T L - U L T R A L I G H T
T L - 3 0 0 0 S I R I U S
F l i g h t
P u b l i s h e d
Aircraft s/n:________________
Airport, building 84
503 41 Hradec Kralove
tel/fax: +420 4952 13378
tel +420 4952 11753
tel +420 4952 18910
info@tl-ultralight.cz
www.tl-ultralight.cz
a n d
m a n u a l
i n
J a n u a r y
o p e r a t i o n a l
2 0 0 9
Registration no._____________:
1
r
e
v

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TL 3000 Sirius and is the answer not in the manual?

Questions and answers

Related Manuals for TL Ultralight TL 3000 Sirius

Summary of Contents for TL Ultralight TL 3000 Sirius

  • Page 1 T L - U L T R A L I G H T Airport, building 84 503 41 Hradec Kralove tel/fax: +420 4952 13378 tel +420 4952 11753 tel +420 4952 18910 info@tl-ultralight.cz www.tl-ultralight.cz T L - 3 0 0 0 S I R I U S F l i g h t a n d o p e r a t i o n a l...
  • Page 2 This page blank for notes: Page 2 of 68...

  • Page 3: Table Of Contents

    1. GENERAL INFORMATION ....................8 1.1. Important Information ......................... 8 1.2. Description of the aircraft........................8 1.2.1. Airframe ..............................8 1.2.2. Fuel system ............................9 1.2.3. Propeller..............................9 1.2.4. Engine ..............................9 1.2.5. Control movements........................... 10 1.2.6. Basic technical data of the airplane....................12 1.3.

  • Page 4: Emergency Procedures

    2.7. Maximum flight height ........................23 2.8. Meteorological condition restriction....................23 2.9. Carriage of restricted goods......................25 2.10. Types of airport traffic........................25 3. EMERGENCY PROCEDURES..................26 3.1. Misfire of the engine ..........................26 3.1.1. Failure of the engine during the flight to the height 200m............26 3.1.2.
  • Page 5 4.13. Standing up to the plane........................37 5. PERFORMANCE ........................ 37 5.1. Assumptions for performance calculations.................. 37 5.2. Speeds ..............................38 5.3. Rate of climbs and height loss from the beginning of stalling ..........38 5.4. Ceiling ............................... 38 5.5. Gliding range ............................38 5.7.
  • Page 6 7.3. Warranty Service ..........................60 7.4. Periodical revision after every 50hours ..................60 7.5. Periodical revision after every 100hours..................60 7.6. Periodical revision after every 200hours..................61 7.7. Inspection after every 300hours ..................... 61 7.8. Jacking points on the plane....................... 61 7.9.
  • Page 7 I wish you a lot of joy from flying with your new airplane the TL-3000 Sirius. In Hradec Králové 1 January 2009. TL Ultralight L.T.D. Jiří Tlustý TL-ULTRALIGHT s.r.o. Airport, building 84...

  • Page 8: General Information

    1. General Information In case this guidebook refers to the rule UL1, UL 2 or UL 3, it is only referring to the corresponding rules of Letecké amatérské asociace české republiky – Czech Republic amateur flight association. This association is controlled by Úřad pro civilní letectví- Office for civil aviation Czech Republic.

  • Page 9: Fuel System

    The cabin is arranged with seats next to each other – side-by-side, remarkable view into all sides is provided by windows. Locking of two side doors is point-to-point. The door windows are equipped with rotating vents or sliding windows. The controls for the airplane are duplicated, arranged with a steering yokes. A control rod controls the elevator;...

  • Page 10: Control Movements

    ATTENTION! Some engines are not certificated as flying engines. Even though maximum attention is paid during the manufacture of the engine, misfire of the engine can occur at any time. The pilot is responsible for the consequences associated with flying this aircraft. The obligation of the pilot to fly at all times where in the event of an engine failure they are able to glide and land safely to a pre-selected area.
  • Page 11 The Throttle Lever is located between the pilot and passenger in the center console, forward represents full throttle and backwards returns engine to idle. Page 11 of 68...

