CNET CWP-906 User Manual

Wireless-n pci adapter
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
User Manual
Wireless-N PCI Adapter
CWP-906
Model:
CNet Technology Inc.
www.CNet.com.tw

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CWP-906 and is the answer not in the manual?

Questions and answers

Related Manuals for CNET CWP-906

Summary of Contents for CNET CWP-906

  • Page 1 User Manual Wireless-N PCI Adapter CWP-906 Model: CNet Technology Inc. www.CNet.com.tw...

  • Page 2: Table Of Contents

    4.2.5.1 Statistics ................41 4.2.6 WMM ........................43 4.2.6.1 WMM .................. 44 4.2.6.2 Example to Configure to Enable DLS ......45 (Direct Link Setup) ................45 4.2.6.3 Example to Configure TO Enable Wi-Fi Multi-Media ... 48 CNet Technology Inc. www.CNet.com.tw...
  • Page 3 Is Failed in Profile ..................75 4.3.4 Example to Configure with WEP on ..............78 4.3.5 Example to Configure with WPA-PSK ............83 4.3.6 Example to Configure with WPA ................ 87 ....................5. Trouble Shooting CNet Technology Inc. www.CNet.com.tw...

  • Page 4: Introduction

    Supports Windows® 2000, XP 32/64, Vista 32/64, Win 7 32/64 Contents of Package One PCI Adapter One Installation CD One dipole antenna Contact your local authorized reseller or the store where you purchased for any items damaged and/or missing. CNet Technology Inc. www.CNet.com.tw...

  • Page 5: Designing Your Pci Adapter

    PCI Adapter supports up to 150 Mbps connections. It is fully compliant with the specifications defined in 802.11n standard The status LED indicators of PCI Card are described in the following.  Link/Act ON (Green): Indicates a valid connection.  Link/Act Flashing: Indicates the Adapter is transmitting or receiving data CNet Technology Inc. www.CNet.com.tw...

  • Page 6: Installation

    PCI Adapter all the way in. after it is firmly in to place, secure its fastening tab to your PC's chassis with a mounting screw. Then close your PC. Attach the external antennas to PCI Adapter's antenna port.\ Power On the PC. Note: Select Cancel button, when “Found New Hardware” window appears. CNet Technology Inc. www.CNet.com.tw...

  • Page 7: Install Driver And Utility

    1. Insert Installation CD to your CD-ROM drive. And click . The wizard will be run and install all necessary files to your computer automatically. 2. Click next to accept the Agreement. Or click Cancel to cancel the installation Click NEXT CNet Technology Inc. www.CNet.com.tw...
  • Page 8 It’s recommended to select Ralink Configuration Tool, which provides fully access to all functions of PCI Adapter. b. If you prefer to use the wireless configuration tool provided by Windows XP or Vista, please select Microsoft Zero Configuration Tool CNet Technology Inc. www.CNet.com.tw...
  • Page 9 5. Click Finish to complete the software installation. CNet Technology Inc. www.CNet.com.tw...

  • Page 10: Utility Config

    If "Use RaConfig as Configuration utility" is selected, please jump to Section 2 on running RaUI. If "Use Zero Configuration as Configuration utility" is selected, please continue. We will explain the difference between RaUI and WZC. Figure 1-3 shows the RaUI status when WZC is activated as the main control utility. CNet Technology Inc. www.CNet.com.tw...
  • Page 11 The profile button will be gray. Profile functionality is removed since the NIC is controlled by WZC. The connection and add profile function will be gray. Profile functionality is removed since the NIC is controlled by WZC. Please read through this document for full details on the other functions provided by RaUI. CNet Technology Inc. www.CNet.com.tw...

