Setting reference altitude The altitude reading is based on the measurement of the barometric pressure.
  • Page 17: Measuring Cumulative Ascent/Descent

    TIP: Use the outer rim segment sea level air pressure indicator to set your altitude. 2.2.3 Measuring cumulative ascent/descent To measure your cumulative ascent/descent: 1. Press [A] to start measuring. The icon is shown on the display. 2. Rotate [A] to switch between ascent and descent. 3.
  • Page 18 1. In mode, rotate [A] downwards to enter . The latest altitude TIME MEMORY log is shown first. 2. Rotate [A] downwards to browse the logs from latest to oldest. Rotate [A] upwards to browse the logs from oldest to latest. 3.
  • Page 19: Compass View

    2.3 Compass view view allows you to orient yourself in relation to magnetic North. COMPASS Suunto Elementum Terra has a tilt compensated compass which means that the reading is steady even if the compass is tilted. 1. Activate view from...
  • Page 20 NOTE: Avoid any metal or magnetic fields as they disturb the calibration. The calibration includes two sequences. The sequences follow each other automatically, so read all the instructions before starting the calibration. To calibrate the compass: 1. In view, keep [C] pressed to activate the calibration. COMPASS 2.
  • Page 21 NOTE: The device informs 'FAIL' if the calibration does not succeed. If the calibration fails, re-calibrate the compass. TIP: Buckle the device strap, place the support cushion inside the strap and put it in the package so that the device is level. Perform the calibration on a table, which does not contain metal.
  • Page 22: Measuring Weather

    Suunto Elementum Terra measures constantly the surrounding air pressure (absolute air pressure). Based on this measurement and current altitude, Suunto Elementum Terra calculates the sea level air pressure and presents it graphically in the outer rim of the display. It is more common to interpret sea level air pressure values.
  • Page 23: Forecasting Weather Changes

    Again, if the air pressure is constantly dropping, there is a higher possibility of bad weather. 3.3 Automatically switching between measuring altitude and weather changes Unfortunately, it is not possible to measure weather and altitude changes at the same time, as both cause a change in the surrounding air pressure. Suunto...
  • Page 24: At Constant Altitude

    Elementum Terra senses vertical movement and switches to measuring altitude, when needed. When switching to measuring altitude, the maximum delay for showing the updated altitude value is 59 seconds. When altitude is shown, it is updated with a maximum delay of 10 seconds. The benefit of automatic...
  • Page 25: Moving In Altitude

    NOTE: If you are at a constant altitude and the weather changes very fast, the watch may interpret the air pressure change as movements in altitude and change the altitude value. USER EXAMPLE: WEATHER CHANGE WHILE SLEEPING You slept overnight at camp and the weather in the morning is worse than yesterday evening.
  • Page 26 The measuring interval is 1, 5 or 10 seconds (depending on vertical speed). The sea level air pressure value stays steady and the altitude reading changes according to your vertical movement. NOTE: The barometric trend arrow flattens out when altitude is measured for over a 6-hour period, as the device does not change the sea level air pressure value while measuring altitude.
  • Page 27: Care And Maintenance

    NOTE: Do not use detergents or solvents of any kind as they might cause damage to the unit. Do not try to repair the unit yourself. Contact an authorized Suunto service, distributor or retailer for any repairs. Use only original Suunto accessories - damage caused by non-original accessories will not be covered by warranty.
  • Page 28 NOTE: Do not attempt to replace the battery yourself: www.suunto.com/Support/Service-Centers/Service-Center-Locator/...
  • Page 29: Specifications

    5 SPECIFICATIONS 5.1 Technical specifications General ● Operating temperature: -10 °C to +60 °C / -2°F to +140°F ● Storage temperature: -30 °C to +60 °C / -22°F to +140°F ● Water resistance: 100 m / 300 ft (according to ISO 6425) ●...
  • Page 30: Trademark

    Suunto brand trademarks and names are registered or unregistered trademarks of Suunto Oy. This document and its contents are proprietary to Suunto Oy and are intended solely for the use of clients to obtain knowledge and information regarding the operation of Suunto products.
  • Page 31: Disposal Of Device

    5.5 Disposal of device Please dispose of the device in an appropriate way, treating it as electronic waste. Do not throw it in the garbage. If you wish, you may return the device to your nearest Suunto representative.
  • Page 32: Warranty

    If, however, you purchased the Product in a member state of the European Union, Iceland, Norway, Switzerland, or Turkey, and Suunto originally intended the Product for sale in one of these countries, this Limited Warranty is valid and enforceable in all of these countries. The warranty service may be limited due to the possible country-specific elements in the Products.
  • Page 33: Warranty Period

    (1) year. To the extent your national laws permit, the Warranty Period will not be extended or renewed or otherwise affected due to subsequent resale, Suunto authorized repair or replacement of the Product. However, part(s) repaired or...
  • Page 34: Access To Suunto Warranty Service

    4. the Product has been exposed to influence from chemical products including (but not limited to) mosquito repellents. Suunto does not warrant that the operation of the Product will be uninterrupted or error free, or that the Product will work in combination with any hardware or software provided by a third party.
  • Page 35: Other Important Notices

    When the Product or a part is replaced, any replaced item becomes the property of Suunto. If a refund is given, the Product for which the refund is given must be returned to a Service Center as it becomes the property of Suunto and/or Service Center.
  • Page 36 Suunto knew of the likelihood of such damages. Suunto shall not be liable for delay in rendering service under the limited warranty, or loss of use during the time...
  • Page 37 +34 91 11 43 175 SWEDEN +46 8 5250 0730 SWITZERLAND +41 44 580 9988 +44 20 3608 0534 +1 855 258 0900 © Suunto Oy 9/2010, 9/2014, 4/2016, 8/2016 Suunto is a registered trademark of Suunto Oy. All Rights reserved.
