- Page 1 Turf Sweeper & Parts Manual TV 30 7/11...
- Page 2 TV 30...
- Page 3 MEANING: Failure to understand and obey this warning may result in injury to you or others. Whenever this symbol is used, please pay very close attention to the information presented, and make sure you fully understand. If you do not, contact your dealer or Harper Industries, Inc. for clarification.
- Page 4 TWELVE MONTHS from the original date of retail purchase to the original purchaser. Harper Industries will repair or replace, at our option, any part which our examination shows to be defective. Warranty is limited to parts, labor and ground freight delivery of replacement parts.
- Page 5 PARTS SECTION Table of Contents Table of Contents Frame and Engine Frame Assembly..........OPERATOR SECTION Control Arm Assembly........To the Owner or Operator..........Front Axle Assembly........Warranty Statement............Engine and Tank Installation......Table of Contents............Diesel Engine Assembly........Specifications..............Fuel Tank Assembly......... Control Identification Engine Shield Assembly........
- Page 6 Terresolve EL 3068, bio-based, high-performance, ISO 68 – viscosity, severe ser- vice NOTE: Following publication of this manual, certain changes in standard equipment and/or options may have occurred which would not be included in these pages. Your Harper dealer is the best source for up-to-date information. TV 30...
- Page 7 Control Identification ROPS – Roll-Over Protective Structure is certified and designed to protect operator in case of a roll-over. Always wear a safety belt. Steering Wheel – steering is hydraulically controlled. Turning radius of the sweeper head is approximately 46 in. Steering wheel HOPPER HOPPER DOOR...
- Page 8 Hopper Lift Height Decal – always keep the Park Brake Indicator – light illuminates height of the turf vac in mind during operation when key switch is on and park brake is set. and be alert for wires, branches, etc. If this decal is damaged, replace it immediately.
- Page 9 SWITCH Mercury is highly toxic. If mer- Remove safety lock before lowering hopper. cury switch container is replaced, return old container to Harper Industries for disposal. SAFETY WARNING! Do not leave Turf Vac unattended, or...
- Page 10 Diesel Fuel Safety Guidelines • Always use an approved container for transporting diesel fuel. Equipment & Controls • Do not allow open flames or sparks • Read and understand this manual. while performing maintenance or refu- • Altering this equipment in any manner eling.
- Page 11 Battery • Before starting the machine, visually inspect all nuts, bolts and other fasten- SAFETY WARNING! ers to see that they are properly se- Batteries can produce explosive gas. cured. Nuts, bolts and other fasteners Use extreme caution when working on should be checked every 8 to 10 hours the battery.
- Page 12 • The hydraulic oil level should be moni- Maintenance tored daily with the oil dip stick located on the top of the hydraulic oil reservoir Hydraulic System next to the filter indicator. • The hydraulic system of the TV30D is •...
- Page 13 Grease Zerk Locations Left Side Right Side Front Axle (R) Front Pivot* Deck Lift (L) Front Pivot* Deck Lift (R) Broom (L) Roller (L) Roller (R) Front Axle (L) Broom (R) * same zerk Air Cleaner Front Pivot Zerk Air Intake Front Axle Zerks Clamps (3) PROCEDURE...
- Page 14 Cooling System Engine Oil Engine Oil Fill Engine Oil Filter Hydraulic Coolant Recovery Cooler Bottle Dipstick Radiator • The dipstick and engine oil fill are lo- cated on the back left side of the en- Radiator Fill gine. • Clear hydraulic oil cooler and radiator •...
- Page 15 Fuel Filter Standard Torque Chart Fuel Filter SAFETY WARNING! Refer to the Standard Torque Chart when- ever bolts, nuts or screws are tightened. • Fuel filter is located under the same cover as the engine oil fill and dipstick at the back left side of the engine. •...
- Page 16 See the Kubota Operation and Maintenance Manual provided with the TV30D for a detailed description of all maintenance and service procedures for the engine. • For the TV30D, Harper Industries recommends the following: Daily or Before Starting Engine Check for leaks, smell of fuel, loose or damaged parts...Repair as needed.
- Page 17 1000 Hour Maintenance ̶ Perform these and all previous items: Change hydraulic oil..............19 gal. Terresolve EL 3068 Check valve clearance Every One or Two Months ̶ Perform these and all previous items: Recharge battery 1500 Hour Maintenance ̶ Perform these and all previous items: Check of fuel injection nozzle injection pressure 3000 Hour Maintenance ̶...
- Page 18 TV 30...
-
Page 19: Parts Section
Parts Section TV 30... - Page 20 TV 30...
