- Page 1 O w n e r ’s M a n u a l I n t e r n a t i o n a l engi ne ered fo r t h e wo r ld ’s h ar s he s t c lim ates ®. .. ( w h erever yo u h a pp en to l i ve) ava i l a ble o n w w w.
- Page 2 If you require additional information, please call your local Arctic Spas® dealer. A complete list of dealers and international Arctic Spas websites can be found on the internet at www.ArcticSpas.com.
-
Page 3: Table Of Contents
Contents Important Safety Instructions ............3 Hyperthermia ...................5 Spa Specifications ................6 Installation Instructions ..............7 Electrical Specifications ..............8 Electrical Installation Instructions ............8 Startup Procedures ................9 Spa Overview ..................11 Jets ....................12 Topside Control Panel ..............13 Read and Follow Quick Reference Guide ..............14 All Instructions Spa Care and Maintenance .............16 It is important to LED Replacement ................19... -
Page 4: Important Safety Instructions
Important Safety Instructions: READ AND FOLLOW ALL INSTRUCTIONS CAREFULLY When installing and using this electrical equipment, basic safety precautions should always be followed, including: 1) WARNING: To reduce the risk of injury, do not permit children to use this product unless they are closely supervised at all times. -
Page 5: Save These Instructions
b) Since excessive water temperatures have a high potential for causing fetal damage during the early months of pregnancy, pregnant or possibly pregnant women should limit hot tub water temperatures to 100ºF (38ºC). If pregnant, please consult your physician before using a hot tub. c) The use of alcohol, drugs, or medication before or during hot tub use may lead to unconsciousness with the possibility of drowning. -
Page 6: Hyperthermia
AVERTISSEMENT: Avant d’utiliser une cuve de relaxation mesurer la température de l’eau à l’aide d’un ther momètre précis. WARNING: Do not use a hot tub immediately following strenuous exercise. AVERTISSEMENT: Ne pas utiliser une cuve de relaxation immédiatement après un exercice fatigant. WARNING: Prolonged immersion in a hot tub may be injurious to your health. -
Page 7: Spa Specifications
5100 Litres 866 Kg x 16Amp 171.75”x93” 50.5” NA / Euro 1347 Gallons 1909 Lbs 1 phase x 32Amp or 3 phase Beauport 240 Volt, 50 Amp 436cm x 236cm 128.5 cm 5500/2x3600 5100 Litres 866 Kg x 16Amp 86”x86”... -
Page 8: Installation Instructions
Spa Specification chart. This weight per square foot must not exceed the structure’s rated capacity, or serious structural damage could result. Your Arctic Spas Dealer can help you with local information such as zoning regulations and building ®... -
Page 9: Electrical Specifications
For detailed instructions on how to use onSpa, download the app here http://www.arcticspas.com/support/downloads-manuals-brochures/ or go to www.ArcticSpas.com Electrical Installation Instructions ARCTIC SPAS MUST BE WIRED IN ACCORDANCE WITH ALL ®... -
Page 10: Startup Procedures
Startup Procedures IMPORTANT: Your Arctic Spa has been thoroughly tested during the manufacturing process to ® ensure reliability and long-term customer satisfaction. Before filling the spa, wipe the spa shell clean with a soft rag. Make sure to fill spa through filter bucket. The following instructions must be read and followed exactly to ensure a successful start-up or refill. - Page 11 When the water temperature climbs above 85ºF (29ºC), proceed to the next step. 9) Test and Adjust Sanitizer level (Chlorine ideal 1 - 3 ppm or Bromine ideal 3 - 5 ppm). 10) Rotate diverters to centre position and press “Pump 2” button on topside control panel for 5 seconds to activate the “Boost filtration system”.
-
Page 12: Spa Overview
Spa Overview A: Topside Control | See Topside Control Overview section in this manual. B: Waterspout | Control by an ON/OFF valve. C: Neckjets | Rotating neck jets are designed for your own personal comfort and are controlled by an ON/OFF valve. D: Monsoon Jet E: Jets | All jets are adjustable and can be turned ON/OFF and can also be locked in the fully ON position, simply by... -
Page 13: Jets
Single Pulse Five Inch (5”) Jets The five-inch Hydro-massage jets give a wide circular massage. These jets are adjustable by turning the face of the jet clockwise for a stronger flow and counter-clockwise for a softer flow and eventually off. The Jet can also be locked in the fully ON (open) position by turning the face of the jet clockwise until it does not go any further. -
Page 14: Topside Control Panel
Topside Control Panel Your spa control has been specifically designed so that by simply connecting the spa to a properly grounded source, and following the start-up procedures in this manual, the spa will automatically heat to the set temperature. Many other functions, such as filtration, safety checks and maintenance reminders have been automated so that your spa experience will be as carefree as possible. -
Page 15: Quick Reference Guide
Quick Reference Guide The Quick Reference Guide provides a quick overview of your spa’s main The Quick Reference Card provides a quick overview of your spa’s main functions and The Quick Reference Card provides a quick overview of your spa’s main functions and The Quick Reference Card provides a quick overview of your spa’s main functions and functions and the operations accessible with your digital control pad. -
Page 16: Troubleshooting
PROGRAMMING THE SETTINGS - Pump 2, Pump 3 (Pump 4 & Pump 5 on an epic series spa) and the blower run for 20 seconds, then - Pump 1 runs at low speed for the programmed number of hours (see below), and - The ozonator is turned on. -
Page 17: Spa Care And Maintenance
IMPORTANT: With reusable filters, it is necessary to rinse the filter cartridges week- ly. Every month, and each time the spa is drained for cleaning, clean the cartridges in filter cleaner. (With Arctic Spas disposable filters, simply replace the cartridge whenever the spa is drained, or about every three months). -
Page 18: Filtration System
Care of Spa Pillows The spa pillows used in many of the Arctic Spas ® models will provide years of comfort if treated with care. They have been positioned above the water level to minimize the bleaching effects of chlorinated water and other spa water chemicals. - Page 19 MANUAL SAFETY COVER Care of the Spa Cover WARNING: The cover is a manual safety cover that meets or exceeds all prevailing requirements of ASTM Standards for spa safety covers when installed and used correctly as of the date of manufacture. Non-secured or improperly secured covers are a hazard.