  • Page 12: Basic Technical Data Of The Airplane

    1.2.6. Basic technical data of the airplane Wing span 9.40m Length 6.75m Height 2.25m Wing area 11.15m2 Root profile depth 1.30m Ending profile depth .90m Wing aspect ratio 7.92 Surface loading 40.30kg/m2 Aileron span 1.87m Aileron area 0.51m2 Aileron deflections 11.50 down 7.60...

  • Page 13: Layout Of The Airplane

    1.3. Layout of the airplane Dimensioned Layout of the TL-3000 Sirius Page 13 of 68...

  • Page 14: Detecting The Center Of Gravity Position, Allowed And Measured Values

    1.4. Detecting the center of gravity position, allowed and measured values Observance of the center of gravity is vital for the stability and manageability of the airplane. That’s why it is necessary for every airplane pilot to know how to diagnose the center gravity position of the airplane for different occupancy.

  • Page 15: Weighing The Airplane For The Foreword Center Of Gravity Position

    1.4.1. Weighing the airplane for the foreword center of gravity position • Pilot’s seat is occupied with a pilot with the lowest allowed weight • There cannot be any load on the plane; the fuel tank must be full • Measure the weight of the rear wheels; add the left side and the right side together.

  • Page 16: Air-Speed Data And Position Fault Of Pitot Tube

    Km/h Knots Take off speed Climb speed Cruising speed 180-230 97-124 Accession landing (approach) The speed of bearing the surface (landing) Maximum speed of horizontal flight Design turnover speed V 160 is due to diagram V – n in Type design Never never-exceed speed Vne Maximum speed at turbulence Stalling speed with no flaps...

  • Page 17: Reparation Table Of Real And Indicated Air-Velocity In Km/H

    For safety reasons not extending the maximum allowed speeds we choose the type of lower real calibrated speed than the indicated speed. All speed limits introduced in this guidebook as operating restrictions are initiated as the speeds indicated by the air- speed recorder.

  • Page 18: Positioning Of The Load

    Fuel amount in liters Max.allowed C.G. Max.allowed C.G. the fuel tank crew weight / % / Crew weight with / % / without baggage baggage 20 kg / kg / / kg / Full 3 / 4 1 / 2 1 / 4 30min of flight 2.2.3.

  • Page 19: Propeller Operating Restrictions

    2.3. Propeller operating restrictions There is a general requirement for protecting the propeller against the effects of rain and sun when not in actual use. Covers for your propeller blades were delivered together with your propeller and please, use them at any time when your airplane is parked for any time.

  • Page 20: Consumption Of Fuel

    2.4.2. Consumption of fuel The consumption of fuel expressively depends on the type of propeller, engine, and the technique of the pilot, total weight of the airplane, height of the flight, flight regime and the consumption is expressively influenced by the meteorological conditions with the consumption being increased with higher temperature.

  • Page 21: Allowed Turns

    Non-acrobatic operation due to Ul2, part 1, letter A, point 2 includes any turns needed for normal flying, practicing of stalls (drops) and sharp turn to 60degrees. We also stress that the airplane TL 3000 Sirius with its exceptional attributes leads on operating acrobatically, this airplane is not an aerobatic airplane and intentional stalls (drops), spins and aerobatics are strictly prohibited.

  • Page 22: Pilot´s Qualification

    Maximum weight of 450 kg cannot be over passed in any case! 2.6.2. Pilot´s qualification TL 3000 Sirius is aerodynamically controlled airplane. The rule UL 1 in head 3 determines the requirements for qualification of the pilot for this category of airplane.

  • Page 23: Pilot's Place On The Plane, Age Of The Crew, Using The Seat Belts

    2.6.3. Pilot’s place on the plane, age of the crew, using the seat belts The airplane TL 3000 Sirius is equipped with two pilot controls and the ability of seeing the appliances from both seats is well. Assessing the place of pilot is not a technical question but the law question.
  • Page 24 restrictive conditions: Page 24 of 68...

  • Page 25: Carriage Of Restricted Goods

    Maximum outside temperature +45 degrees of Celsius Minimum outside temperature -15 degrees of Celsius Maximum speed of wind against the direction of taking off 6m/s Maximum vertical side component of wind 3m/s Maximum speed of the wind in the direction of taking off 1m/s Operating restrictions of the airplane in the way of meteorological conditions in cooler weather are determined mostly by the possibility of ice formation.

