Parts List - Strong TrussTrouper 1.2 Instruction Manual

Item Part No.
1 41243
2 65431
3 41325
4 83381
5 25420
6 4251003
- 4257000
- 4257102
7 4372250
8 65420
9 65824
10 83742
11 4433000
- 4507101
- 4438002
12 83744
13 49226
14 49208
15 83745
16 4437100
17 48395
18 10048A
19 49290
20 4377103
21 49130
22 7200835
23 20102200

PARTS LIST

Figure 4
Description
Yoke, Welded Assembly
Inner Tube Retaining Collar
Yoke Pivot, Welded Assembly
Swivel Clamp Collar
Strap (2 req'd.)
Screw, 1/4-20 x 1" Hex Head
Lockwasher, 1/4" Split Ring
Flatwasher, 1/4"
Screw, 3/8-16 x 2-1/4" Square Head
Thrust Bearing
Inner Tube, Welded Assembly
Outer Tube & Base Column, Welded Assembly
Screw, 7/16-14 x 3" Hex Head (4 req'd.)
Flatwasher, 1/2"
FlexLock Hexnut, 7/16-14
Base Leg, Welded Assembly (4 req'd.)
Leveling Foot (4 req'd.)
Caster (4 req'd.)
Leg T-Bolt (4 req'd.)
Flatwasher, 7/16"
Height Adjusting Pin, 3/8" Diameter
Knob, Red Plastic
Swivel Clamping Shaft
Thrust Washer
Handle Shaft
Tripod Yoke, Welded Assembly
Spigot (Hex Nut not shown)
TT/17
