15. Holden 6 Pin Adapter

Used for Australian Holden of OBD
generation 1.
Japanese cars such as Toyota and Nissan
assembled in Australia with Holden built
engines may have this type of adapter, too.
Vehicle side DLC is generally located
beneath the glove box to the center facia.

16. GM Opel 10Pin Adapter

Used for the communication with
Opel cars of OBD generation 1.
Also available with MULTISCAN
Australian Holden, South American
Opel and European
software packages.
Vehicle side DLC
located in the fuse box beneath the dashboard or near the parking brake.

17. Ford 20 Pin Adapter

Used for the communication with Ford cars
of OBD generation 1, including Australian
and British Fords.
Vehicle side DLC is generally located in the
fuse box beneath the dashboard.
(P/N. 3001-0023)
(P/N. 3001-0019)
Vauxhall
is generally
(P/N. 3001-0020)
Chapter 2 - 11
