EarthCore ISF-SBVT24VE(N,P) Installation & Owner's Manual

Stadium burner vented systems

Advertisement

Quick Links

Burner Systems:
ISF-SBVT24/30VE(N,P)
ISF-SBVT36/39VE(N,P)
Regulated burner
system for use with
propane or natural gas
WARNING
If the information in this manual is not
followed exactly, a fire or explosion
may result, causing property damage,
personal injury, or loss of life.
Do not store or use gasoline or other
flammable vapors and liquids in the
vicinity of this or any other appliance.
WHAT TO DO IF YOU SMELL GAS:
• Open a window.
• Do not try to light any appliance.
• Do not touch any electrical switch; do
not use any phone in the building.
• Immediately call the gas supplier
from a neighbor's phone. Follow gas
supplier's instructions.
• If you cannot reach the gas supplier,
call the fi re department.
Installation and service must be performed
by a qualified professional installer,
service agency, or the gas supplier.
This appliance is only for use with the type
of gas indicated on the rating plate.
EARTHCORE INDUSTRIES, LLC. • 6899 Phillips Industrial Blvd • Jacksonville, FL 32256
REV 0 - 1706060745
STADIUM BURNER VENTED SYSTEMS
Leave this manual with the appliance.
Retain this manual for future reference.
IMPORTANT: READ THESE INSTRUCTIONS
CAREFULLY BEFORE STARTING
INSTALLATION OF THE UNIT.
The ISOFLAMES burner system is to be installed only
in a solid-fuel burning fi replace with a working fl ue and
constructed of noncombustible material. The installation,
including provisions for combustion and ventilation air
must conform with the National Fuel Gas Code, ANSI
Z223.1/NFPA 54, or the CSA B149.1, Natural Gas
and Propane Installation Code, and applicable local
building codes.
A damper clamp is included to maintain the minimum
permanent vent opening and to prevent full closure
of the damper blade. The chimney damper MUST
be fully opened when burning the unit. The unit is
designed to burn with yellow fl ames; thus adequate
ventilation is absolutely necessary.
To comply with certification, listings, and building
code acceptances, and for safe operation and
proper performance of this burner system, use ONLY
ISOFLAMES parts and accessories. Use of other
controls, parts, and accessories that are not designed
for use with ISOFLAMES burner systems is prohibited
and will void all warranties, certifi cations, listings, and
building code approvals, and may cause property
damage, personal injury, or loss of life. Earthcore will
not be liable for any damages caused by this misuse.
*Note: Solid-fuels shall not be burned in a fi replace
where a decorative appliance is installed.
INSTALLER:
CONSUMER:
1
INSTALLATION &
OWNER'S MANUAL
DESIGN CERTIFIED
to
Vented Decorative Appliance
ANSI Z21.60-2012
CSA 2.26-2012
FOR INSTALLATION IN
SOLID-FUEL BURNING
FIREPLACES*
12-086
L-A2-420

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ISF-SBVT24VE(N,P) and is the answer not in the manual?

Questions and answers

Summary of Contents for EarthCore ISF-SBVT24VE(N,P)

  • Page 1 *Note: Solid-fuels shall not be burned in a fi replace where a decorative appliance is installed. INSTALLER: Leave this manual with the appliance. CONSUMER: Retain this manual for future reference. 12-086 EARTHCORE INDUSTRIES, LLC. • 6899 Phillips Industrial Blvd • Jacksonville, FL 32256 REV 0 - 1706060745 L-A2-420...
  • Page 2 Earthcore ne sera pas responsable des dommages causés par ce détournement. *Note: des Plein-carburants ne seront pas brûlés dans une cheminée où un appareil décoratif 12-086 est installé. EARTHCORE INDUSTRIES, LLC. • 6899 Phillips Industrial Blvd • Jacksonville, FL 32256 REV 0 - 1706060745 L-A2-420...
  • Page 3: Table Of Contents

    TABLE OF CONTENTS GETTING STARTED ........... IMPORTANT PRE-INSTALLATION AND FIREPLACE SAFETY INFORMATION ..................FIREPLACE OPERATING SAFETY INFORMATION ............................SPECIFICATIONS ......................DAMPER CLAMP INSTRUCTIONS ........................... BURNER PARTS LIST INSTALLATION ............................INSTALLATION .......................... BURNER INSTALLATION ............................LIGHTING TEST ..........................LOG SET PLACEMENT ......................
  • Page 4 L'INFORMATION DE SÛRETÉ IMPORTANTE DE PRÉINSTALLATION ET DE CHEMINÉE ATTENTION: L'installation et la réparation doivent être faites par un NFI certifi é ou tout autre installateur professionnel qualifi é. Installateur: Lisez soigneusement ces instructions avant d'installer ce système de brûleur à gaz. Soyez sûr que vous comprenez tous les mesures de sécurité...
  • Page 5: Important Pre-Installation And Fireplace Safety Information

