Step 4; Step 5 - NEC OPS i5 PC Install Manual

Step 4

1. Open box containing OPS PC and remove contents - there
should be the OPS PC, CD and Option board slot cover.

Step 5

1. Using Phillips head screwdriver and the 4 screws you
saved when removing the factory cover, install the Option
board slot cover.
2. Using Phillips head screwdriver, remove the two slot
retaining screws at the front of the slot. Save these 2
screws as you will use them to secure the OPS PC in place
once installed.
*Note also in image, the 2 handle screws that have been re-
inserted in the previous steps, but that do NOT go in all the way
Revised 12-30-2011
4
Page