  • Page 26: Emergency Procedures

    3. Emergency procedures 3.1. Misfire of the engine The procedure while failure of the engine differs due to the time we have to solve the situation, so the height of the flight where the failure occurs. 3.1.1. Failure of the engine during the flight to the height 200m •...

  • Page 27: Fire On Board Of The Plane

    Vibrations can exhibit by the glide performing and this is the consequence of unsymmetrical by-passing the aerodynamic clean airplane TL 3000 Sirius. In this case slow down the speed of the glide.

  • Page 28: Undercarriage Failure

    3.4. Undercarriage failure 3.4.1. Main undercarriage failure Land on the side of not damaged leg, on this side using the ailerons, tries to relief the damaged leg as long as possible, in case of the main undercarriage failure. 3.4.2. Front undercarriage failure In the course of the front undercarriage failure, try to keep the front up as long as possible, if possible do not use brake, because the inertia force actuating on the center of gravity of the airplane is trying while braking to collapse the front of the airplane...

  • Page 29: Operating Procedures

    Before the flight, introduce the placing of the starter to the fellow- traveler and let him try on a dustproof system if he is possible to use it. 4. Operating Procedures 4.1. Starting up the engine Tasks which need to have been done especially before first startup of the engine in the flight day, or in the case the engine had cooled down, are written in detail in the guidebook for the maintenance for the engine of your airplane, which was delivered to you with other documents.

  • Page 30: Important Parts Made Before Getting Off

    We initiate only the basic principles: let the engine run for about 2 minutes with the revolutions of 2000/minute and • continue with its warming up with the revolutions of 2500/min till the oil temperature does not reach 50*Celsius. Check the temperatures and the pressures while warming up and if all operating values have been reached do the test of ignition at the revolutions of 4000/min, the drop of the revolutions •...
  • Page 31 while taxiing, try the function of the brakes and pilotage of the front wheel, • maximum speed taxiing 4km/h slow walk Page 31 of 68...

  • Page 32: Taxiing

    set the altitude meter • check the gas pressure indicator • check if all required values of the engine are achieved • check if both ignition circuits are turned on • check the turning on of the appliances, respectively check the artificial horizon •...

  • Page 33: Maximum Power Of Wind At Time Of Taking Off

    At flight at the flight level it is necessary to count with big sensitivity of controlling agents and the reactions to the pilotage of the airplane change with the speed of the flight, the speed of TL 3000 Sirius Carbon has a wide range. ATTENTION!

  • Page 34: Descent

    4.8. Descent While descending from higher flight levels which lasts longer time we recommend not to descent at no load in order to protect the engine from cooling down, but to descent with slight tension engine with speed about 220km/h. Page 34 of 68...

  • Page 35: Sideslip

    4.8.1. Sideslip The slip should be performed at the speed between 120 to 130km/h. 4.9. Landing Set the propeller to small angle of incidence if your propeller is adjustable, in case having to repeat the landing, your engine would have the full disposal of output. Set the weighing of the airplane slightly heavy on the tale and fasten your seat belts.
  • Page 36 ATTENTION! Before leaving and locking the cabin lock and lock in the saving • system Page 36 of 68...

  • Page 37: Flying In Lateral Wind

    4.11. Flying in lateral wind If you will be flying with keeping the prescribed meteorological restrictions, the allowed values do not present any expressive barrier in order to take off nor land. If you will have to land in stronger lateral wind use the technique of glide against the wind or the flight with lateral bending against the wind.

  • Page 38: Speeds

    5.2. Speeds Stalling speed of the airplane in the landing configuration Vso 62km/h Maximum never-exceed speed Vne 253km/h Max.speed of horizontal flight with max. steady output of the engine Vh 230km/h These figures have been calculated at the maximum aircraft weight of 450kg and will vary dependant on such factors as weight of the aircraft and altitude above mean sea level.
  • Page 39 will decrease when the engine is switched off due to the increased drag. Page 39 of 68...

  • Page 40: Landing Length

    5.6. Length of start Takeoff length has been determined within the following constraints: Maximum All Up Weight of 450 kg • Nil wind • Dry, straight and short cut grassy landing strip • Nil gradients • 1st Stage of flap •...