  • Page 12: Use Wzc To Configure Wireless Nic

    Figure 1-4 status prompt for no connection 2. Right-click the network connection icon in taskbar Figure 1-5 Select WZC main status 3. Select "View Available Wireless Networks" and the "Wireless Network Connection" dialog box will pop up, as shown in Figure 1-6. CNet Technology Inc. www.CNet.com.tw...
  • Page 13 Figure 1-6 Wireless Network Connection 4. Select the intended access point and click "Connect". Then click "Connect Anyway" as shown as Figure 1-7. Figure 1-7 Select intended AP : AP1, then click "Connect" Figure 1-8 Connect AP: AP1 successfully CNet Technology Inc. www.CNet.com.tw...
  • Page 14 5. If you want to modify information about the AP, click "Change advanced settings" as shown in Figure 1-9. Then select the "Wireless Networks" tab shown as Figure 1-10. Figure 1-9 Click "Change advanced settings" Figure 1-10 Choose the "Wireless Networks" tab CNet Technology Inc. www.CNet.com.tw...
  • Page 15 6. Click "Properties" as shown in Figure 1-11. Then click "OK" button. Figure 1-11 AP's properties 7. After filling in the appropriate value, click "OK." The pop-up will indicate the status. as shown in Figure 1-12. Figure 1-12 Network connection status CNet Technology Inc. www.CNet.com.tw...
  • Page 16 AP will be shown with a blue icon beside it, as shown in Figure 1-13. Users may use the advanced tab to configure more advanced features provided by Ralink's wireless NIC. For details on configuring the advanced features, please check the Advance setting section. Figure 1-13 Show connection status by using WZC to initiate the connection CNet Technology Inc. www.CNet.com.tw...

  • Page 17: Raui

    The arrow icon indicates the connected BSS or IBSS network. The dialog box is shown in Figure 2-1. Figure 2-1-1 RaUI section introduction There are three sections to the RaUI dialog box. These sections are briefly described as follow. CNet Technology Inc. www.CNet.com.tw...
  • Page 18 Figure 2-1-2 Button section Figure 2-1-3 Move to the left Figure 2-1-4 Move to the right 2. Function Section: Appears to present information and options related to the button. Figure 2-1-5 Profile page Figure 2-1-6 Network page CNet Technology Inc. www.CNet.com.tw...
  • Page 19 Figure 2-1-7 Advance page Figure 2-1-8 Statistics page Figure 2-1-9 WMM page CNet Technology Inc. www.CNet.com.tw...
  • Page 20 Figure 2-1-10 WPS page Figure 2-1-11 About page 3. Status Section: This section includes information about the link status, authentication status, AP's information and con- figuration, and retrying the connection when authentication is failed. Figure 2-1-12 Link Status CNet Technology Inc. www.CNet.com.tw...
  • Page 21 Figure 2-1-13 Authentication Status Figure 2-1-14 AP's Information Figure 2-1-15 Retry the connection CNet Technology Inc. www.CNet.com.tw...
  • Page 22 : Indicates the connected and signal strength is normal. : Indicates that it is not yet connected. : Indicates that a wireless NIC can not be detected. : Indicates that the connection and signal strength is weak. CNet Technology Inc. www.CNet.com.tw...

  • Page 23: Profile

    10. RTS Threshold: Users can adjust the RTS threshold number by sliding the bar or keying in the value directly. 11. Fragment Threshold: The user can adjust the Fragment threshold number by sliding the bar or key in the value directly. CNet Technology Inc. www.CNet.com.tw...
  • Page 24 : Click to add a new profile. : Click to edit an existing profile. : Deletes an existing profile. : Activates the selected profile. : Shows information of the related status section. : Hides information of the related status section. CNet Technology Inc. www.CNet.com.tw...

  • Page 25: Add/Edit Profile

    7. Channel: Only available for setting under Ad-hoc mode. Users can choose the channel frequency to start their Ad-hoc network. Authentication Type: There are 7 type of authentication modes supported by RaUI. They are open, Shared, LEAP, WPA and WPA-PSK, WPA2 and WPA2-PSK. CNet Technology Inc. www.CNet.com.tw...

