- Page 1 Digital Set Top Box DFTA12HD The Gold Technical Support Line: 1902 215 259 Personal Product Support (Charges will apply at $2.95 per minute)
-
Page 2: Introduction
Introduction Thank you for buying this Bush product, which is designed to give you many years of trouble-free service. You may already be familiar with using a similar unit, but please take time to read these instructions. They are designed to familiarize you with the unit’s many features and to ensure you get the very best from your purchase. -
Page 3: Table Of Contents
Table Of Contents Introduction…………………………………………………………….……..1 Safety instructions………………………………………………………….. 3 About the Set-Top-Box………………………………………………………4 Front panel and rear panel illustration………………………………..…5 Front Panel……………………………………………………………………5 Rear Panel……………………………………………………………..……5 Remote control……………………………………………………………….6 Installing the batteries…………………………………………………………7 Connecting to equipments………………………………………….………..8 First time installation…………………………………………….………..12 Basic operations…………………………………………………….……..13 Main menu…………..………………………………………………….……..16 Menu Tree………..……..……………………………………………….……17 Installation…………………………………………………………………..18 Auto Scan…..….……………………………………………………..18 Manual Scan………………………………………………………..……….18 Program edit…………..……………………………………………..……..19 System setup………………………………………………………….…….21... -
Page 4: Safety Instructions
Safety Instructions Always read the safety instructions carefully Keep this User's Manual for future reference Keep this equipment away from humidity Lay this equipment on a reliable flat surface before setting it up. Do not stand it on soft furnishings. If any of the following situation arises, get the equipment checked by a service technician: - The equipment has been exposed to moisture. -
Page 5: About The Set-Top-Box
About the Set-Top-Box This DVB-T TV Receiver is a Free-To-Air digital terrestrial receiver, allowing you to access free-to-air digital terrestrial TV channels and radio broadcasts on your TV set. Its digital reception covers VHF & UHF band. Compared with the analog TV programs, digital TV programs eliminate the noise and interference but offer high quality video and audio. -
Page 6: Front Panel And Rear Panel Illustration
Front panel and rear panel illustration Front Panel POWER To turn the Stand-by mode ON/OFF. MENU To enter the main menu. Press the button again to return to previous menu. OK To confirm the choice with the highlighted menu item. EXIT To exit the menu. -
Page 7: Remote Control
Remote control Remote key functions: POWER To turn the Stand-by mode ON/OFF. Numeric buttons (0-9) To select a channel by direct number input. SUBT To switch the close caption ON/OFF. EXIT To cancel operation or exit the menu directly. To Page Down (5-)/Page Up (5+). MENU To enter into the main menu, Press again to exit to previous menu. -
Page 8: Installing The Batteries
Installing the batteries Remove the battery cover from the remote control and put two AAA size batteries inside the compartment. The diagram inside the battery compartment shows the correct way to install the batteries. Caution: 1. Keep batteries out of children’s reach. 2. -
Page 9: Connecting To Equipments
Connecting to equipments How to get good reception In general you are not required to change the existing antenna. However if your antenna is not in good condition you should consider replacing them to ensure uninterrupted digital television viewing. Viewers in areas of poor analog reception may need specialists’ advice about antenna requirements for digital reception in their area. - Page 10 Connecting to equipment Connect the STB receiver via YPbPr output and Audio output (for high definition viewing) Connect the STB receiver via VGA output and Audio output (for high definition viewing)
- Page 11 Connecting to equipments Connect the receiver via HDMI output (for high definition viewing) Audio connections via Optical/Coaxial/Mixed Audio L/R Output...
- Page 12 Connecting to equipments Connect the receiver to DVD recorder or VCR. Note 1: Allows the recorder to record different channels. Note 2: Enables the recorder to record the digital channel you are watching.
