Trouble shooting guide, SP/ Mechanical
Applicable for T630/T628
Contents:
1
Explanations ....................................................................................................................2
1.1
1.1.1
1.2
1.2.1
2
Appearance Problems.....................................................................................................3
3
Alert Problems ................................................................................................................5
3.1
3.2
4
Audio Problems...............................................................................................................7
4.1
4.2
5
Charging/Capacity..........................................................................................................9
5.1
5.2
6
Data Communication Problems.....................................................................................9
7
Key problem ..................................................................................................................10
7.1
7.2
7.3
8
LCD/Illumination..........................................................................................................13
8.1
8.2
9
Network..........................................................................................................................14
10
On/Off ............................................................................................................................15
10.1
10.2
11
SIM-Problems ...............................................................................................................16
12
Other ..............................................................................................................................17
12.1
13
Software Problems ........................................................................................................18
14
Revision History ............................................................................................................18
4_00021-1/FEA 209 544/84 A
Sony Ericsson Mobile Communications AB
Service functions in the software.......................................................................2
Reset ..................................................................................................................2
Liquid damage ...................................................................................................2
Action ................................................................................................................2
Vibrator .............................................................................................................5
Polyphonic.........................................................................................................5
Earphone problems............................................................................................7
Microphone problems........................................................................................7
Charging ............................................................................................................9
Capacity.............................................................................................................9
Side keys..........................................................................................................10
Keyboard .........................................................................................................10
Joystick ............................................................................................................10
LCD .................................................................................................................13
Illumination .....................................................................................................13
Battery .............................................................................................................15
On/Off key.......................................................................................................15
Camera Problems.............................................................................................17
Trouble Shooting Guide, SP/Mechanical
Approved according to 000 21-LXE 107 42/1
Advertisement
Table of Contents
Related Manuals for Sony Ericsson T630
Summary of Contents for Sony Ericsson T630
-
Page 1: Table Of Contents
Illumination .....................13 Network..........................14 On/Off ..........................15 10.1 Battery ......................15 10.2 On/Off key.......................15 SIM-Problems .......................16 Other ..........................17 12.1 Camera Problems.....................17 Software Problems ......................18 Revision History ......................18 4_00021-1/FEA 209 544/84 A Approved according to 000 21-LXE 107 42/1 Sony Ericsson Mobile Communications AB... -
Page 2: Explanations
Make a general visual inspection for corrosion or oxidation caused by liquid damage. No further action should be taken for a liquid damaged phone. Handle the unit according to local company or GSP directives. 4_00021-1/FEA 209 544/84 A 2(18) Sony Ericsson Mobile Communications AB... -
Page 3: Appearance Problems
Check the camera ring (Fig. 2.5) for scratches and if it fits correctly. Replace it if necessary. If the failure still occurs, handle the unit according to the local company or the GSP directives. Fig. 2.1 Fig. 2.2 Fig. 2.3 4_00021-1/FEA 209 544/84 A 3(18) Sony Ericsson Mobile Communications AB... - Page 4 Trouble Shooting Guide, SP/Mechanical Fig. 2.4 Fig. 2.5 4_00021-1/FEA 209 544/84 A 4(18) Sony Ericsson Mobile Communications AB...
-
Page 5: Alert Problems
Check if the sound channel gasket (Fig. 3.5) is mechanical damaged or dirty. Replace it if necessary. If the failure still occurs, handle the unit according to the local company or the GSP directives. Fig. 3.1 Fig. 3.2 4_00021-1/FEA 209 544/84 A 5(18) Sony Ericsson Mobile Communications AB... - Page 6 Trouble Shooting Guide, SP/Mechanical Fig. 3.3 Fig. 3.4 Fig. 3.5 4_00021-1/FEA 209 544/84 A 6(18) Sony Ericsson Mobile Communications AB...
-
Page 7: Audio Problems
Check if the microphone (Fig. 4.5) is mechanically damaged, dirty or oxidized. Replace it if necessary. If the failure still occurs, handle the unit according to the local company or the GSP directives. Fig. 4.1 Fig. 4.2 4_00021-1/FEA 209 544/84 A 7(18) Sony Ericsson Mobile Communications AB... - Page 8 Trouble Shooting Guide, SP/Mechanical Fig. 4.3 Fig. 4.4 Fig. 4.5 4_00021-1/FEA 209 544/84 A 8(18) Sony Ericsson Mobile Communications AB...
-
Page 9: Charging/Capacity
Replace it if necessary. If the failure still occurs, handle the unit according to the local company or the GSP directives. Fig. 5.1 4_00021-1/FEA 209 544/84 A 9(18) Sony Ericsson Mobile Communications AB... -
Page 10: Key Problem
Check if the joystick button (Fig. 7.7) is mechanical damaged or dirty. Replace it if necessary. Note: When replacing the joystick button remember to replace the joystick dust gasket as well. 4_00021-1/FEA 209 544/84 A 10(18) Sony Ericsson Mobile Communications AB... - Page 11 Trouble Shooting Guide, SP/Mechanical If the failure still occurs, handle the unit according to the local company or the GSP directives. Fig. 7.1 Fig. 7.2 Fig. 7.3 Fig. 7.4 Fig. 7.5 4_00021-1/FEA 209 544/84 A 11(18) Sony Ericsson Mobile Communications AB...
- Page 12 Trouble Shooting Guide, SP/Mechanical Fig. 7.6 Fig. 7.7 4_00021-1/FEA 209 544/84 A 12(18) Sony Ericsson Mobile Communications AB...
-
Page 13: Lcd/Illumination
Remember to store the setting with “SAVE”. If the failure still occurs, handle the unit according to the local company or the GSP directives. Fig. 8.1 Fig. 8.2 Fig. 8.3 4_00021-1/FEA 209 544/84 A 13(18) Sony Ericsson Mobile Communications AB... -
Page 14: Network
Check if the antenna connector (Fig. 9.3) is dirty or oxidized. Clean it if necessary. If the failure still occurs, handle the unit according to the local company or the GSP directives. Fig. 9.1 Fig. 9.2 Fig. 9.3 4_00021-1/FEA 209 544/84 A 14(18) Sony Ericsson Mobile Communications AB... -
Page 15: On/Off
Check if the Power on/off key (Fig. 10.2) is mechanically damaged or dirty. Replace it if necessary. If the failure still occurs, handle the unit according to the local company or the GSP directives. Fig. 10.1 Fig. 10.2 4_00021-1/FEA 209 544/84 A 15(18) Sony Ericsson Mobile Communications AB... -
Page 16: Sim-Problems
Check if the SIM-lock lid (Fig. 11.1) is mechanically damaged, dirty or oxidized. Replace it if necessary. • Check if the SIM-reader (Fig. 11.2) is dirty or oxidized. Clean it if necessary. Fig. 11.1 Fig. 11.2 4_00021-1/FEA 209 544/84 A 16(18) Sony Ericsson Mobile Communications AB... -
Page 17: Other
Replace the camera module if necessary. Note: When replacing the camera module, check if the camera module gasket (Fig. 12.2) is damaged in any way. Replace it if necessary. Fig. 12.1 Fig. 12.2 4_00021-1/FEA 209 544/84 A 17(18) Sony Ericsson Mobile Communications AB... -
Page 18: Software Problems
The Software revision and date will be indicated in the display. If the failure still occurs, handle the unit according to the local company or the GSP directives. 14 Revision History Rev. Date Changes / Comments 2003-11-18 First release 4_00021-1/FEA 209 544/84 A 18(18) Sony Ericsson Mobile Communications AB...