  • Page 41: Maximum Endurance

    5.8. Maximum Endurance The endurance is the maximum time that aircraft can fly without refueling. It is calculated by multiplying the available fuel in the tanks, by the lowest hourly consumption. To achieve maximum duration, the speed must be reduced to a level which is not safe in all but the smoothest of flying conditions and as such, full details are not provided here.

  • Page 42: Flying Range

    5400 5500 The optimalization of propeller operation itself is not sufficient in order to ensure the flight in relatively low fuel consumption. The engine as well operates with certain effectively and its fuel consumption does not rise with RPM linearly but slightly progressively (it rises the most between RPM 3500 and 5500).
  • Page 43 If required, the rear fuselage may be anchored by the use of a wide strap placed around the body. It is recommended that a soft, clean pad be placed under the strap to prevent slippage and also prevent scratching and damage to the fuselage. Page 43 of 68...

  • Page 44: Assembly And Disassembly Of The Plane

    6.3. Manipulation with the plane The aircraft is provided with a tow bar which secures to the stub axle of the nose wheel. Due to the low weight of the aircraft, one person can easily manipulate the aircraft using this bar. When the tow bar is unavailable, the aircraft may be handled by: Pushing on the leading edge of the wings within a distance of 2m from the •...
  • Page 45 shift horizontal from front pins direction down • Page 45 of 68...

  • Page 46: Assembly Of The Plane

    6.4.2. Assembly of the plane The assembly of the plane should be performed by to persons in reversed order than the disassembly of the plane. ATTENTION! All self-stop hunts with the nylon rings can be used only once. All metal can be used at maximum 3times after the compression of its cut out from the tongs.
  • Page 47 Once a month or as required, polish the surface of the aircraft and canopy to preserve the finish. Car polish and glass or plastic preservation liquids may be used. Page 47 of 68...
  • Page 48 6.6. Before flight inspection The pre-flight inspection starts on the left side of the cabin and proceeds clockwise. Perform the following inspections prior to each flight: Canopy • check the cleanness • check for damage to seals • check for correct seating •...
  • Page 49 Important Watch for possible rubbed places on pipes, especially at points where they are secured, or at places where they are connected to metallic parts of the engine. If you experience problems with the connection of the carburetor to the engine via the rubber tubing, it may be necessary to modify the attachment in accordance with the engine maintenance handbook.
  • Page 50 • check free movement of ailerons • check fuel cap sealing Right Undercarriage • check symmetry of undercarriage • check wheel cover for damage • check brakes • check for malformation • check for alignment and spacing • check axle securing nuts Right Wheel Tire •...

  • Page 51: Filling The Fuel

    Left wing • the same as the right wing Left Undercarriage • the same as the right undercarriage Left Wheel Tire • as for right wheel tire Interior of the cabin • check the cleanliness • check full and free movement of controls •...

  • Page 52: Service Life Of Airplane And Periodic Maintenance

    • With regards to placing fuel tank neck it is appropriate to use platform or stool (do not lean any kind of platform or ladder on sandwich aircraft skin which could be damaged) • Ensure that all containers and funnels are marked fuel safe •...

  • Page 53: Daily Maintenance

    The propeller should undergo regular inspections as set out by the manufacturer. To prolong the life of the propeller, avoid long grass and stone areas which may damage the leading edge. There is no specified service life of the engine. The engine is subject to review by the Rotax manufacturer after every 1200 hours.

  • Page 54: Ground Handling

    Place Type of lubricant Frequency Front undercarriage leg grease once a year Aileron hinges transmission oil every 50 hours Upper and bottom rudder hinges transmission oil every 50 hours Elevator hinges transmission oil every 50 hours Control linkages transmission oil every 50 hours Aileron hinges transmission oil...
  • Page 55 color. Page 55 of 68...

  • Page 56: Wheel Disassembly Of Main Undercarriage

    7.2.4. Wheel disassembly of main undercarriage The disassembly demands the cooperation of two persons, for assembly prepare the bracket, ensuring wedges and self protecting nut M14. • ensure the second wheel of the main undercarriage by the wedges from both sides •...