-
Page 13: First Time Installation
First time installation Note: Be sure to turn on the main power at the rear of your receiver before using the receiver. After all the connections have been made properly, switch on your TV. Make sure the receiver is connected to the mains and press Power to switch the receiver on. If you are using the receiver for the first time or restored to factory default, a First Time Installation menu will be displayed to guide you through the initial setup to set the time zone, the daylight saving, the TV screen type and scan channels. -
Page 14: Basic Operations
Basic operations Switch program 1. Press the NUMERIC keys (0~9) on the remote control to select the channel number you want. 2. Press the key on the remote control or the front panel to change the available channels upward/downward. 3. Press the RECALL key to view the previous channel selected. Volume control 1. - Page 15 Basic operations Change video output mode Press OUTPUT key to select the matched video monitor between YPbPr and VGA. Change TV/Radio mode Press TV/Radio key to change the program list mode between TV and Radio. View program info 1. Press INFO key to view the detailed information of current program. 2.
- Page 16 Basic operations EPG (Electric Program Guide) 1. Press EPG key to view the EPG information that are provided by the content providers. 2. Press key to view the event information such as event name, event time. 3. Press OK key to view the detailed information of the current event. 4.
-
Page 17: Main Menu
Main menu This section guides you to walk through of all options on the Menu screen Navigation in the main menu 1. Press MENU key to bring up the main menu or return previous. 2. Press key to move upward/down to the desired sub menu. 3. -
Page 18: Menu Tree
Main menu Menu Tree Installation Scan selected channels Auto scan Program Edit Edit FAV Browse Lock Skip Delete Rename Move System Setup A/V setting Local time setting System information Factory default User Preference OSD Language OSD Transparency CH info bar time out Volume bar time out Parental control... - Page 19 Installation Auto Scan 1. Go to Main menu > Installation. 2. Press BLUE key to auto scan all the channels. 3. Press EXIT key if you want to stop during the auto scan. Manual Scan 1. Go to Main menu > Installation 2.
- Page 20 Program edit NOTE: If there is no program stored, you can not access the edit menu. Edit Favourite 1. Go to Main menu > Program edit > TV or Radio list. 2. Press YELLOW key to show the favorite list and then press key to select the desired favorite list, press OK key to enter favorite edit mode.
- Page 21 Program edit Delete Program 1. Go to Main menu > Program edit > TV or Radio list. 2. Press RED key to show a list of Edit modes. Press key to select the delete item. 3. Press OK key to enable the delete function. 4.
- Page 22 System setup A/V Output Settings 1. Go to Main menu > System setup > A/V output setting. 2. Press key to select the options: Resolution, Video output, Screen aspect, Audio output. And press OK to enter submenu of selected option. 3.
-
Page 23: User Preferences
User preferences OSD Language Go to Main menu > User preferences >OSD language. Only English is supported for this receiver. OSD Transparency 1. Go to Main menu > User preferences >OSD Transparency. 2. Press key to select the OSD Transparency option, and press OK key to enter submenu. -
Page 24: Parental Control
User preferences Parental Control 1. Go to Main menu > User preferences >Parental control. 2. Press key to select the Parental Control option, and press OK key and input the correct the PIN code to enter the submenu. 1. Parental Rating To set the rating level. -
Page 25: Trouble Shooting
Trouble shooting If you experience problems with this receiver or its installation, in the first instance please read carefully the relevant sections of this User Manual and this Troubleshooting section. Problem Possible cause What to do No signal found Aerial is disconnected Check aerial lead Aerial Check aerial... -
Page 26: Technical Specifications
Technical specifications Item Specification Tuner Frequency Range VHF: 174MHz to 230MHz UHF: 470MHz to 862MHz Input Impedance 75Ohms unbalanced Signal Input Level -78~-25dbm Bandwidth 7MHz Demodulation Demodulator COFDM OFDM Modulation 2K, 8K FFT, SFN and MFN Packed Carries 2K/8K Guard Interval 1/4, 1/8, 1/16, 1/32 Connectors RF IN... -
Page 27: Warranty
In the unlikely event that your product fails to work normally, please contact the Bush Warranty 1800 509 394 (Australia) or 0800 450 259 (New Zealand) and have your receipt of purchase on hand. - Page 28 PO BOX 6287 Silverwater NSW 1811 www.bushaustralia.com.au...
