Page 1: Usr-W600 User Manual
USR-W600 User Manual Technical Support: h.usriot.com USR-W600 User Manual File Version: V1.0.6.01 Jinan USR IOT Technology Limited... -
Page 2: Table Of Contents
USR-W600 User Manual Technical Support: h.usriot.com Contents USR-W600 User Manual............................1 Features..................................3 1.Get Start..................................4 1.1.Application Diagram..........................4 2.Product Functions..............................5 2.1.WIFI mode..............................5 2.1.1.STA mode............................5 2.1.2.AP mode.............................5 2.1.3.AP+STA mode............................6 2.1.4.Encryption mode..........................6 2.2.Work mode..............................6 2.2.1.Transparent transmission mode....................6 2.2.2.AT command mode..........................7... -
Page 3: Features
Support WEP/WEA/WPA2. Support AP, STA, AP+STA. Support RS232 and RS485 serial ports. Support electrostatic protection. Support TCP/UDP Client identity packet function. Support Simple Config/Airkiss/usrlink. Support HTTP Client mode. Jinan USR IOT Technology Limited... -
Page 4: Get Start
USR-W600 User Manual Technical Support: h.usriot.com 1.Get Start Product link: http://www.usriot.com/p/rs232rs485-wifi-converter-wireless-serial-server/ If you have any question, please submit it back to customer center: Figure 1 Download Page http://h.usriot.com 1.1.Application Diagram Figure 2 Application diagram Jinan USR IOT Technology Limited www.usriot.com... -
Page 5: Product Functions
USR-W600 User Manual Technical Support: h.usriot.com 2.Product Functions This chapter introduces the functions of USR-W600 as the following diagram shown, you can get an overall knowledge of it. Figure 3 Product Functions diagram 2.1.WIFI mode USR-W600 supports three WIFI mode: STA, AP, AP+STA. -
Page 6: Ap+Sta Mode
2.2.1.Transparent transmission mode In this work mode, W600 can make a bidirectional connection between serial side and network side. This connection is transparent transmission. Data from serial device can be received in network, and network data Jinan USR IOT Technology Limited www.usriot.com... -
Page 7: At Command Mode
7, 8 1, 2 Data Bits None, Odd, Even, Mark, Space Stop Bits NFC: No flow control Parity Bits FC: Hardware flow control 485: Enable RS485 Flow Control Figure 9 Serial port basic parameters Jinan USR IOT Technology Limited www.usriot.com... -
Page 8: Serial Package Method
User can modify serial parameters by sending data conformed to specific protocol via network. It is temporary, after resetting module, the parameters will back to original parameters. 2.4.Features 2.4.1.Search in LAN Figure 11 Search in LAN Jinan USR IOT Technology Limited www.usriot.com... -
Page 9: Tcp/Udp Client Identity Packet Function
32 bytes) or USR Cloud identity packet(only work in TCP Client mode). 2.4.3.Usrlink When W600 works in AP mode will open a UDP port to receive usrlink commands(Port number 48899, same as ‘Search in LAN’ function and can be changed). Jinan USR IOT Technology Limited www.usriot.com... -
Page 10: Simple Config
WIFI connection exceptions include: 1. In STA mode, PING gateway unsuccessfully three times in succession. 2. In AP mode, no STA connecting. 3. In AP+STA mode, PING gateway unsuccessfully in succession and no STA connecting. Jinan USR IOT Technology Limited www.usriot.com... - Page 11 2.If W600 switched from STA mode to AP+STA mode automatically, W600 will connect to AP and back to STA mode after connecting successfully. 2~240 Initialize WIFI Initialize WIFI Initialize WIFI 2~240 min Figure 14 WIFI connection exceptions handling Jinan USR IOT Technology Limited www.usriot.com...
-
Page 12: Parameter Configuration
Technical Support: h.usriot.com 3.Parameter configuration There are two ways to configure USR-W600. They are Web Server and AT command. 3.1.Web Server User can connect PC to W600 through AP interface and enter Web Server to configure. Web Server default parameters as follows:... -
Page 13: Contact Us
Tel: 86-531-88826739/86-531-55507297 5.Disclaimer This document provide the information of USR-W600 products, it hasn’t been granted any intellectual property license by forbidding speak or other ways either explicitly or implicitly. Except the duty declared in sales terms and conditions, we don’t take any other responsibilities. We don’t warrant the products sales and use explicitly or implicitly, including particular purpose merchant-ability and marketability, the tort liability of any other patent right, copyright, intellectual property right.
