USER MANUAL

12. Kia 20Pin Adapter

Used for the communication with Kia cars of OBD generation 1.
DTC read & erase and data stream
functions are available for the cars
with this type of adapter.
Refer
message.
The appearances of Kia 20Pin adapter and Ssangyong 20Pin Rectangular
adapter are exactly same, however, the internal wiring and circuit are different.
Check the engraved name and the body color of the adapter carefully before
use. Improper adapter connection may result in serious malfunction of
either control system and MULTISCAN plus head unit

13. Ssangyong 20Pin Rectangular Adapter

Used for Ssangyong cars of OBD
generation 1.
Vehicle side DLC is located in the
engine compartment.
Refer to the warning above.

14. Ssangyong 14Pin Circular Adapter

(P/N. 3001-0007)
Used for old Ssangyong cars of OBD
generation 1.
Vehicle side DLC is located in the engine
compartment.
For MULTISCAN plus
(P/N. 3001-0004)
to the following warning
WARNING
Chapter 2 - 10
(P/N. 3001-0005)
