Plug & Play Harness Installation
PLUG & PLAY C7 CORVETTE HARNESS INSTALLATION:
All connections of the C7 CORVETTE plug and play
installation harness in Corvette vehicles are done at the
HMI module in the drivers kick panel.
Step 1: Access the connectors at the HMI module, see Pic 2
on page 8.
Step 2: Disconnect 16-pin black male connector from the HMI
module.
Step 3: Insert 16-pin black male connector of the
C7 CORVETTE plug‐and‐play harness into the HMI module.
Step 4: Insert previously disconnected factory 16-pin black
male connector into the 16-pin black female connector of the
C7 CORVETTE plug‐and‐play harness.
Step 5: Connect C7 CORVETTE harness to the C7 CORVETTE
video interface.
Step 6: Disconnect BLUE connector from the HMI module.
Step 7: Insert BLUE male connector of the C7 CORVETTE plug
‐and‐play harness into the HMI module.
Step 8: Insert previously disconnected factory BLUE male
connector into the BLUE female connector of the
C7 CORVETTE plug‐and‐play harness.
Step 9: Connect both C7 CORVETTE harness to the
C7 CORVETTE video interface.
