MODEL VX141MSPRO
MASONRY/BRICK SAW
OWNER'S/OPERATOR'S MANUAL
Caution!
Read Safety and General Instructions carefully before using saw for the first time.
REV. 5
serial
number -
You should record the Serial Number of your Tile Saw on this Owner's/Operator's Manual
and on the Warranty Card. The Warranty Card must be sent back with all the required
pertinent information for the warranty to take effect.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VX MSPRO VX141MSPRO and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Pearl Abrasive VX MSPRO VX141MSPRO

Summary of Contents for Pearl Abrasive VX MSPRO VX141MSPRO

  • Page 1 MODEL VX141MSPRO MASONRY/BRICK SAW OWNER’S/OPERATOR’S MANUAL serial number - You should record the Serial Number of your Tile Saw on this Owner’s/Operator’s Manual and on the Warranty Card. The Warranty Card must be sent back with all the required pertinent information for the warranty to take effect. Caution! Read Safety and General Instructions carefully before using saw for the first time.

  • Page 2: Table Of Contents

    TABLE OF CONTENTS PAGE GENERAL SAFETY RULES FOR ALL POWER TOOLS ......3 SYMBOLS .

  • Page 3: General Safety Rules For All Power Tools

    i. GENERAL SAFETY RULES FOR ALL POWER TOOLS WARNING! Read all instructions. As with all machinery there are certain hazards involved with operation and use of the machine. The following basic safety precautions should be followed at all times to reduce the risk of fire, electric shock and serious personal injury to you or others.

  • Page 4: Symbols

    21. Extension cords. Make sure your extension cord is in good condition. When using an extension cord, be sure to use one heavy enough to carry the current your product will draw. An undersized cord will cause a drop in line voltage resulting in loss of power and overheating.

  • Page 5: Features

    iii. FEATURES REINFORCED RIGID FRAME contruction provides steady precision cutting POWERFUL 2HP MOTOR induction motor designed to be powerful yet convenient the user HEAVY DUTY ALUMINUM SWITCH box with an integrated circuit breaker further increasing saw reliability OPTIONAL OUTER TRAY for wet application RAISED PLATFORM FRAME TABLE LOCKING MECHANISM...

  • Page 6: Unpacking

    v. UNPACKING Open the container. Carefully lift the saw out evenly by the frame. Be certain you have the following items before you discard the container: • Saw • Size 19 Open Wrench • Water hose kit • 14" saw blade •...
  • Page 7 THE CUTTING TABLE WARNING: It is recommended to cut all the way through the material being cut. Failure to do so can result in the diamond The heavy-duty cutting table provides the durability to handle large blade grabbing the material causing damage and possibly materials.

  • Page 8: Water Hose Kit Installation

    vii. WATER HOSE KIT INSTALLATION 1. Orient the w ater pipes as shown in Fig. A. Insert the shortest pipe from the "Y" adapter into the adjacent sleeve at the rear of the blade guard. First, you will need to remove the black cap covering the hole insert (#1).

  • Page 9: Proper Blade Use

    viii. PROPER BLADE USE DO’S DON’TS • Inspect blades daily for cracks or uneven wear. • Do not operate the saw without safety guards in position. • Always use appropriate blade for material being cut. • Do not operate the saw with blades larger than 14". •...

  • Page 10: Electrical Motor Specifications

    x. ELECTRICAL MOTOR SPECIFICATIONS Horse Power 2 HP Volts 115V Amps Motor RPM 3,440 rpm Cycle 60 Hz WARNING: To avoid permanent motor damage you must use the correct extension cord. Never use more than one extension cord at a time. Follow the chart for proper size.

  • Page 11: Replacement Parts List

    xi. REPLACEMENT PARTS LIST VX141MSPRO MAIN ASSEMBLY PART NAME PART NUMBER PART NAME PART NUMBER Frame assembly (no rails) PA150328 M5 X 0.8 X 16L Cross screw (4) V3925058 Depth guide weldment PA141094 Dia 17mm arbor inner flange V390029 Collar Set Cutting Head V390046 Dia 17mm arbor outer flange V390006...
  • Page 12 VX141MSPRO FRAME ASSEMBLY PART NAME PART NUMBER PART NAME PART NUMBER Left Arm V390007 M8 X 1.25 X 30L Socket hex bolt (2) PA2704081 Metal pan frame V390017 M6 x 1.0 x 10L Socket head hex screw (4) PA150333 Dust Collection Pan V390014 M6 x 1.0 Nut (2) PA0610001...
  • Page 13 VX141MSPRO CUTTING HEAD ASSEMBLY PART NAME PART NUMBER PART NAME PART NUMBER 2 HP motor VX141122 M5 Spring lock washer (2) V3925053 Motor Fan Cover PA141079 5/16" - 18 UNC Nut (4) PA01191 Motor Fan PA150231 30D X 120 Handle PA150313 Motor Adjustment Clip S1000-10...
  • Page 14 VX141MSPRO SWITCH ASSEMBLY PART NAME PART NUMBER PART NAME PART NUMBER Switch box PSV00002R 25Amp Circuit breaker PA150350 (no cover or electrical components) Aluminum cover PA100006 Reset button boot S1000-03.1 Aluminum rotary switch (external) PA100019 20Amp Toggle switch V390027 Metal relay fork (internal) PA141117 M4 x 0.7 x 13L Countersunk cross screw (4) PA2912...
  • Page 15 VX141MSPRO BLADE GUARD ASSEMBLY PART NAME PART NUMBER D12.7 Circular end cap PA250731 Arbor Cover V390003 D14.5 Circular end cap (2) PA25073 M6 Narrow washer (3) PA00082 M6 X 1.0 Nylon Nut CX38088 M6 X 1.0 X 16L Hex bolt PA00083 M6 x 1.0 x 10L Hex bolt V390322...

  • Page 16: Troubleshooting

    xii. TROUBLESHOOTING WARNING! For your safety and the safety of others, turn the power switch off and always remove the plug from power source before troubleshooting. Repairs performed by unauthorized personnel could cause serious hazard. We recommend that service to this tool be performed by a qualified service technician with original equipment replacement parts.
  • Page 17 Problem Possible Cause Solution Irregular run of the saw blade. Poor tension in the blade material. Return the saw blade to the manufacturer. Excessive wear. Wrong type of saw blade. Use harder saw blades. Shaft of motor causes wobbling. Have bearings of the motor of the motor replaced.

  • Page 18: Accessories And Parts

    Problem Possible Cause Solution Saw blades shows blooming colors. Lateral friction when cutting. The material feed is too high; proceed more slowly. Grinding marks on the saw blade. Material is not being fed parallel to the saw Ensure that the direction of feed is absolutely blade.

  • Page 19: The Right Blades Does The Right Job

    Pearl reserves the right to discontinue products at any time without notice. All illustrations displayed in this manual are the property of Pearl Abrasive Co. and shall not be duplicated or reproduced without the express written consent of Pearl Abrasive Co.
  • Page 20 CORPORATE OFFICE: 455 SATELLITE BOULEVARD, SUWANEE, GA 30024 562-927-5561 • FAX 562-928-3857 Toll Free: 800-969-5561 ONTARIO • CANADA 375-2 PIDO ROAD PETERBOROUGH, ONTARIO K9J-6X7 www.pearlabrasive.com Part No. VX141MSPROMAN • 01/24...
