Profoon PDX-5200 Series User Manual

Hide thumbs Also See for PDX-5200 Series:

Advertisement

Quick Links

Download this manual
USERS MANUAL
PDX-5200
series

Advertisement

loading
Need help?

Need help?

Do you have a question about the PDX-5200 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Profoon PDX-5200 Series

Summary of Contents for Profoon PDX-5200 Series

  • Page 1 USERS MANUAL PDX-5200 series...
  • Page 2 MENUGUIDED PROGRAMMING press NU” NUMMERGEHEUGENS display geeft invoeren geheugens blz. 17 “PHONEBK” DELETE uitwissen geheugens blz. 17 press press MODIFY corrigeren geheugens blz. 18 ∇ “OK” INSTELLINGEN HANDSSET display geeft BEEP attentietoontjes blz. 21 “HANDSET” EAR VOL ontvangstvolume blz. 13 RING VOL belvolume handset blz.
  • Page 3 The declaration of conformity is available on the website WWW.PROFOON.COM DECLARATION OF NETWORKCOMPATIBILITY The Profoon PDX-5200 series is designed for use on the ‘public switched telep- hone networks (analogue single-line)’ of telephone- and cable-companies inside the European Union. Each country and/or provider might require a different telephoneplug.
  • Page 4 INHOUDSOPGAVE OVERZICHT HANDSET ........6 OVERZICHT BASIS .
  • Page 5 attentietoontjes ......... . 21 uitschakelen toetsenbord .
  • Page 6 WHERE TO FIND: HANDSET built-in loud- display, see page 8 speaker button ∆ and ∇: - press to display the last 10 numbers you dialled Memory button: - press during program- - press to make calls to ming to move through the numbers stored in menu’s memory...
  • Page 7 WHERE TO FIND: BASE connections for the power adapter and for the telephonecable (backside base) handset locator: - press to call all handsets - press and hold to register new handsets telephone-LED (green) - comes on during a telephonecall - flashes when new messages are recorded or new caller-ID’s have been received (when you have listened to all messages and vie- wed the callers list, this LED will go off.
  • Page 8 DISPLAY SYMBOLS handsetname handsetnumber (free programmable) There are more than 12 digits, the display shows the last 12 only. Batterylevel. You are connected on an intercom call. You are connected to the telephone line. your handset is ringing for an intercom call. Your handset is ringing for an incoming call..
  • Page 9 This telephone is not designed for making emergency telephone calls when the power fails. Make alternative arrangements for access to emergency services. SAFETY INFORMATION 1. Please read all the instructions of this manual before using this product. 2. Observe all the instructions marked on this product. 3.
  • Page 10 INSTALLATION 1. Connect the telephone line cord, one side into the wall socket, another side to the base station socket. 2. Power-up the base station by connecting the AC power adapter to the mains socket and another side to the power jack of the base station.
  • Page 11 Your security PIN You will need the PIN-code for setting or changing some features and to register new handsets. The default PIN is 0000. You can change it to any number, up to eight digits. Press the button , the display shows PHONEBK Press the button TWICE, the display shows BASE Press the OK button...

  • Page 12: Making And Answering Calls

    MAKING AND ANSWERING CALLS Speakerphone function: When you press the SPEAKERPHONE (xxxx) button, you can listen without holding the handset to your ear. You can start a call by pressing the SPEAKERPHONE button, or press it any time during a call; but you must press the PHONE ( ) button to end a call.
  • Page 13 Memory dialling You can store up to 40 numbers in each handset's memory. Each number can have up to 20 digits, and you can store a name of up to eight characters with the number. To store a number: 1. Press the MENU button, the display shows "PHONEBK" 2.
  • Page 14 To make a memory call: 1. Press the MEMORY button, the display shows xx 2. Press the xx or xx button until the display shows the name or number you want 3. Press the PHONE or SPEAKERPHONE button To modify (change) a number in memory: 1.