  • Page 26: Example On Adding Profile In Network

    2. Hexadecimal - 128bits : 26Hex characters. 3. ASCII - 40bits : 5 ASCII characters. 4. ASCII - 128bits : 13 ASCII characters 4.2.2.3 Example on Adding Profile in Network Click "Add" below the Profile List. CNet Technology Inc. www.CNet.com.tw...
  • Page 27 The "Add Profile" will appear. CNet Technology Inc. www.CNet.com.tw...
  • Page 28 Specify a Profile Name. Select an AP from the SSID drop-down list. The AP list is from the last Net- work. CNet Technology Inc. www.CNet.com.tw...
  • Page 29 Now the profile which the user set appears in the profile list. Click "Activate". CNet Technology Inc. www.CNet.com.tw...

  • Page 30: Network

    : Indicates the network type is in infrastructure mode. : Indicates the network type is in Ad-hoc mode. Indicate that the wireless network is security - enabled. : Indicates 802.11a wireless mode. : Indicates 802.11b wireless mode : Indicates 802.11g wireless mode. CNet Technology Inc. www.CNet.com.tw...
  • Page 31 3. If the intended network uses encryption other than "Not Use," RaUI will bring up the security page and let the user in- put the appropriate information to make the connection. Please refer to the example on how to fill in the security informa- tion CNet Technology Inc. www.CNet.com.tw...
  • Page 32 A. General information contains the AP's SSID, MAC address, authentication type, encryption type, channel, network type, beacon interval, signal strength and supported rates. It is shown in Figure 2-3-1-2. Figure 2-3-1-2 General information about the Access Point CNet Technology Inc. www.CNet.com.tw...
  • Page 33 9. UUID-E: The universally unique identifier (UUID) element generated by the Enrollee. The value is 16 bytes. 10. RF Bands: Indicates all of the RF bands available to the AP. A dual-band AP must provide it. The values are CNet Technology Inc. www.CNet.com.tw...
  • Page 34 "2.4GHz" and "5GHz". Figure 2-3-1-3 WPS Detailed information about the AP CNet Technology Inc. www.CNet.com.tw...
  • Page 35 CCX information contains the CCKM, Cmic and Ckip information. It is shown in Figure 2-3-1-4. Figure 2-3-1-4 CCX information about AP's detail information CNet Technology Inc. www.CNet.com.tw...
  • Page 36 802.11n information contains some related 802.11n information. It is shown in Figure 2-3-1-5. Figure 2-3-1-5 802.11n information CNet Technology Inc. www.CNet.com.tw...

  • Page 37: Example On Adding Profile In Network

    4.2.3.2 Example on Adding Profile in Network 1. Select the AP from the list on the Network tab CNet Technology Inc. www.CNet.com.tw...
  • Page 38 2. Click "Add to Profile" CNet Technology Inc. www.CNet.com.tw...
  • Page 39 3. The System section will appear at the bottom of the Add Profile window. You can specify your own profile name CNet Technology Inc. www.CNet.com.tw...
  • Page 40 4. Next, you will see the new profile in the profile list. Click "Activate" CNet Technology Inc. www.CNet.com.tw...

  • Page 41: Advanced

    4.2.5.1 Statistics The Statistics page displays detailed counter information based on 802.11 MIB counters. This page translates that MIB counters into a format easier for the user to understand. Figure 2-5-1 shows the detailed page layout. CNet Technology Inc. www.CNet.com.tw...
  • Page 42 3. RTS Frames Successfully Receive CTS: Successfully receive CTS after sending RTS frame. 4. RTS Frames Fail To Receive CTS: Failed to receive CTS after sending RTS. 5. Frames Retransmitted Successfully: Successfully retransmitted frames numbers. 6. Reset counters to zero. CNet Technology Inc. www.CNet.com.tw...
  • Page 43 2. Frames Received With CRC Error: The number of frames received with a CRC error. 3. Frames Dropped Due To Out-of-Resource: The number of frames dropped due to a resource issue. 4. Duplicate Frames Received: The number of duplicate frames received. 5. Reset all the counters to zero. CNet Technology Inc. www.CNet.com.tw...

