Note
For optimal performance, a 6 mm or 8 mm lens is recommended.
For more information about lenses see www.axis.com
4. Attach the bottom cover from the P39 Series camera to AXIS
T96B05 bottom cover.
5. Thread the network cable through the hole and connect it.
See image 2.
6. Mount the bottom cover with the screws (4x). See image 3.
AXIS T96B05 Outdoor Housing
< 4mm (3/16 in)
