This manual contains supplementary instructions regarding the use of the
computer. It explains the cases where the operation of the computer differs from
that in the Operating Instructions.
Your computer is equipped with the HSPA modem enabling you to communicate
using radio frequencies.
Contents
Description of Parts ............................................................ 2
Inserting/Removing a SIM Card ......................................... 2
Supplied Accessories ......................................................... 2
Installing the Software ........................................................ 3
Troubleshooting .................................................................. 5
Specifi cations ...................................................................... 6
Appendix .............................................................................. 7
Terms and illustrations in this Manual
NOTE:
CAUTION:
(Start) - [All Programs] :
[start] - [Run]:
:
:
Some of the illustrations in this manual may differ slightly in shape from the
actual items in order to make the explanation easier to understand.
About the abbreviations in this manual, refer to the table on page 7.
Supplementary Instructions
Useful and helpful information.
Condition that may result in minor or moderate injury.
Click
(Start), and then click [All Programs].
Click [start], and then click [Run].
You may need to double-click in some cases.
Page in these Supplementary Instructions or in the
Reference Manual for the computer.
Reference to the on-screen manuals.
for HSPA Modem
Personal Computer

Advertisement

loading

  Related Manuals for Panasonic CF-U1G

  Summary of Contents for Panasonic CF-U1G

  • Page 1: Table Of Contents

    Supplementary Instructions for HSPA Modem Personal Computer This manual contains supplementary instructions regarding the use of the computer. It explains the cases where the operation of the computer differs from that in the Operating Instructions. Your computer is equipped with the HSPA modem enabling you to communicate using radio frequencies.
  • Page 2: Description Of Parts

    Description of Parts Refer to the Operating Instructions for the computer. Inserting/Removing a SIM Card Before using the HSPA modem, set a SIM card to the SIM card slot. Refer to the Operating Instructions for the computer. Supplied Accessories Wireless WAN (HSPA) Software CD-ROM ............1...
  • Page 3: Installing The Software

    Connect the CD/DVD drive to the computer. Turn on the computer, and run the Setup Utility by pressing while [Panasonic] boot screen is displayed. If [Enter Password] is displayed, input the Supervisor Password. Select the [Advanced] - [Wireless Confi guration] menu, and set [Wireless WAN] to [Enabled].
  • Page 4 Installing the Software Click [start] - [RUN], enter “x:* \gb2kpack\setup.exe”, and click [OK]. “x:” is the drive letter of the CD/DVD drive. Change this to match the drive letter on your own computer. Uninstalling the software Click (Start) - [Control Panel] - [Uninstall a program] - [Wireless WAN Software Installer for Gobi 2000], and then click [Uninstall] to uninstall the software.
  • Page 5: Troubleshooting

    Troubleshooting Cannot • <Except for CF-H1 series> communicate. Confi rm that wireless switch is in ON. • Confi rm that [Wireless WAN] is set to [Enabled] in the [Advanced] menu of the Setup Utility. • Use the Wireless Switch Utility and confi rm that the wireless WAN is on.
  • Page 6: Specifi Cations

    Specifi cations Data Communication HSUPA Category 6, 5.7 Mbps HSDPA Category 8, 7.2 Mbps UMTS 3GPP Release 5 EDGE/ MultiSlot Class 10 GPRS Other Features Mobile Originated SMS (MO-SMS) Mobile Terminated SMS (MT-SMS) No Support Voice No Support 1.8/3V SIM Support...
  • Page 7: Appendix

    Appendix Abbreviations EDGE Enhanced Data rates for Global Evolution GPRS General Packet Radio Service HSDPA High Speed Downlink Packet Access Subscriber Identity Module Short Message Service UMTS Universal Mobile Telecommunications System HSPA High Speed Packet Access HSUPA High Speed Uplink Packet Access...
  • Page 8 Importer’s name & address pursuant to the EU GPSD (General Product Safety Directive) 2001/95/EC Art.5 Hagenauer Straße 43 65203 Wiesbaden Germany © Panasonic Corporation 2010 Printed in U.K. UK0110-1050 CPE02180YA...