  • Page 44: Wmm

    1. WMM Enable: Enable Wi-Fi Multi-Media. The setting method follows Section 2-6-2. 2. WMM - Power Save Enable: Enable WMM Power Save. The setting method follows Section 2-6-3. 3. Direct Link Setup Enable: Enable DLS (Direct Link Setup). The setting method follows Section 2-6-4. CNet Technology Inc. www.CNet.com.tw...

  • Page 45: Example To Configure To Enable Dls

    1. Click the "Direct Link Setup Enable" checkbox 2. Change to "Network" function. Add an AP that supports DLS features to the profile. The result will look like the Pro- file Page in the figure below. CNet Technology Inc. www.CNet.com.tw...
  • Page 46 2. The Timeout Value indicates the time in seconds before it disconnects automatically. The value is an integer. The integer must be between 0~65535. A zero value specifies that it stays connected. The default Timeout Value is 60 seconds. CNet Technology Inc. www.CNet.com.tw...
  • Page 47 "DLS Status" on the opposite side, the user’s local MAC address and Timeout Value are displayed. b. Display the values of "DLS Status" to "Direct Link Setup" as follow: 1. In "DLS Status" select a direct link STA what you want to show it's values in "Direct Link Setup". CNet Technology Inc. www.CNet.com.tw...
  • Page 48 2. Double click. And the result will look like the below figure. c. Disconnect Direct Link Setup as follow: 1. Select a direct link STA. 2. Click "Tear Down" button. The result will look like the below figure. CNet Technology Inc. www.CNet.com.tw...

  • Page 49: Example To Configure To Enable Wi-Fi Multi-Media

    WMM indicates as follows: 1. Click "WMM Enable". 2. Change to "Network" function. And add an AP that supports WMM features to a Profile. The result will look like the below figure in Profile page. CNet Technology Inc. www.CNet.com.tw...

  • Page 50: Example To Configure To Enable Wmm-Power Save

    4.2.6.4 Example to Configure TO Enable WMM-Power Save 1. Click "WMM-Power Save Enable". 2. Please select which ACs you want to enable. The setting of enabling WMM Power Save is successfully. CNet Technology Inc. www.CNet.com.tw...

  • Page 51: Wps

    UUID-E and RF Bands. Further details are available here: WPS Information on AP. 5. PIN Code: The user is required to enter an 8-digit PIN Code into Registrar. When an STA is the Enrollee, you can click "Renew" to re-generate a new PIN Code. CNet Technology Inc. www.CNet.com.tw...
  • Page 52 15. Automatically select the AP: Starts to add to AP by using to select the AP automatically in PIN method. **There are examples in section 2-7-3 (PIN Enrollee Setup), section 2-7-4(PBC Enrollee Setup) and section 2-7-5 (Registrar Configures and AP) ** CNet Technology Inc. www.CNet.com.tw...

  • Page 53: Wps Information On Ap

    WPA system. 2. Encryption Type: For open and shared authentication mode, the selection of encryption type are none and WEP. For WPA, WPA2, WPA-PSK and WPA2-PSKauthentication mode, the encryption type supports both TKIP and AES. CNet Technology Inc. www.CNet.com.tw...
  • Page 54 8. UUID-E: The universally unique identifier (UUID) element generated by the Enrollee. This is a 16 byte value. 9. RF Bands: Indicates all the RF bands available on the AP. A dual-band AP must 10. Provide it. The values are "2.4GHz" and "5GHz". CNet Technology Inc. www.CNet.com.tw...