  • Page 15: Answering Machine

    and the IN USE light stops flashing. To return a call: To make a return call to someone who's called you: 1. Press the PHONE or SPEAKERPHONE button while either the name or number is shown on the display. To delete a Caller Display record: 1.
  • Page 16 To control answering machine functions, you first press the button xx (also labelled R). You can then scroll through the menus for the functions you want. Some of the numbered buttons also give you shortcuts for functions you often use. Just press the button followed by the numbered button, as shown here. 1 OGM Record the outgoing message (OGM) 2 OGM...
  • Page 17 The display shows messages 0 (or the current number of recorded messages) and the symbol while the machine is switched on. If "MEM FULL" flashes momentarily on the display, and you hear a warning 'beep', the machine's memory is full. You'll need to delete some or all recorded messages before you can switch on (see page xx).
  • Page 18 5. Press the button xx to go back to standby mode Message playback: While the answering machine is switched on, the total number of recorded mes- sages (new and old, and including a memo, if you have recorded one) is shown on the display.
  • Page 19 can record up to 13 messages; with the maximum length set to 60 seconds, it can record up to 8 messages. 1. Press the button xx, the display shows "MSG PLAY" 2. Press the xx button FOUR times, the display shows "ICM LENGTH" 3.
  • Page 20 2. While your OGM is playing, press xx, your OGM stops playing. 3. Key in your remote security code (see page xx) If there are new messages, they will be played back. If there are no new messages, any old messages will be played back. When all messages have been played, you'll hear two 'beeps'.
  • Page 21 Tones and volumes Earpiece volume: While the phone is not connected on a call: 1. Press the MENU button, the display shows "PHONEBK" 2. Press the xx button, the display shows "HANDSET" 3. Press the OK button, the display shows "BEEP" 4.
  • Page 22 Handset ringing volume: You have a choice of five volume levels or of turning the ringer off. 1. Press the MENU button, the display shows "PHONEBK" 2. Press the xx button, the display shows "HANDSET" 3. Press the OK button, the display shows "BEEP" 4.

  • Page 23: Customising Your Phone

    9. Press the MENU button to go back into standby mode CUSTOMISING YOUR PHONE Your handset name: The default name shown on your handset's display is "PROFOON". You can change this to anything with up to eight characters. 1. Press the MENU button, the display shows "PHONEBK"...
  • Page 24 Auto-answer: Normally, you need to press the PHONE or SPEAKERPHONE button to answer an incoming call. But with auto-answer turned on, when your handset is resting on the base unit or in a charger-pod and it rings for an incoming call, you can answer by simply lifting the handset.
  • Page 25 ! With the keypad locked, you cannot make emergency calls to 999 or 112. Your security PIN: You will only need this feature if you plan to set up Call Barring (see page xx) and to register new handsets (see page xx). The base unit has a default PIN (personal identity number) of 0000.
  • Page 26 9. Press the xx or xx button to change the level of call barring 10. Press the OK button to confirm 11. Press the MENU button to go back into standby mode To turn call barring OFF: Follow steps 1 to 11, setting the level to "NO BAR" at step 9 Emergency call (BabyCall) With this option turned on, the handset can't be used to make any outside calls except to a number you have programmed in.

  • Page 27: System Failure

    If you have a Twin, Triple or Quad system, you will already have two, three or four handsets. You can also buy spare handsets and charger pods separately - they're supplied as PROFOON PDX-5210. Altogether, you can have up to five handsets registered to the base unit, as num- bers 2, 3, 4 and 5.
  • Page 28 Each handset has its own number - 1, 2, 3, 4 or 5 - which is shown on the right- hand side of the display. You can change each handset's name from "PROFOON" to a name of your choi- ce, as described on page xx.
  • Page 29 ! You cannot de-register the handset you are currently using. Registering to a different brand of base unit: Each PDX-5200 series handset can be registered to any GAP-compatible base unit; or you can register other GAP-compatible handsets to your PDX-5200 series base unit.
  • Page 30 3. Press the PHONE button on your handset to end the intercom call (the other person will hear Busy tone, and should also press the PHONE button to hang To transfer a call: When you have made or answered an outside call, to transfer it to another hand- set: 1.
  • Page 37 ver1.0, Dec. 2003...