  • Page 57: Electrical System Voltage

    7.2.6. Electrical system voltage The aircraft is fitted with a 12V negative earth electrical system. Some of the electrical items, such as the radio, have their own inline fuse however there are no master circuit breakers or fuses installed. Each of the main switches acts as a fuse. Page 57 of 68...

  • Page 58: Tolerance And Setting Up Values

    During normal operation, if the voltage drops when switching using appliances, such as transmitting on the radio or altering the pitch of the propeller, check the battery for corrosion, correct connection and electrolyte level. If the fault remains, check the entire electrical system or refer the problem to an authorized service centre.

  • Page 59: Changing The Fuel Filter In The Engine Area

    7.2.12 Changing the fuel filter in the engine area The fuel filter should be checked regularly to ensure that it is not blocked and replaced as necessary. Due to possible dust and dirt remaining in the fuel tank after construction, the first change of the filter should occur after a maximum of 12 hours operation and then at least every 50 hours.

  • Page 60: Maintenance Of Sr 2000/3000 Woodcomp Propeller

    7.2.13 Maintenance of SR 2000/3000 Woodcomp Propeller A visual inspection of the propeller blades, leading edges, hub and spinner is to be performed every 10 hours. During this inspection, clean the propeller with non abrasive, non-corrosive cleaning agents. 7.3. Warranty Service A warranty service is conducted after 25 hours of service and is performed by an authorized service centre.

  • Page 61: Periodical Revision After Every 200Hours

    7.6. Periodical revision after every 200hours As per the 100 hour inspection, but also the ignition plugs are changed. 7.7. Inspection after every 300hours This revision is made after every 295-305 flight hours or after three years of operating. The diagnostics of all stressed parts of the construction is made and also its detailed range is prescribed by the internal rule of the producer by the detected state.

  • Page 62: List Of Labels And Their Placing

    7.9. List of labels and their placing The following labels may be found on the aircraft: Airframe manufacturer details, including the airframe serial number, are located • on the inner left side of the fuselage behind the pilot’s seat. Aircraft manufacturer’s details are located on the partition behind the passenger •...

  • Page 63: Airframe Repair

    All repairs to the aircraft control systems should be completed by an authorized service person and the aircraft must be test flown by a suitably qualified pilot prior to returning to flight status. 8.4. Airframe repair Minor damage to the surface finish of the aircraft should be cemented, rubbed back and painted.

  • Page 64: Inspection Of Electrical System

    8.8. Inspection of electrical system All cable connections must be checked for security, wear, abnormal damage and corrosion. Replace corroded damaged cables prior flight. Page 64 of 68...

  • Page 65: Engine Rotax 912, 912S And 914 Maintenance

    Indications of wear or damage may include, but are not limited to, corrosive buildup on terminals, melted, loose or broken insulation or disconnected or exposed wires. Ensure that spark plug cables are secured correctly and not loose on the plug. Release of the plug connector can be the reason for burnt or melted cables and improper operation of the engine.

  • Page 66: Refrigerating Liquid

    Fouled or discolored plugs may indicate other engine anomalies such as loose valves, incorrect mixture setting, fouled air filter or incorrect engine operating temperatures. The correct spark plug color should be a light brown. Refer to the engine manufacturer’s handbook for further information. Spark plugs should be replaced every 200 hours or when damage or wear is evident during normal inspections.

  • Page 67: Service Life, Revision And Engine Revisions

    ATTENTION! Do not open the tap of the refrigerating liquid tank in hot state. You can get burnt easily. While letting out the refrigerating liquid it is necessary to open the tap of the tank and screw out the low tightening screw / with the impermeable ring / of the water pump. Then it is necessary to release the low pipe of the cooler of the refrigerating liquid / which is located lower than the engine to let the old refrigerating liquid leak out, after letting it out, put the pipe back on the cooler and tighten the buckle carefully.

  • Page 68: Service Life Of Rubber Parts Of Engine

    Some maintenance tasks to be undertaken at the 100 and 200 hourly maintenance periods may only be undertaken by an authorized technician. We recommend that this servicing be undertaken by the engine manufacturer or his nominated representative. ATTENTION! Engine warranty is subject to the strict adherence to maintenance schedules and operating procedures as prescribed in the engine operations manual and aircraft flight manual.