  • Page 55: Example To Add To Registrar Using Pin Method

    The user obtains a device password (PIN Code) from the STA and enters the password into the Regi- strar. Both the Enrollee and the Registrar use PIN Config method for the configuration setup. The fol- lowing image outlines the process. 1. Select "Enrollee" from the Config Mode drop-down list. CNet Technology Inc. www.CNet.com.tw...
  • Page 56 2. Click "Rescan" to update available WPS APs. 3. Select an AP (SSID/BSSID) that STA will join to. CNet Technology Inc. www.CNet.com.tw...
  • Page 57 STA first. After that, search out your WPS Device name and MAC address at Microsoft Regi- strar. Add a new device and enter PIN Code of STA at Microsoft Registrar when prompted. 6. The result should appear as the image below. CNet Technology Inc. www.CNet.com.tw...
  • Page 58 7. Configure one or more credentials 8. Then connect successfully. The result appears as the following image. 9. Click "Detail" CNet Technology Inc. www.CNet.com.tw...
  • Page 59 -> Received M2 -> (Received M2D -> Sending EAP-Rsp (ACK)) -> Sending M3 -> Received M4 -> Sending M5 -> Received M6 -> Sending M7 -> Received M8 -> Sending EAP-Rsp(Done) -> Configured -> WPS status is disconnected -> WPS status is connected successfully-SSID CNet Technology Inc. www.CNet.com.tw...

  • Page 60: Example To Add To Registrar Using Pbc Method

    If the Enrollee discovers more than one Registrar in PBC mode, it MUST abort its connection attempt at this scan and con- tinue searching until the two-minute timeout. *Before you press PBC on STA and candidate AP. Make sure all APs aren't PBC Mode or APs using PBC mode have left their Walk Time. CNet Technology Inc. www.CNet.com.tw...
  • Page 61 2. Click PBC to start the PBC connection. 3. Push the PBC on AP. *Allow time for an exchange between Step 2 and Step 3. 4. The progress bar as shown in the figure below indicates that scanning progress CNet Technology Inc. www.CNet.com.tw...
  • Page 62 CNet Technology Inc. www.CNet.com.tw...
  • Page 63 5. When one AP is found, join it. 6. Check WPS Information on the available WPS APs. 7. Configure and receive one or more credential(s). CNet Technology Inc. www.CNet.com.tw...
  • Page 64 3. Too Many PBC AP available : Scanning AP -> Too Many PBC AP available -> Scanning AP -> Too Many PBC AP available -> 4. WPS configuration doesn't complete after two-minute connection WPS Eap process failed. CNet Technology Inc. www.CNet.com.tw...
  • Page 65 AP1 is a G-Band AP using PBC mode. (ID = 0x0004) AP2 is a G-Band AP using PBC mode. (ID = 0x0004) They have the different UUID-E. STA would regard these two APs as two different APs and wait until only one PBC AP is available. CNet Technology Inc. www.CNet.com.tw...

  • Page 66: Example To Configure A Network/Ap Using Pin Or Pbc Method

    4.2.7.5 Example to Configure a Network/AP using PIN or PBC Method 1. Select Registrar from the Config Mode drop-down list. CNet Technology Inc. www.CNet.com.tw...
  • Page 67 2. Enter the details of the credential and change configurations (SSID, Authentication, Encryption and Key) manually if needed. 3. If the PIN configuration is setup, enter the PIN sent from the Enrollee. Start CNet Technology Inc. www.CNet.com.tw...

  • Page 68: About

    Receive EAP Rsp (Done) ->Sending EAP Rsp (ACK) -> Configured -> WPS status is disconnected -> WPS tatus is connected uccessfully-SSID 4.2.8 About 4.2.8.1 About Click "About" displays the wireless card and driver version information as shown in Figure 2-8. CNet Technology Inc. www.CNet.com.tw...
  • Page 69 Figure 2-8 about function 1. Connect to Ralink's website: Ralink Technology, Corp. 2. Display Configuration Utility, Driver, and EEPROM version information. 3. Display Wireless NIC MAC address. CNet Technology Inc. www.CNet.com.tw...

  • Page 70: Link Status

    13. Signal Strength 1~3: Receive signal strength 1~3, user can choose to display as percentage or dBm format. 14. Noise Strength: Display noise signal strength. 15. HT: Display current HT status in use, containing BW, GI, MCS, SNR0, and SNR1 value. (Show the information only for 802.11n wireless card. ) CNet Technology Inc. www.CNet.com.tw...

