  • Page 1 User Manual for your CLH60SLMSS & CLH60SLMW & CLRH60SS & CLRH90SS & CLH600BXSS & CLH900BXSS & CLH9GLSS Cooker Hood NOTE : This User Instruction Manual contains important information, including safety & installation points, which will enable you to get the most out of your appliance. Please keep it...
  • Page 2: Table Of Contents

    CONTENTS YOUR COOKER HOOD’S SPECIFICATIONS ….……………..………….2 IMPORTANT SAFETY INFORMATION……………………………….…3-4 ENVIRONMENTAL NOTE ………….…………………………………………5 USING YOUR COOKER HOOD……………………………...……………6-7 MAINTAINING AND CLEANING YOUR COOKER HOOD ……….8-9 INSTALLATION INSTRUCTIONS ……………………….……...….10-23 TROUBLESHOOTING ……………………………………………24 CONDITIONS OF GUARANTEE……………………………………………25 HT Mod 15/08/09...
  • Page 3: Your Cooker Hood's Specifications

    Please see the installation section of this manual for details. Specifications of your Cooker Hood: Model Width control light Extraction Carbon (CM) capacity filter CLH60SLMSS Slider SF11 switch incandescence CLH60SLMW Slider SF11 switch incandescence CLRH60SS Push button...
  • Page 4: Important Safety Information

    Important Safety Information: Please Read this before installing & using. Any installation work must be DO NOT SET YOUR * NOTE - carried out by a qualified COOKER HOOD LESS THAN electrician or competent person. 750 mm ABOVE YOUR COOKER! The hood must be installed in o When installed between accordance with the installation...
  • Page 5: Important Safety Information

    Important Safety Information: Please Read this before installing & using. from your room, not o Ensure the ducting for steam. the extractor function has the same diameter as o Warning - Always ensure o the outlet hole all the that the cooker hood has way through.
  • Page 6: Environmental Note

    Environmental Note Note : Before discarding an old appliance, switch off and disconnect it from the power supply. Cut off and render any plug useless. Cut the cable off directly behind the appliance to prevent misuse. This should be undertaken by a competent person. CONFORMITY TO W.E.E.E.
  • Page 7: Using Your Cooker Hood

    Using your Cooker Hood: To use your cooker hood: Make sure it has been properly installed. Find the CONTROL PANEL. It is located on the hood’s front surface near the upper right corner of the unit. The CONTROL PANEL contains switches as shown in the Figure below. These perform separate functions.
  • Page 8 *Push button : ‘V’- Motor Off button ‘W’ - Motor operation: = low speed, = mid speed, = high speed. ‘U’ - Light ‘ON/OFF’ button-This button controls the light *Electronic button ‘W’ - Motor operation: = low speed, = mid speed, = high speed.
  • Page 9: Maintaining And Cleaning Your Cooker Hood

    PLEASE NOTE THAT YOUR COOKER HOOD CAN BE USED EITHER IN RECIRCULATION MODE OR IN EXTRACTION MODE. TO USE IN RE-CIRCULATION MODE, YOU WILL NEED TO FIT THE CARBON FOAM. Cleaning your Cooker Hood: Before cleaning, always ensure that you * IMPORTANT: have switched your cooker hood OFF at the omni-polar switch, set at the wall from the cable:...
  • Page 10 Maintenance - Cleaning the Anti-grease Filters To prevent this fire hazard, the grill should be cleaned regularly (depending on use) every 10-15 days and at least every three months in a dishwasher or in hot water with normal washing-up detergent. To clean the grill by hand: First remove the anti- Soak it for about one hour in...
  • Page 11 • NOTE - After carefully rinsing and drying the anti- grease grill, put it back in place. Never put it back in wet! • Never attempt to use your Cooker hood without the grease filter grill in place! Maintenance – Changing the Light Bulb and Carbon Foam Changing the light bulb Before changing the light bulb, ensure that the appliance is not live (i.e., ensure that you have switched it off at the omni-polar switch on...
  • Page 12 Installing / Changing the Carbon Filter Your Cooker Hood uses a CARBON and GREASE Filter to purify the air for the air recirculation function. You will find that one filter will attach over the front of the fan motor (please see figure at bottom of page). The active carbon filter must be replaced regularly, at least once every three months, to allow normal operation.
  • Page 13: Carbon Filter