-
Page 20: Led Replacement
LED Light Replacement All Arctic Spas come equipped with two 12 volt multicolored ® underwater lights for night use. The Family Light Package option comes with five lights. Should you need to change any light, follow these simple steps: 1. Make sure the lighting is turned off, by checking the topside be sure the light icon is not showing. -
Page 21: Water Maintenance
Methods For Testing The Spa Water Accurate water testing and analysis are an important part of effectively maintaining your spa water. To follow the Arctic Spas recommended program, you must have the ability to test for: ® • Total Alkalinity (TA) •... - Page 22 • Rinse the test cells before and after each use. • Do not dispose of test samples into the spa water. • When adding drops of chemicals from the kit (the reagents) into the test block, hold the bottle vertically and add the drops slowly to be sure the correct quantity is used. •...
- Page 23 circulation of water can cause the erosion of metals from spa equipment which can present possible scaling and staining problems in your spa. Cases of source water with high minerals (such as some well water): 1. We recommend you add 3 1/2 tablespoons (48 grams) of Arctic Pure Best Defense per 1000 ®...
- Page 24 If the pH is too high, it can be decreased by adding Arctic Pure Adjust Down to the spa water. ® 5. It is important to check the pH on a regular basis. The pH will be affected by the bather load, the addition of new water, the addition of various chemicals, and the type of sanitizer used.
- Page 25 Start-up: 1. Add pucks to floating dispenser and open to setting 4. 2. Add 7 tablespoons (100 grams) of Arctic Pure ® Refresh per 1500 litres (396 gallons) of water. 3. Add 1 tablespoon (14 grams) of Arctic Pure ® Spa Boost per 1000 litres (265 gallons) of water.
-
Page 26: Common Spa Water Problems~Cause & Remedy
Common Spa Water Problems~Cause & Remedy PROBLEM POSSIBLE CAUSES A. Poor Filtration CLOUDY WATER B. Suspended particles C. Organic contaminants build up D. pH high E. Total alkalinity high F. Combined chlorine in the water G. High dissolved solids H. Hardness too high A. - Page 27 SOLUTIONS ® A. Dirty filter, clean with Arctic Pure Filter Restore (not with disposable filter). Increase Filter cycle. ® B. Add Arctic Pure Easy Clear ® C. Shock treatment with Arctic Pure Refresh ® D. Add Arctic Pure Adjust Down until level reads 7.2-7.6 ®...
-
Page 28: Warranty
No labour warranty is provided by Arctic Spas for retrofitted Spa Boy systems. Arctic Spas® warrants the spa shell to the customer against water loss due to structural Disclaimer: This is not an automatic water care system. The system is set up for failure for as long as the original customer shall own the spa. -
Page 29: Conditions Of Warranties
DISCLAIMERS spa and Arctic Spas® determination with regard thereto shall be final. Arctic Spas® will not be liable for loss of use of the spa or other incidental or EXCLUSIONS consequential costs, expenses or damages that may include but not limited... -
Page 30: Troubleshooting Spa Problems
Troubleshooting Spa Problems 1. Nothing functions: The GFCI Breaker has tripped or there is a power failure. Test GFCI Breaker. Turn breaker back on and see if spa powers up, if not contact your factory authorized dealer. 2. Spa does not heat: Check to see if the heat indicator is on or there are any error messages on the topside control panel. -
Page 31: Preforming Software Upgrade
Performance and Reliability is the Arctic Spas Customer Guarantee. If ® your spa cannot be repaired under our extensive warranty, Arctic Spas will provide a replacement spa ® equal in value to the original purchase price of the defective spa. Our philosophy Guarantees you Cus- tomer Satisfaction. - Page 32 engin eered fo r t he wo r l d ’s har she s t c l imate s ®. .. (w h e re ve r yo u h ap p en to l i ve) #19769...