  • Page 71: Security

    5. WEP Key: Only valid when using WEP encryption algorithm. The key must match the AP's key. There are several formats to enter the keys. a. Hexadecimal - 40bits: 10 Hex characters. b. Hexadecimal - 128bits: 32Hex characters. c. ASCII - 40bits: 5 ASCII characters. d. ASCII - 128bits: 13 ASCII characters CNet Technology Inc. www.CNet.com.tw...

  • Page 72: Setting

    Session Resumption: The user can choose "Disable" and "Enable". Tunnel Authentication: a. Protocol: Tunnel protocol, List information include "EAP-MSCHAP v2", "EAPTLS/Smart card", "Generic Token Card", "CHAP", "MS-CHAP", "MS-CHAP-V2","PAP" and "EAP-MD5". b. Tunnel Identity: Identity for tunnel. c. Tunnel Password: Password for tunnel. CNet Technology Inc. www.CNet.com.tw...

  • Page 73: Client Certification

    Only "EAP-FAST" and "LEAP" authentication can key in domain name. Domain names can be keyed in the blank space. 2. Tunnel ID/Password: Identity and Password for the server Client Certification Use Client certificate: Client certificate for server authentication. CNet Technology Inc. www.CNet.com.tw...
  • Page 74 1. Certificate issuer: Select the server that issues the certificate. 2. Allow intermediate certificates: It must be in the server certificate chain between the server certificate and the server specified in the "certificate issuer must be" field. 3. Server name: Enter an authentication sever root. CNet Technology Inc. www.CNet.com.tw...

  • Page 75: Example To Reconnect 802.1X Authenticated Connectiom After 802.1X Authenticated Connection Is Failed In Profile

    1. Authentication type chooses "PEAP", key identity into test. Tunnel Protocol is "EAP-MSCHAP-v2, the tunnel identity and tunnel password are tested. Those settings are the same as our intended AP's setting. 2. Because of keying identity and password errors, the result will appear as in the image below. CNet Technology Inc. www.CNet.com.tw...
  • Page 76 The tunnel identity is wpatest2 and the tunnel password is test2. Those setting are the same as our intended AP's setting. 4. Click "OK". If it worked perfectly and the result will appear as the image below. CNet Technology Inc. www.CNet.com.tw...
  • Page 77 1. Choose "PEAP" as the Authentication type and key-in "wpatest2" as the identity .Tunnel Protocol is "EAP-MSCHAP-v2, and the tunnel identity is "wpatest2". The tunnel password is "test2". These settings are the same as our intended AP's setting. 2. When a "Timeout" occurs, The following dialog box will be displayed; CNet Technology Inc. www.CNet.com.tw...
  • Page 78 3. If it has connected successfully, the dialog box will appear as follows; CNet Technology Inc. www.CNet.com.tw...

  • Page 79: Example To Configure With Wep On

    4.3.4 Example to Configure with WEP on 1. Select an AP with WEP encryption and click "Connect". CNet Technology Inc. www.CNet.com.tw...
  • Page 80 2. The Auth.\Encry. function will appear as below CNet Technology Inc. www.CNet.com.tw...
  • Page 81 3. Enter 1234567890 in the Key#1 Hexadecimal field. This value is same as our intended AP's setting. CNet Technology Inc. www.CNet.com.tw...
  • Page 82 4. Click "OK". The dialog box will appear as below; CNet Technology Inc. www.CNet.com.tw...

  • Page 83: Example To Configure With Wpa-Psk

    4.3.5 Example to Configure with WPA-PSK 1. Select the AP with a WPA-PSK authentication mode and click "Connect". CNet Technology Inc. www.CNet.com.tw...
  • Page 84 2. Auth.\ Encry. function appears. CNet Technology Inc. www.CNet.com.tw...
  • Page 85 3. Select WPA-PSK as the Authentication Type. Select TKIP or AES encryption. Enter the WPA Pre-Shared Key as "12345678". CNet Technology Inc. www.CNet.com.tw...
  • Page 86 WPA Pre-Shared Key entered is not correct, you won’t be able to exchange any data 4. Click "OK". Be careful, frames, even though the AP can be connected. CNet Technology Inc. www.CNet.com.tw...