    Installing / Changing the Carbon Filter. Your Cooker Hood uses a pair of CARBON FILTERS to purify the air for the air recirculation function. You will find that the filters will attach to both sides of the fan motor (please see figures at bottom of page).
  • Page 14 INSTALLATION INSTRUCTIONS - Electrical Before installation and usage, read all the instructions and make sure that the voltage (V) and the frequency (Hz) indicated on the identification plate (found inside your Cooker Hood) and all the data inside the appliance are exactly the same as the voltage and frequency in your home.
  • Page 15: Installation Instructions

    INSTALLATION INSTRUCTIONS – installing your Cooker Hood With the hood installed PLEASE NOTE THAT YOU WILL HAVE TO above a hob, there should DECIDE BEFORE INSTALLING YOUR always be a pot or pan on COOKER HOOD WHETHER YOU WANT IT the hob zone or ring that is AS AN EXTRACTION FAN! THE in use.
  • Page 16 INSTALLATION INSTRUCTIONS – installing your Cooker Hood KITCHEN UNIT / UNDERSIDE OF CABINET INSTALLATION NOTE: Ensure that the grease filter grill has been removed. (E) – Extraction Function only If you are using the top exhaust outlet (meaning that you have plugged the rear one), first cut a hole measuring 130mm in diameter in the floor of the cupboard into which the hood will be...
  • Page 17 8) Position the hood against the wall and mark the position of the support holes that are to be drilled as shown in the figure below. These support holes can be found on Fig. 4 on next page marked as ‘D’ with the anchoring holes marked as ‘E’...
  • Page 18 INSTALLATION INSTRUCTIONS – Attaching the Hood Rear view of your cooker hood. -------------------------------------------------------------------------- 1) Using a drill bit with a 8 mm diameter, make holes in the wall where you have marked these positions (see below). -------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------------- 2) Insert the expansion fixings (raw plugs) in the holes and then screw the support screws halfway in (see below figure, at right).
  • Page 19 INSTALLATION INSTRUCTIONS – Attaching the Hood ------------------------------------------------------------------------------------------- ------------------------------------------------------------------------------------------- 4) (EXTRACTION FUNCTION ONLY) Connect the coupling to the top of the cooker hood (see below). Then connect the discharge pipe to the coupling as shown below. Remember that your ducting will have to match the specifications shown in the notes on Extraction / Air Purifier (Recirculation) Modes on p.18.
  • Page 20 INSTALLATION INSTRUCTIONS – Fitting the Chimney FITTING THE PIPE – Once your Cooker Hood has been installed, you can now fit the pipe. 1) Take the two casings ‘A’ and ‘B’: 2) Rest the bottom of the casing ‘A’ on the top of the hood, taking care to position the tabs of the casing correctly on the back of the hood as shown as part ‘X’...
  • Page 21 INSTALLATION INSTRUCTIONS – Fitting the Chimney 6) Take the fixing bracket ‘G’ (Fig. 4 – previous page), centre it with respect to the mark you previously made, keeping it in contact with the ceiling, and then mark the anchoring holes (‘H’).
  • Page 22 ATTACHING THE GLASS Remove the metal grease filters from the hood Slacken both anchoring screws “F” Place the glass ‘Q’ on the upper shelf of the hood, pushing it in towards the wall. Tightening the screws ‘F’ again in the hole and connecting them to the unit.
  • Page 23 Extraction / Air Purifier Modes of Operation EXTRACTION OPERATION – Installation Instructions Ensure that you have fitted the union (‘N’) to the upper part of the hood using the packaged two screws supplied inside the packing (Fig. 1 – on right). Using a 125 mm diameter pipe, connect the union (N) on the upper part of the hood (see Fig.
  • Page 24 If your Cooker Hood comes with a Lower Bracket * Note on what to do if your Cooker Hood is the version that comes with a BRACKET. Please note that your cooker hood may include a lower bracket. If this is the case, you will need to have it installed as such. This will mean a slight change in how the cooker hood is to be installed from the process shown on page 13.
  • Page 25: Troubleshooting

    Troubleshooting If something has gone wrong with your Cooker Hood, checking against this chart might keep you from having to call for service. Symptom Solution Check that the hood is connected • to the electricity supply. The cooker hood will not start! Check that the fan speed control is •...
  • Page 26 WARRANTY REGISTRATION CARD THIS WARRANTY IS VALID IN NEW ZEALAND ONLY Note: d) damage to surface coatings caused by Please complete the following details when you cleaning or maintenance using products not unpack the product and return the bottom portion of recommended by the owner’s handbook;...
  • Page 27 Affix stamp here Applico Ltd Warranty Department Private Bag 92-900 Onehunga Auckland applico_warranty_card.indd 2 applico_warranty_card.indd 2 19/10/06 4:17:46 PM 19/10/06 4:17:46 PM...
