Technaxx TX–78 User Manual

The Declaration of Conformity for this device is under the Internet link: www.technaxx.de/ (in
bottom bar "Konformitätserklärung"). Before using the device the first time, read the user manual
carefully. This device has a rechargeable battery. It must be fully charged before first use.
NOTE: Charge the battery of the device every 2–3 month if it is not used!
Service phone No. for technical support: 01805 012643 (14 cent/minute from German fixed-line and
42 cent/minute from mobile networks). Free Email: support@technaxx.de
Important Hints *
 This device has 4 indicator lights. When only 2 LED are shining, or less, then do NOT use
the device to start your car ! But you can use it for charging digital devices.  When trying to
start your car more than 3x without success, stop starting it. Disconnect the device to avoid
damaging other parts of the car.  Check the power of the device 1x per month and also
charge it to ensure it can work in an emergency case.  Do NOT use the device all the time
for charging. Maybe then it will not have enough power for starting a car in an emergency
situation.  Device shuts down automatically when it is not loading other external devices.
Features
 3-in-1 Power Bank: Jump Starter for the car battery, Charging (e.g. Smartphone, Tablet
PC, etc.), Emergency Light  Jump start: diesel cars up to 3L engine, gasoline/petrol cars
up to 5L engine  Integrated emergency light (3 lighting effects)  Built-in protection against
overcurrent, short circuit, overload/-charge and overvoltage  2 USB outputs for
simultaneous charging of two devices  4-in-1 charging cable supports Micro USB & Mini
USB & Lightning & 30-pin connector  Ideal size to fit into the inner front glove
compartment
Technical specifications
Jump Start output
Starting current / Peak current
Input voltage
Output (USB ports)
Battery Clamps
Battery
Charging time
When device is fully charged it can charge iPhone 6S ~3 times
When device is fully charged it can be used ~200 times
Operating temperature
Storage temperature
Weight / Dimensions
Package Contents
Technaxx
Jump Starter 10000mAh TX–78
This device is only suitable for CARS (12V) !
12V output for starting a car
300A / 400A
at home 15V/1A, in a car 12V/1A
5V/1A and 5V/2A
Input: DC 10.8–15V 400A, Output: DC 12V 400A
Lithium polymer battery with 10000mAh 3.7V/ 36.63Wh
~4 hours
Jump Starter 10000mAh TX-78, 4-in-1 USB cable, Jump Starter
cable with battery clamps, Home charger, Car charger,
®
* User Manual
0°C up to +60°C
–10°C up to +60°C
385g / (L) 16.5 x (W) 7.3 x (H) 2.8cm
User Manual
