Lenovo ThinkPad E570 User Manual page 108

3. Remove the removable battery. See "Replacing the removable battery" on page 77.
4. Remove the bottom cover. See "Replacing the bottom cover" on page 83.
5. Detach the connector
6. Install the new coin-cell battery
7. Reinstall the bottom cover. See "Replacing the bottom cover" on page 83.
8. Reinstall the removable battery. See "Replacing the removable battery" on page 77.
9. Turn the computer over. Connect the ac power adapter and all cables to the computer.
Attention: After you replace the coin-cell battery, reset the system date and time in the ThinkPad Setup
program. See "Date/Time menu" on page 52
92
ThinkPad E570, E570c, and E575 User Guide
1 and remove the coin-cell battery
1 and attach the connector
2 .
2 .