  • Page 87: Example To Configure With Wpa

    4.3.6 Example to Configure with WPA 1. Select an AP with WPA authentication mode and click "Connect". CNet Technology Inc. www.CNet.com.tw...
  • Page 88 2. The Auth.\ Encry. Function pop up. (If AP setup security to Both (TKIP + AES), system defines is AES that security is severely.) CNet Technology Inc. www.CNet.com.tw...
  • Page 89 3. Click "8021X" and the setting page will appear. CNet Technology Inc. www.CNet.com.tw...
  • Page 90 1. Select "PEAP" as the Authentication type from the drop-down list. Key-in "wpatest2" for the identity. "Select "EAP-MSCHAP v2" from the drop-down list for tunnel authentication and key-in the tunnel identity as "wpatest2" and the tunnel password as "test2". These settings are the same as our intended AP's setting. CNet Technology Inc. www.CNet.com.tw...
  • Page 91 2. Click OK. The dialog box should appear as below. *If you want to disconnect, please click cancel button in Authentication Status function. *In Profile function, show "Profile Name" option only in adding AP to Profile function. CNet Technology Inc. www.CNet.com.tw...
  • Page 92 3. If the connection is successful, the dialog will appear as below. CNet Technology Inc. www.CNet.com.tw...
  • Page 93 TLS / Smart Card : 1. "Select TLS / Smart Card" from the Authentication type drop-down list. TLS only requires the identification to be set as "wpatest2" for server uthentication. CNet Technology Inc. www.CNet.com.tw...
  • Page 94 2. TLS must use client certification. Click "Client Certification" and select a certification for server authentication. CNet Technology Inc. www.CNet.com.tw...
  • Page 95 3. Click "OK". The dialog box should appear as the image belo *If you want to disconnect, please click "Cancel" on the Authentication Status function page. *In Profile function, show "Profile Name" option only in adding AP to Profile function. CNet Technology Inc. www.CNet.com.tw...
  • Page 96 4. If it connected successfully, the result will appear as in the image below. CNet Technology Inc. www.CNet.com.tw...
  • Page 97 1. Select TTLS from the Authentication type drop-down list. Key-in the identity as "wpatest2". Select CHAP for tunnel authentication, and key-in the identity as "wpatest2" and tunnel password as "test2". These settings are the same as our in- tended AP's setting. CNet Technology Inc. www.CNet.com.tw...
  • Page 98 2. Click "OK". The dialog box should appear as the image below. *If you want to disconnect, please click "Cancel" on the Authentication Status function page. *In Profile function, show "Profile Name" option only in adding AP to Profile function. CNet Technology Inc. www.CNet.com.tw...
  • Page 99 3. If the connection is successful, the dialog box will appear as the image below. CNet Technology Inc. www.CNet.com.tw...
  • Page 100 1. Select EAP-FAST from the Authentication type drop-down list. Key-in the identity as "wpatest2" and a domain name into the blank field. Tunnel Protocol only supports "Generic Token Card" now. The tunnel identity is "wpatest2" and pass- word is "test2". These setting are the same as our intended AP's setting. CNet Technology Inc. www.CNet.com.tw...
  • Page 101 2. Click "OK". The dialog box should appear as the image below CNet Technology Inc. www.CNet.com.tw...
  • Page 102 3. If the connection is successful, the dialog box will appear as the image below. *If you want to disconnect, please click "Cancel" on the Authentication Status function page. *In Profile function, show "Profile Name" option only in adding AP to Profile function. CNet Technology Inc. www.CNet.com.tw...

  • Page 103: Trouble Shooting

    BSSs being established, rather than a single BSS with multiple clients associated to it. Check that the Network Connection for the wireless client is configured properly. If Security is enabled, make sure that the correct encryption keys are entered on both PCI Adapter and the access point. CNet Technology Inc. www.CNet.com.tw...
