MODEL VXRS RAIL SAW
Owner's/OperatOr's Manual
Caution!
Read Safety and General Instructions carefully before using saw for the first time.
REV. 1
serial
number -
You should record the Serial Number of your
Tile Saw on this Owner's/Operator's Manual
and on the Warranty Card.
The Warranty Card must be sent back with
all the required pertinent information for the
warranty to take effect.
Patents Pending
ssembled in U.S. .
Advertisement
Table of Contents
Related Manuals for Pearl Abrasive X10RS
Summary of Contents for Pearl Abrasive X10RS
- Page 1 MODEL VXRS RAIL SAW Owner’s/OperatOr’s Manual serial number - You should record the Serial Number of your Tile Saw on this Owner’s/Operator’s Manual and on the Warranty Card. The Warranty Card must be sent back with all the required pertinent information for the warranty to take effect.
-
Page 2: Table Of Contents
TABLE OF CONTENTS page COntents ..............2 genearl safety rules &... -
Page 3: General Safety Rules
ii. GENERAL SAFETY RULES AND PRECAUTIONS W RNING! Read all instructions. s with all machinery there are certain hazards involved with operation and use of the machine. The following basic safety precautions should be followed at all times to reduce the risk of fire, electric shock and serious personal injury to you or others. Keep these important operating instructions with this product. - Page 4 21. Extension cords. Make sure your extension cord is in good condition. When using an extension cord, be sure to use one heavy enough to carry the current your product will draw. n undersized cord will cause a drop in line voltage resulting in loss of power and overheating. If in doubt, use the next heavier gage. The smaller the gage numbers the heavier the cord.
-
Page 5: Health Warnings
iii. HEALTH WARNINGS Some dust are created by power sanding, sawing, grinding, drilling, and cause other construction activities contains chemicals known to cause cancer, birth defects or other reproductive harm. Some examples of these chemicals are: • Lead from lead based paints, •... -
Page 6: Features
v. FEATURES The VX10RS Stone Saws are designed with water flow control in mind. The water pump, inside the tray or as an option it can be used inside a bucket, a water control valve and splash guards ensure proper water flow during operation. Powerful 1-1/2HP Position Lock Direct Motor cuts... -
Page 7: Blade Installation
vi. UNPACK, ASSEMBLY & SET -UP UNP CK Open the container, carefully lift the saw frame handles and place it on a flat, level working area. Be certain that you have the following items before you discard the container: Water Pump Fold-in Legs with Wheels Water Level Tube 10"... -
Page 8: Cutting Head Installation
ix. CUTTING HEAD x. SIDE TABLE & SPLASH GUARD INSTALLATION INSTALLATION 1. Slide the motor into the body of the cutting head 1. Install the side table and splash guard as shown in mainframe, holding the motor front (outer) ring figure 3 to the side. -
Page 9: The Rip Guide
xii.THE RIP GUIDE The MasterGuide is a two-piece assembly consisting against the side and limit stops with the right hand. of a template base and a unique detachable ruler lways turn off the saw before you leave the machine guide. This permits any cutting angle between 0° unattended. -
Page 10: Cutting Depth
FEATURES used for cutting natural and artificial stone materials, do not cut wood or metal! • The easily removable cutting table is covered with an • The saw uses diamond saw blades with diameters anti-skid rubber coating, which allows the material up to 10". -
Page 11: Do's & Don'ts For Blades
xviii.THE RIGHT BLADE DOES THE RIGHT JOB For the most effective cutting and blade life always use the recommended Pearl brasive Co. blade. APPLICATION PEARL BLADE CERAMIC EXTRA HARD PORCELAIN MARBLE GRANITE HARDSTONE STONE SERIES TILE CERAMIC DTLB19 Series GRT Series SD Series SH Series SHD Series... - Page 12 xx. CARE AND MAINTENANCE W RNING! For your safety before CLEANING performing any maintenance on the saw, turn off the power switch and unplug the power cord. FTER EVERY USE OF THE M CHINE: • Remove dirty water from container. GENERAL RULES •...
- Page 13 TEMPERATURE CHANGES xxii. ACCESSORIES MBIENT TEMPER TURE BELOW 37°F (WINTER) Part Name • To prevent the water in the pump and cooling system ngle Guide from freezing, remove the water after using the machine or when there will be a long break. Make Part Number sure that the cooling system is entirely drained so V370060...
-
Page 14: Water Pump Maintenance
xxiii. REPLACEMENT PARTS LIST P RT N ME P RT NUMBER P RT N ME P RT NUMBER Guide Rail V370001 15 Side Splash Guard V370015 Ruler Guide Bolt (set of 4)/M6X16 V370002 16 Rear Rubber Cutting Table V370016 Supporting Post Lock Bolt/ M5X20 V370003 17 Splash Guard Wing Nut/M6 V370017... - Page 15 28 29 P RT N ME P RT NUMBER P RT N ME P RT NUMBER 23 Water Flow “Y” dapter V370023 40 Circuit Breaker V370041 24 Water Control Valve V370024 41 Toggle Switch V370042 25 Blade Guard Lock Knob V370025 42 Switch Housing Control Panel V370043...
- Page 16 xxiv.TROUBLESHOOTING PROBLEM POSSIBLE C USE SOLUTION - Power cord not properly - Check that the machine is properly M CHINE DOES NOT RUN WHEN fixed/plugged in. connected to the power supply. SWITCHED ON - Power cord defective. - Have the power cord checked, replace if necessary.
- Page 17 PROBLEM POSSIBLE C USE SOLUTION EXCESSIVE WE R - Wrong type of saw blade. - Use harder saw blades. - Shaft of motor causes wobbling. - Have bearings of the motor or the - Overheating. motor replaced. - Ensure optimum flow of cooling water.
-
Page 18: Customer Service
xxv. HOW TO ORDER PARTS Please have the following information ready before calling: • Serial Number of your Tile Saw • Model Number of the Tile Saw • When purchased and where • Part Description ll parts listed may be ordered from your Local warehouses. If the part is not stocked locally, call our Corporate office and ask for our Customer Service Department. - Page 19 – 19 –...
- Page 20 CORPORATE OFFICE: SO. CALIFORNIA • USA 4900 ZAMBRANO ST., COMMERCE, CA 90040-0031 562-927-5561 • FAX 562-928-3857 Toll Free: 800-969-5561 www.pearlabrasive.com GEORGIA • USA ONTARIO • CANADA 3950 STEVE REYNOLDS BLVD., 375-2 PIDO ROAD NORCROSS, GEORGIA 30093 PETERBOROUGH, ONTARIO K9J-6X7 Part No. VX10RS • 07/17...