    IMPORTANT PRE-INSTALLATION AND FIREPLACE SAFETY INFORMATION CAUTION: Installation and repair must be done by an NFI Certifi ed or other qualifi ed professional installer. Installer: Carefully read these instructions before installing this gas burner system. Be sure you understand all safety precautions and warnings contained in this manual. A.
  • Page 6 INFORMATIONS SUR LA SÉCURITÉ D'EXPLOITATION DE CHEMINÉE A. Adultes doivent être présents lors de cet appareil au gaz est en marche. Cette unité ne doit pas être laissé sans surveillance ou brûlure lorsque tout quelqu'un dort. B. Gardez le domaine du clair réglé de notation de gaz et libérez des matériaux combustibles, l'essence, et d'autres vapeurs et liquides infl...
  • Page 7: Fireplace Operating Safety Information

    FIREPLACE OPERATING SAFETY INFORMATION A. Adults shall be present when this gas appliance is operating. This unit shall not be left burning when unattended or while anyone is sleeping. B. Keep the area of the gas burner system clear and free from combustible materials, gasoline, and other fl ammable vapors and liquids.
  • Page 8: Specifications

    SPECIFICATIONS ISOFLAMES gas burner systems must be installed only in a wood burning fi replace with the minimum fi rebox dimensions and venting requirements met (see table on this page). This appliance is designed to burn with yellow fl ames; adequate ventilation is absolutely necessary. Product Specifi...
  • Page 9: Wiring Diagram

    SPECIFICATIONS (cont.) WIRING DIAGRAM Pilot assembly Insulated copper Black Main wire Copper Green harness White (Main gas out) Black Orange (GND) Pilot G a s (Pilot gas out) Main inlet Ignition Step motor Valve main fl ame module Battery Main fl ame pack step output Black...
  • Page 10: Damper Clamp Instructions

    DAMPER CLAMP INSTRUCTIONS The damper clamp with hex bolt (Fig. 10-1) is provided as a means to prevent full closure of the damper blade. The clamp is Set screw easily attached to most damper blades with pliers or a wrench, and must be permanently installed.
  • Page 11: Burner Parts List

    BURNER PARTS LIST Thermocouple Pilot Electrode Flash tube Remote transmitter and switch box batteries included with burner system. 24/30 burner model shown Note: Photos not to scale Replacement parts can be ordered from your local ISOFLAMES dealer. The log set is purchased and packaged separately;...
  • Page 12: Installation

    INSTALLATION The ISOFLAMES burner system must be installed by a qualifi ed professional service technician. Instructions must be followed carefully to ensure proper performance and full benefi t from the burner system. Check to be sure the burner system is designed and labeled for the type of gas (natural or propane gas) supplied to the fi...
  • Page 13: Lighting Test

    INSTALLATION (cont.) Place the decorative heat shield over the switch box as Must rest on fl oor and at rear corner shown in Fig. 13-1. LIGHTING TEST Prior to proceeding with installation, perform a lighting test (see lighting instructions for lighting your burner). Allow the unit to completely cool after testing.
  • Page 14: Log Set Placement

    INSTALLATION (cont.) LOG SET PLACEMENT • Follow the instructions included with the log set for step by step log placement. • Read all safety warnings and important information in the instructions supplied with the log set to ensure proper placement. •...
  • Page 15: Installing/Replacing Batteries

    INSTALLING/REPLACING BATTERIES CAUTION: Ensure the unit is connected to the gas line and has been tested for leaks before you insert batteries. CAUTION: Turn off the remote and/or burner and allow the unit to completely cool prior to any battery replacements. Important: Prior to inserting batteries, always apply a small Remove amount of dielectric grease to both ends of each...
  • Page 16: Notes Page

    NOTES PAGE Please use this page to record any information that you may want to have at hand.
  • Page 17: Lighting Instructions