- Page 21 Table of Contents PARTS SECTION Table of Contents Frame and Engine Frame Assembly..........Control Arm Assembly........Front Axle Assembly......... Engine and Tank Installation......Diesel Engine Assembly........Fuel Tank Assembly.......... Engine Shield Assembly........Deck Assembly..........Deck Installation..........Broom Kit............1.10 Finger Kit............1.11 Verticut/Dethatch Kit.........
- Page 22 TV 30...
- Page 23 PARTS FRAME & ENGINE SECTION TV 30...
- Page 24 TV 30...
- Page 25 TV 30 ii 1.1...
- Page 26 TV 30...
- Page 27 TV 30...
- Page 28 TV 30...
- Page 29 TV 30 ii 1.4...
- Page 30 TV 30...
- Page 31 TV 30 ii 1.5...
- Page 32 TV 30...
- Page 33 TV 30...
- Page 34 TV 30...
- Page 35 TV 30 ii 1.8...
- Page 36 TV 30...
- Page 37 TV 30 1.10...
- Page 38 TV 30 1.11...
- Page 39 TV 30 1.12...
- Page 40 TV 30 1.13...
- Page 41 TV 30 ii 1.13...
- Page 42 TV 30 1.14...
- Page 43 TV 30 1.15...
- Page 44 TV 30 1.16...
- Page 45 TV 30 ii 1.16...
- Page 46 TV 30 1.17...
- Page 47 TV 30 1.18...
- Page 48 TV 30...
- Page 49 PARTS HYDRAULIC SECTION TV 30...
- Page 50 TV 30...
- Page 51 TV 30...
- Page 52 TV 30...
- Page 53 TV 30...
- Page 54 TV 30...
- Page 55 TV 30...
- Page 56 TV 30...
- Page 57 TV 30...
- Page 58 TV 30...
- Page 59 TV 30 ii 2.9...
- Page 60 TV 30 iii 2.9...
- Page 61 TV 30 iv 2.9...
- Page 62 TV 30 2.10...
- Page 63 TV 30 ii 2.10...
- Page 64 TV 30 2.11...
- Page 65 TV 30 ii 2.11...
- Page 66 TV 30 2.12...
- Page 67 TV 30 ii 2.12...
- Page 68 TV 30 2.13...
- Page 69 TV 30 ii 2.13...
- Page 70 TV 30 2.14...
- Page 71 TV 30 ii 2.14...
- Page 72 TV 30 2.15...
- Page 73 TV 30 ii 2.15...
- Page 74 TV 30 2.16...
- Page 75 TV 30 ii 2.16...
- Page 76 TV 30 2.17...
- Page 77 TV 30 ii 2.17...
- Page 78 TV 30 2.18...
- Page 79 TV 30 ii 2.18...
- Page 80 PORT LABEL ABBREVIATIONS ABBREVIATION DESCRIPTION AUXILIARY BOX/HOPPER DOOR EXTEND (CLOSE) BOX/HOPPER DOOR RETRACT (OPEN) BOX/HOPPER LIFT EXTEND (UP) BOX/HOPPER LIFT RETRACT (DOWN) CASE DRAIN CHARGE PRESSURE CHARGE RETURN CASE SUCTION DECK LIFT EXTEND (DOWN) DECK LIFT RETRACT (UP) DECK MOTOR PRESSURE DECK MOTOR RETURN DECK PRESSURE DRAIN...
- Page 81 PARTS ELECTRICAL SECTION TV 30...
- Page 82 TV30 DIESEL WIRING SCHEMATIC DIAGRAM OVERVIEW 332017 BRAKE BLACK BLACK INDICATOR BLACK MASTER LIGHT PUR/RED PUR/RED PUR/RED BRAKE RED/WHT PUR/RED PUR/RED SWITCH HARNESS BLACK RED/WHT PACKARD 630 RED/WHT SERIES. 10 CAVITY HI / LO PUR/YEL SWITCH BLACK BLACK YEL/GRN YEL/GRN HOPPER YEL/GRN PACKARD 630...
- Page 83 TV 30...
- Page 84 TV 30...
- Page 85 TV 30...
- Page 86 TV 30...
- Page 87 TV 30...
- Page 88 TV 30...
- Page 89 TV 30...
- Page 90 TV 30 ii 3.8...
- Page 91 TV 30...
- Page 92 NOTES Harper Industries, Inc. Telephone: 620-896-7381 151 E. Highway 160 Toll-Free: 800-835-1042 Harper, KS 67058 Fax: 620-896-7129 Website: www.harperindustries.com E-mail: info@harperindustries.com TV 30...
- Page 93 © 2011 Harper Industries, Inc. All rights reserved. Printed in U.S.A. TV 30...
