1.1 RMC20 Front Panel Description
Fig. 1.1.1 RMC20 Front Panel Detail
The RMC20 LED definitions are as follows:
ITEM
Tx LED
RX LED
Power LED
©
2006 RuggedCom Inc. All rights reserved
Activity
Blinking (Yellow)
Blinking (Yellow)
Solid (Green)
5
Comments
Transmitting Serial Data
Receiving Serial Data
Power On
Rev100
