Description

Video Inputs:
HDMI Input: Connect any video source that has HDMI output, most
popular application is smartphone/tablet connection. All iOS Apple device
will require lightning to HDMI adapter made by Apple. Some Android
smartphones have micro HDMI port and some will require MHL adapters,
please refer to your smartphone user manual for correct MHL adapter.
WHEN PLACING THE INTERFACE BEHIND PANELS TAKE CARE TO AVOID ANY PRESSURE
ON THE HDMI CONNECTOR, AS IT MAY BREAK OFF THE BOARD IF TOO MUCH FORCE IS
APPLIED.
Video 1: Composite video input for front camera.
(if installing front camera make sure the camera doesn't not have
reverse image enabled, otherwise left and right view will be
reversed.)
Video 2: Composite video input for an aftermarket back‐up camera.
(we recommend asking customer if they plan to use camera while
driving, in this event you will connect the camera to a +12V
accessory power instead of +12V reverse trigger.
Video 3: Composite video input for left camera.
Video 4: Composite video input for right camera.
Audio Output:
3.5 mm Audio Output Jack: 3.5mm audio jack provides audio output
from connected HDMI source. 3.5mm aux audio jack can be connected to
3.5mm AUX audio jack input of vehicle stereo system.
USB:
Micro USB update port: configuration of features and settings that may
need to be adjusted prior to installation.
USB charger port: provides 2 amp power output.
Plug and Play Harness:
DVI Input: HMI Cable.
DVI Output: HMI Cable.
Plug and Play Harness: 100% plug and play harness for power and
Data for NavTool.