    LIGHTING INSTRUCTIONS FOR YOUR SAFETY, READ BEFORE LIGHTING WARNING: If you do not follow these instructions exactly, a fi re or explosion may result causing property damage, personal injury or loss of life. A. This appliance is equipped with an ignition device that automatically lights the pilot. DO NOT attempt to light the pilot by hand.
  • Page 18 INSTRUCTIONS D'ALLUMAGE POUR VOTRE SÉCURITÉ LISEZ AVANT D'ALLUMER AVERTISSEMENT: Si vous ne suivez pas ces instructions à la lettre, un incendie ou une explosion entraînant des dommages matériels, des blessures ou des pertes de vie. A. Cet appareil est équipé d'un dispositif d'allumage qui allume automatiquement la veilleuse. NE PAS essayer d'allumer la veilleuse manuellement.
  • Page 19: Manual Lighting

    LIGHTING INSTRUCTIONS (cont.) MANUAL LIGHTING Remote receiver CAUTION: DO NOT attempt to light the pilot by hand. 1. Locate the OFF/REMOTE slide actuator on the left rear of the burner. Slide the actuator to the left / OFF position. See Fig. 19-1. 2.
  • Page 20 INSTRUCTIONS D'ALLUMAGE (cont.) ALLUMAGE MANUEL récepteur à distance ATTENTION: NE PAS essayer d'allumer la veilleuse manuellement. 1. Localisez actionneur coulissant OFF/REMOTE sur le côté gauche du brûleur. Glisser le servomoteur sur la position gauche / OFF. Voir Fig. 20-1. 2. Repérez l'interrupteur ON/OFF sur le devant de la boîte de commutation.
  • Page 21: Remote Operating Instructions

    REMOTE OPERATING INSTRUCTIONS ORIENTATION Prior to remote transmitter use, light the appliance per the Signal REMOTE LIGHTING section. The remote transmitter will only light operate the unit when it is in the remote mode. Familiarize yourself with the transmitter buttons, as illustrated in Fig. 21-1. button Identify the four transmitter buttons (used with this system): •...
  • Page 22 MODE D'EMPLOI À DISTANCE ORIENTATION Avant la première utilisation télécommande, allumez l'appareil Feu de pour la section d'éclairage à distance. La télécommande signalisation ne fonctionne que l'appareil quand il est en mode distant. (sur) Familiarisez-vous avec les touches de l'émetteur, comme touche illustré...
  • Page 23: Cleaning And Servicing

    CLEANING AND SERVICING Note: Servicing may be necessary to ensure proper pilot operation and proper burn characteristics. Always shut off the gas to the appliance while performing service work. Allow the appliance to cool before servicing. Installation, service, and repair must be done by an NFI Certifi ed or other qualifi ed professional service technician.
  • Page 24: Syncing The Remote System

    CLEANING AND SERVICING (cont.) SYNCING THE REMOTE SYSTEM Note: Syncing the remote system will cause the burner (rear of burner assy) to ignite. Control module Ensure the burner system is off and completely cool. The remote receiver (found on the rear of the burner assembly) has a sync button (see Fig.
  • Page 25: Troubleshooting

    TROUBLESHOOTING POSSIBLE CAUSE SOLUTIONS BURNER SHUTTING DOWN DURING OPERATION A. Insuffi cient or excessive gas A1. Check gas pressure (Read D.- F. of IMPORTANT PRE-INSTALLATION AND pressure FIREPLACE SAFETY INFORMATION section, & check with local gas company). A2. Other gas appliances may be on the same gas line, dropping gas pressure to log set.
  • Page 26 TROUBLESHOOTING (Cont.) POSSIBLE CAUSE SOLUTIONS SOOTING A. On logs, in fi rebox, or room A. Check gas pressure (see Section 1, A1 of this table). B. Drafts in room B. Eliminate drafts by closing heating and air conditioning vents, returns, and outside air vents. Fans blowing directly into fi...
  • Page 27: Customer Service & Warranty

    Earthcore Industries, LLC authorized dealer or call us directly at 800 642-2920. It is important for you to register your ISOFLAMES gas log system with Earthcore. Please complete the warranty card included in this manual on the following page.
  • Page 28: Warranty Card

    WARRANTY CARD Please cut along dashed lines and send to: Earthcore Industries, LLC 6899 Phillips Industrial Blvd. Jacksonville, Fl 32256 Attn: Technical Department Warranty Card Date of Purchase: _________________________________________________________________ Name: _________________________________________________________________________ Address: _______________________________________________________________________ City, State: ______________________________________________________________________ Phone No.: ______________________________________________________________________ Gas Log Burner Size: 24”...
